Step
1
2
3
4
Run data
The Run Data pane shows the current values of some parameters, for example rocking
motion and accumulated time. To change the Run Data display, select View:Run Data,
right click in the Run Data pane and:
•
•
ReadyToProcess WAVE 25 Operating Instructions 29009597 AD
Action
In the System Control module:
select Manual:Execute Manual Instructions
•
or
use the shortcut Ctrl+M.
•
Result: The Manual instructions dialog opens.
In the Manual instructions dialog:
Click the + symbol to show the instructions for the instruction group that
•
you want to modify.
Select the instruction that you want to modify.
•
Enter the new values for the instruction.
•
To execute several instructions at the same breakpoint, select and edit an
instruction and click Insert. Repeat for several instructions.
Note:
To update parameter fields during run, check the Auto update... box.
To perform the instructions, click Execute.
select Run Data Groups:Detailed to show more details
or
select Customize to customize the appearance of the Run Data pane.
3 System description
3.6 UNICORN software overview
3.6.3 System control
