1. INTRODUCTION

This manual details the specifications for each type of module, option board, cable and
accessory available for use with a Kingfisher Plus+ Remote Terminal Unit (RTU).
A Kingfisher Plus+ Modular RTU is a highly configurable device that can monitor and control
a wide range of equipment. Kingfisher Plus+ modular RTUs are easy to install and configure,
can be large or small, use interchangeable modules, have advanced communications, and
support powerful programming languages.
RTU Features
• Two-, four-, six- and twelve-slot backplanes.
• Backplanes can be linked together vertically or horizontally providing up to 64 modules
per RTU.
• AC (100 to 240 V
• Battery backup and built-in battery charger.
• Powerful 32-bit Industrial CPUs.
• Up to 16 communication ports.
• Eight-channel analogue input modules.
• Four-channel analogue output modules.
• Eight and sixteen channel digital input/output modules.
• High speed scanning of I/O-signals.
• Electrical isolation of I/O and communication circuits.
• Designed and tested to comply with International Environmental (climatic) Standards
(IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-78).
• Full support for IEC 61131-3 via the ISaGRAF™ programming environment.
• Multiple pre-defined function blocks for communications and diagnostics.
• Support for multiple protocols including – Modbus, DNP3, Allen Bradley
User Defined.
• Event logging of data (time and date stamped).
• Redundant Power Supplies, Processors and Communications
• Self-configuring of I/O modules at start up.
• PC based configuration and diagnostic software – Toolbox PLUS+ software with
ISaGRAF™ Workbench.
• Local and remote configuration.
• Low power operation – suitable for low cost solar installation.
Product Description
The Kingfisher Plus+ RTU offers many desirable features in addition to the abovementioned
items, including small physical size for ease of mounting and handling, changeable port
types (e.g. RS232/422/485, PSTN, Ethernet, private line etc), front panel LED status and
diagnostic display.
Kingfisher Plus+ RTUs may be configured to user I/O, communication circuit requirements,
power supply requirement and processing functionality by selecting the appropriate modules
Hardware Manual Version 7.16
) and DC (20 to 60 V
AC
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
) power supply modules.
DC
®
DF1, and
