5.1.1

Select the tray and Cellbag bioreactor

Select the Cellbag bioreactor size and corresponding tray according to application re-
quirements and system configuration. See the table below for guidelines.
Culture volume/
bioreactor (L)
0.3 to 1
0.5 to 5
1 to 10
1 to 10
5 to 25
Note:
Note:
ReadyToProcess WAVE 25 Operating Instructions 29009597 AD
Cellbag bioreactor
size (L)
2
10
20
22
50
To use a 20 L or 50 L Cellbag bioreactor, the system must be configured for
single mode.
Depending on application and configuration it might be possible to cultivate
below the recommended minimum volume. However, it is highly recommended
to stay above this volume for applications that require high agitation, and pH
and DO control. The temperature, pH, and DO sensors need to be submerged
in liquid throughout the complete rocking cycle to function correctly.
5.1 Set up the system
5.1.1 Select the tray and Cellbag bioreactor
Tray
Single mode
Tray 10, Tray 20
Tray 10, Tray 20
Tray 20
Tray 50
Tray 50
5 Operation
Dual mode
Tray 20
Tray 20
N/A
Tray 50
N/A
