3.2.5 Module LEDs

PS-x2 LEDS
PS-12-x
LED State
ON
960 ms ON,
OK
80 ms OFF
OFF
ON
VIN
OFF
65 ms ON,
450 ms OFF
OVLD
OFF
ON
Tx
OFF
ON
Rx
OFF
BATT (Battery) LEDs
ON
DET
OFF
ON
FLT
OFF
ON
10 ms ON,
BST
2.0 s OFF
OFF
Hardware Manual Version 7.16
Module operating normally.
No communications with RTU Processor Module.
Power off or Module fault.
Mains present / SMPS running
Mains not present / SMPS not running.
In Overload Mode. Output voltage is being ramped down (when powered
from Mains).
PS-x2 is not in Overload Mode.
The PS-x2 is sending data to Processor Module via Backplane.
No data being sent to Processor Module.
Any RTU module sends data via Backplane.
No data being sent by other modules.
Battery or load or DC source connected to B terminals.
No battery nor load nor DC source connected to B terminals
Battery is slow (float) charging.
Battery is not in Float Charge mode.
Battery is fast (boost) charging.
Boost charge is not possible (either external temperature sensor not
connected or it is faulty or battery temperature is out of -20 °C to +60 °C).
Battery is not in Boost Charge mode.
