3.2.7 PS-x1 Specifications

PS-11 and PS-21 Power Supply Modules Specifications
Mains Power
Input
AC Rated Voltage Range
(Maximum Input Current)
DC Rated Voltage Range
(Maximum Input Current)
Power Inlet
Connector
Mains Connector Plug
Cable Housing (optional)
Mains Connector PCB Header
'B' Input / Output
DC Rated Voltage Range
(Maximum Input Current)
Backup Battery Type
Maximum Battery Capacity
Output Power
Total Rated Output Power
Maximum total current
Output
12 V Backplane
5 V Backplane
3
Battery
12 V Auxiliary 3
24 V Auxiliary Isolated
Field Connector
Terminal Block Plug (5.0 mm)
PCB Header (5.0 mm)
Hardware Manual Version 7.16
PS-11-x
100 - 240 V, 50 - 60 Hz
(1.5 A)
96 - 340 V
(1.5 A)
PS-11-x
Phoenix PC 4/3-ST-7.62
Dinkle EC762V-03P
Phoenix KGG-PC 4/3
Phoenix PC 4/3-G-7.62
Dinkle ECH762R-03P
Voltage Range
3
10.2 - 14.4 V
5 V ± 5%
10.8 - 15.0 V
10.8 - 15.0 V
24 V ± 5%
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
Not applicable
DC
JST VHR-3M (housing)
JST SVH-41T-P1.1 (contact)
Not available
12.0 – 15.0 V
DC
(4.5 A)
Sealed Lead-Acid (SLA)
1
25 Ah
2
60 W
4.5 A
Maximum
Protection
Current
PS-11 : Electronic
4.5 A
PS-21 : No
3.0 A Electronic
4.5 A Polyfuse
PS-11 : Electronic
4.0 A
PS-21 : No
0.25 A Polyfuse
WECO 120-M-111/07
Phoenix MSTB 2.5/7-G
WECO 120-A-111/07
Phoenix MSTB 2.5/7-ST
PS-21-x
20 - 60 V
DC
(4.0 A)
PS-21-x
JST S3P-VH
Logic
Control
No
No
4
No
Yes
Yes
