Schaerer Coffee Prime Operating Instructions Manual page 54

www.schaerer.com
"Water supply" menu item
Display text
Water supply
Waste water system
Water filter
"Grinder / brewing unit" menu item
Display text
Name of left bean hopper
Name of right bean hopper
Switch grinders when one is emp-
ty or blocked
54
Description
Aquachange switching
Option 1: Drinking water tank to mains
water supply
► Open the service door and remove the
drinking water tank.
► Screw in the Aquachange screw with a
screwdriver (size 3).
► Re-insert the drinking water tank and
close the service door.
► Set the water supply source to "Mains
water supply".
Option 2: Mains water supply to drinking
water tank
► Open the service door and remove the
drinking water tank.
► Unscrew the Aquachange screw with a
screwdriver (size 3).
► Re-insert the drinking water tank and
close the service door.
► Set the water supply source to "Int. drink-
ing water tank".
Defined for the first time during commissio-
ning.
► If the value changes, this parameter must
be adjusted.
► If the machine is equipped with a waste
water outlet or a waste water tank, re-
move the screw plug in the drip tray.
See also "Options and optional accessories"
Defines the water filter used.
The selected water connection determines
the selection options for the water filter.
Description
You can define any name you like.
Up to max. 24 characters can be entered.
If one of the bean hoppers is empty, both the
side (left / right) and the assigned name are
displayed in the empty message.
If one grinder generates an empty message
or becomes blocked, an activated parameter
automatically changes to the second grinder.
If the system switches to the second grinder,
this grinder remains assigned until the next
empty message or until the beverage recipe
becomes blocked.
Setting range Notes
Mains water
supply /
int. drinking wa-
ter tank
Aquachange screw
Waste water (Option)
outlet /
The machine requires an
optional waste water out-
let.
waste water (Option)
tank /
The machine requires an
optional external waste
water tank.
drip tray (Standard)
The drip tray is locked with
a screw plug.
No filter The system makes a di-
stinction between the
External filter
mains water supply and a
Internal filter
drinking water tank.
Setting range Notes
A – Z Recommended setting:
Name by coffee variety,
0 – 9
e.g. espresso, decaf, etc.
Inactive / active The parameter is automa-
tically activated if the [Sa-
me] setting was selected in
the "Coffee blend in both
bean hoppers" parameter.
Programming
BASCP_EN
V05 | 08.2014
