Technical Specifications - Altronix NetWay8E Installation Manual

Fig. 4
PoE
Camera
Transceiver
PoE
Camera
NetWay8E - Front Panel
Parameter Description
No. of Ports Eight (8) PoE+ Ports (10/100/1000 Mbps).
Input power requirements 115VAC, 60Hz, 3.25A or 230VAC, 50/60Hz, 2.0A.
Indicators Power ON LED
Operating Ambient Temperature: -20ºC to 40ºC (-4ºF to 104ºF).
Relative Humidity: 85%, +/- 5%.
Environmental Conditions
Storage Temperature: -20ºC to 70ºC (-4ºF to 158ºF).
Operating Altitude: -304.8 to 3,048m (-1,000 to 10,000 ft.).
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of an insulated DANGEROUS VOLTAGE within
the product's enclosure that may be of sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
www.altronix.com
NetWay8E Typical Application:
I.T.E. 43KC NetWayXT/NetWayXTX
NetwayXT
Repeater
Extends Ethernet
100m
www.altronix.com
Power OUT IN
Receiver
PACE
Long Range Ethernet Adapters
Extends Ethernet approx. 500m
1Gb
LAN/WAN
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside. Refer servicing to qualified service personnel.
To
NetWay8E

Technical Specifications:

- 4 -
PoE +
Typical UL294 Application:
Camera
Card
Reader
HID Solo
115/230VAC
Input
Strike
Stand-by
Batteries
NetWay8E
