Chapter 4: Jumpers and Connectors for VMC 3000 Series

Internal Connectors and Jumper Settings

Waterproof I/O Board

Power Input Connector

Connector size: 1x3 3-pin header
Connector location: CN3
1 3
Pin Definition
1 IGNITION_F
2 VINGND
3 VIN
Copyright © 2012 NEXCOM International Co., Ltd. All rights reserved

Power Output Connector

Connector size: 1x8 8-pin header
Connector location: J5
1 8
Pin Definition
1 MSMB_DATA
2 MSMB_CLK
3 GND
4 GND
5 GND
53
Pin Definition
6 5V_OUT
7 12V_OUT
8 12V_OUT
MH1 GND
MH2 GND
