Page Setup
Print Preview
Print
Recent Scenes
Exit
DeltaSphere-3000 3D Scene Digitizer
Advanced
Max New Texture Size
Range Align Iterations
Angle-to-triangle cutoff for 3D Models
Model size warning level Warns the user if the model created will be greater than this
Save
Revert
Cancel
Features in the Advanced tab should only be changed by expert
users.
Specifies the maximum texture size for VRML models created
with SceneVision. (Note: SceneVision automatically chooses
the correct texture size for your graphics card. This function is
for models that will be displayed in a different program.)
Specifies the number of iterations of the Compute Fit function
in range alignment. Occasionally a larger number, executing
additional iterations, will improve the alignment.
Determines which points will be connected
when creating a triangular mesh from range data. Lower angles
will connect points at a very oblique angle to the scanner, often
forming 'spiders webs' between surfaces that should not be
connected.
size.
Saves your current preferences
If you've changed preferences without saving, this restores the
saved preferences
Exits preferences.
Specifies printing parameters.
Displays what the page will look like if printed.
Prints the contents of the active window.
Provides list of recently used scene files to open.
Exits SceneVision-3D. If the scene, or any file, has changed
you will be prompted to save the file.
99 9/23/05
