Digital Output Example
Driving external load(s) from
digital output(s)
Notes:
1. Polarity can be reversed.
2. For safety reasons, do not connect more than one power source to a Digital Out Common
terminal.
Hardware Manual Version 7.16
Kingfisher Plus+ Hardware Manual
Channel X
Channel Y
Channel Z
Common
http://www.servelec-semaphore.com/
LOAD X
LOAD Y
LOAD Z
Power
Supply
Page 209
