Chapter 3: Jumpers and Connectors
RTC Battery Connector
Connector type: 1x2 2-pin header, 1.25mm pitch
Connector location: J7
2
1
Pin
Definition
1
GND
2
VBAT
Copyright © 2023 NEXCOM International Co., Ltd. All Rights Reserved.
Internal USB Connector
Connector type: 1x4 4-pin header, 1.0mm pitch
Connector location: J8
1
4
Pin
Definition
1
VCC
3
D+
29
Pin
Definition
2
D-
4
GND
VTC 1021 Series User Manual
