Chapter 5: Jumpers and Connectors for VMC 4000 Series

COM1 RI/Power Switch

Connector size: 4-pin DIP switch
Connector location: SW2
1 2 3 4
Pin Definition
1 COM_12V
3 SP_RI_1
5 COM_RI_PWR
7 COM_RI_PWR
Pin 12V
SW2.1 ON
SW2.2 OFF
SW2.3 OFF
SW2.4 OFF
(*) Default Setting
Copyright © 2012 NEXCOM International Co., Ltd. All rights reserved
Pin Definition
2 COM_5V
4 GND
6 COM_RI_PWR
8 COM_RI_PWR
RI
5V GND
(*)
OFF OFF OFF
ON OFF OFF
OFF ON OFF
OFF OFF

VGA Connector

Connector size: 2x8 16-pin header
Connector location: CN6
2
1
Pin
1
3
5
7
9
11
13
15
ON
74
16
15
Definition Pin
VGA_RED 2
VGA_BLUE 4
VGA_GND 6
RGB_GND 8
VGA_+5V 10
VGA_GND 12
VGA_HS 14
VGA_CLK 16
Definition
VGA_GREEN
VGA_GND
RGB_GND
RGB_GND
VGA_GND
VGA_DATA
VGA_VS
NC
