semaphore KINGFISHER PLUS+ Hardware Reference Manual page 189

Fujicon DO-6 Pin DO-6 Outputs
1 Channel 1
2 Channel 2
4 Channel 3
4 Channel 4
5 Channel 5
6 Channel 6
7 Channel 7
8 Channel 8
9
10
11 Channel 9
12 Channel 10
13 Channel 11
14 Channel 12
15 Channel 13
16 Channel 14
17 Channel 15
18 Channel 16
19 + 12 V
20 + 12 V
Hardware Manual Version 7.16
Belden 9431 Cable Colour
Black
White
Red
Green
Orange
Blue
White/Black
Red/Black
0 V Green/Black
0 V Orange/Black
Blue/Black
Black/White
Red/White
Green/White
Blue/White
Black/Red
White/Red
Orange/Red
Blue/Red
D C
Green/Red
D C
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
Panduit 20 way header pins
1
2
4
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Page 189
