Revert to Saved
Save Window As Image
Preferences
DeltaSphere-3000 3D Scene Digitizer
VRML
RTPI
XYZ
XYZI
XYZRGB
Basic Tab
Display Units
Generates a VRML model (.wrl file) in either Textured or
Color-Per-Vertex format. Also choose minimum angle to
triangle (The number represents the angle between the path of
the laser from the DeltaSphere and the edge of the triangle
being created. 12 is the default The greater the number, the
more points that will be connected by triangles.)
Typically used to export a subset of the file by selecting that
subset.
Exports an ASCII (text) file with the x, y, and z coordinates for
each data point.
The same as XYZ above, plus the laser intensity value for each
point.
The same as XYZ above plus the 3 color values for each point
(for color RTPI files).
Treates an image that is the view of RTPI files shown in
SceneVision windows.
If a range or model file has been edited, but not saved, this
restores the data to the last saved version. This is often used
when aligning color. This function cannot be undone.
Creates an image file of the contents of the active window in
one of several image formats (including jpg, bmp, tif, and png)
Specifies many parameters for SceneVision-3D
Specify inches, Feet and inches, meters, centimeters or
millimeters for all measurements. (Currently all data is stored
in inches.)
