semaphore KINGFISHER PLUS+ Hardware Reference Manual page 187

Dimensions
Mounting
Interface Cable Length
Connection Terminals
Relay Part Number
CAUTION! Contacts should be protected with appropriate suppression devices when wired
with inductive loads to increase the service life of relays (please see the
Inductive Loads" section for more details). Contacts should also be protected with external
fusing.
#)
CAUTION! If input voltage is expected to exceed Safety Extra Low Voltage (SELV) levels
(DC 60 V or AC 42 V
PEAK
must be connected to a single power source and no other power sources are allowed to be
connected to this module.
Hardware Manual Version 7.16
253 mm(L) x 90 mm(W) x 70 mm(H)
(280 mm long with 2 end clamps)
35 mm DIN rail
1500 mm (for connection to the DO-6 module)
Phoenix double height PCB terminal unit arranged in a dual three
way terminal (please see wiring diagram). These terminals can
take wire sizes up to 4 mm
Omron G2R-1-E 12 V
(datasheet is available from http://components.omron.eu/)
relative to system earth and/or ground) then all used commons
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
2 .
DC
"Switching
Page 187
