6.5.2 Dual Serial Option Board Connections

RJ45 Pin
1
2
3
4
5
6
7
8
Wiring diagrams for each port of the Dual Serial Option Board are the same as shown in the
"Serial Option Board Connections" chapter earlier.
Hardware Manual Version 7.16
Direction
OUT
N/A
OUT
IN
Common
IN
IN
OUT
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
RS-232 RS-422 / RS-485
DTR
N.C.
RTS
DCD
GND
CTS
RxD
TxD
N/A
N.C.
TX+
N/A
GND
RX+
RX-
TX-
Page 103
