Notes:
1. The PS-12 and PS-11 modules can be powered using either AC (100 – 240 V
(96 – 340 V). The modules cannot be powered simultaneously via both AC and DC
sources.
2. AC mains power can be supplied to the PS-12 and PS-11 modules only.
WARNING. Supplying AC mains power to a PS-22 or PS-21 module will destroy it.
3. DC mains power to the PS-12 and PS-11 modules can be supplied in any polarity.
4. DC mains power to the PS-22 and PS-21 modules can be supplied only as shown on
the diagrams above.
WARNING. Supplying DC mains power to the PS-22 or PS-21 module in reverse polarity
may severe damage the modules, as there is no protection against reverse polarity on
this input.
5. External temperature sensor should be installed directly onto the battery near its
negative terminal. Connect the negative sensor wire to B- or R- contact of the Field
Connector.
WARNING. Connecting the temperature sensor in reverse polarity will cause permanent
damage to the sensor.
6. The polarity of the temperature sensor wires are colour-coded. One of the following
colour pairs will be supplied based on availability:
Hardware Manual Version 7.16
Positive Terminal (+)
connected to TS
Black striped White
Grey
White
Red
Black
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
Negative Terminal (-)
connected to B- or R-
Black
Black
Black
Black
Black striped Grey
) or DC
