Module Leds - semaphore KINGFISHER PLUS+ Hardware Reference Manual

RJ45 DI-10-GPS
Pin Signal
1 +12V
2 GND
3 PWR_ONn
4 Din
5 Dout
6 PPS
7 nc
8 nc
11.3.7 DI-10 Module LEDs
DI-10-1 [-48] (v3.2)
Hardware Manual Version 7.16
Direction Direction
(DI-10-GPS) (GPS Device)
OUT IN
- -
OUT IN
OUT IN
IN OUT
IN OUT
DI-10 [-48] (v4.3)
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
Signal Level
Power for GPS (100 mA
+12 V
max)
- Power & Signal Ground
Open Drain to Pulled to GND: GPS ON
GND Floating: GPS OFF
RS-232 Serial Data to GPS
RS-232 Serial Data from GPS
5 V TTL Pulse Per Second
Not connected
Not connected
DI-10-[48]GPS (v4.3)
Note
Page 161
