2.5.2 Backplane Cables

While building an RTU, it may become necessary to organise signals and/or power
connections between backplanes. To implement the required interconnections the cables will
be required that can be either assembled (based on the data on the backplane connectors
provided above) or ordered from Semaphore. The following cables are available for order:
Order Code
BPC-01 Interrack 6-way Power Cable, 0.6 m
BPC-02 Interrack 6-way Power Cable, 1.1 m
Interconnect cable, 0.5 m,
BAC-01
8-pin clip on both ends
Interconnect cable, 1.0 m,
BAC-02
8-pin clip on both ends
Interconnect cable, 0.5 m,
BAC-INT-01
8-pin clip to 7-pin terminal plug
Interconnect cable, 1.0 m,
BAC-INT-02
8-pin clip to 7-pin terminal plug
Interconnect cable, 0.5 m,
BAC-PLUS-01
7-pin terminal plug on both ends
Interconnect cable, 1.0 m,
BAC-PLUS-02
7-pin terminal plug on both ends
Interrack 2-way Cable, 1.1 m
(24V / SYNC and GND pins only)
BPC-02-GPS
To distribute GPS time-sync pulse
across racks without power distribution
BPC-SPLIT BPC Splitter Cable, 6-way, 0.1 m
Hardware Manual Version 7.16
Description
POW ER CA B L E S
CO M M C A B L E S
S P EC I AL C A B L E S
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
To be used with Backplanes
(Connectors)
All (J14 to J14)
All (J14 to J14)
BA-x (J13/J15 to J13/J15)
BA-x (J13/J15 to J13/J15)
BA-x (J13/J15) to BA-x-PLUS (J13/J15)
BA-x (J13/J15) to BP-x-PLUS (J13)
BA-x (J13/J15) to BA-x-PLUS (J13/J15)
BA-x (J13/J15) to BP-x-PLUS (J13)
BA-x-PLUS (J13/J15 to J13/J15)
BA-x-PLUS (J13/J15) to BP-x-PLUS (J13)
BA-x-PLUS (J13/J15 to J13/J15)
BA-x-PLUS (J13/J15) to BP-x-PLUS (J13)
All (J14 to J14)
All (J14) to 2x BPC-0x / BPC-02-GPS cables
