Example
10
Option
Payment system interfaces
Cup dispenser
Under-machine cooling unit
Second grinder with bean hopper
Description
Commercially available payment systems
according to the MDB standard can be
connected.
A payment system can be retrofitted.
Possible interfaces:
• MDB-S
• DIVA2
• DIVA2 Max
Connection to dispensing equipment and
cash systems:
• Via E protocol
• Via CSI protocol
Storage for three different cup sizes. Other
cup sizes can be retrofitted at any time.
Three containers at the top for sugar, swizzle
sticks or similar items.
Cup sizes:
• Diameter 60 – 74 mm
• Diameter 75 – 82 mm
• Diameter 83 – 90 mm
External under-machine cooling unit for ma-
chines with Milk Smart.
Capacity: 9.5 l
Application with
foamer UM CU set (under-machine cooling
unit).
A second bean hopper including a grinder
can be retrofitted.
Capacity per bean hopper: 600 g
Product description
non-cleaning
