Schaerer Coffee Prime Operating Instructions Manual page 43

Cleaning
BASCP_EN
V05 | 08.2014
► Turn the powder outlet elbow (1) upwards by 90°.
► Remove the hoses to the powder containers.
► Remove the hoses (2) from the powder system outlet to the beverage outlet.
► Pull out the powder system outlet with the green pushing device.
► Turn the mixing bowl to the right by 90° and pull it forward.
► Lift the powder container slightly at the front and then lift it out.
► Disassemble and clean the powder system outlet and the powder containers.
► Remove the cover (A) and empty the powder container.
► Loosen the right cap nut (B) and remove with the powder outlet elbow.
► Loosen the left cap nut (C) and pull out together with the dosing screw (D).
► Carefully push the two side panels slightly apart and pull the loosening wheel (E) out of the
guides.
► Thoroughly clean all of the individual parts with fresh water.
