Summary of Contents for Altronix NetWay2ES Series
- Page 1 Power over the Ethernet NetWay2ES Series PoE-Powered 2-Port PoE+ Switches Models Include: NetWay2ES - 2-Port PoE+ Switch - Modular plastic case. NetWay2ESWPN - 2-Port PoE+ Switch - NEMA4/4X rated outdoor enclosure. Installation Guide More than just power. Rev. 052521...
-
Page 2: Table Of Contents
Mechanical Drawing and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . pg. 7 - 2 - NetWay2ES Series... -
Page 3: Overview
Overview: Altronix NetWay2ES and NetWay2ESWPN are PoE-powered 2 port PoE/PoE+ switches and are designed for instal- lation at the IDF (Intermediate Distribution Frame) to deploy IP devices . NetWay2ES allows for system expansion by accommodating up to two (2) IP cameras/devices over a single CAT5 or higher structured cable . PoE is passed from a midspan injector, typically located at the MDF (Main Distribution Frame) . -
Page 4: Input/Data Connections
IEEE 802.3af, 802.3at compliant ports rated up to 30W max Yellow LED 10/100 Mbps Green LED 1000 Mbps PoE+ PoE+ Input Signal Output Signal Output Signal Ground Terminal IEEE 802.3bt from midspan/endspan PoE LEDs indicate Output PoE present PoE LED indicates Input PoE present - 4 - NetWay2ES Series... -
Page 5: Typical Application
Product: 0 .25 lb . (0 .11 kg) | Shipping: 0 .42 lb . (0 .19 kg) . Weights (approx.) NetWay2ESWPN: Product: 3 .7 lb . (1 .68 kg) | Shipping: 5 lb . (2 .27 kg) . NetWay2ES Series - 5 -... -
Page 6: Wall Mount Installation
This installation should be made by qualified service personnel . This product contains no serviceable parts . PMK1 outdoor pole mount kits is designed to simplify the installation of Altronix outdoor rated power supplies and acces- sories housed in models WP1, WP3 and WP4 NEMA rated enclosures . PMK1 can be mounted on 2” to 8” (50 .8mm to 203 .2mm) diameter round or 5”... -
Page 7: Mechanical Drawing And Dimensions
(35.1mm) 316 Stainless Steel Padlock Latch Attached 0.375” (9.5mm) Padlock Eye 6.75” (171.5mm) 6.0” (152.4mm) 4.25” (108mm) 304 Stainless Steel Piano Hinge 0.312” (7.9mm) TYP 4 Places 4.0” (101.6mm) 10-32 X 0.25” (6.4mm) 4 Places NetWay2ES Series - 7 -... - Page 8 Notes: Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. IINetWay2ES Series E25U MEMBER - 8 -...
