11.3.2 DI-10 Options and Ordering Info
Unless explicitly noted, all hardware versions of DI-10 modules are described in this manual.
Comparing with its predecessor (v3.2), the newer DI-10 version (v4.3) has some differences
in the module features and specifications and also has a new optional GPS time
synchronisation of the sequence of event recording.
The DI-10 modules without "-48" suffix in their Order Code have Digital Inputs compatible
with 12 V and 24 V control systems. The modules with the "-48" suffix in the Order Code
have elevated change-over thresholds of Digital Inputs designed for use in 48 V and higher
control systems.
Any DI-10 v4.3 module can be a GPS Slave, having its events timing synchronised to an
accurate timing signal generated by a DI-10-[48]GPS v4.3 module (GPS Master) that has an
additional interface for connection to an external 3
Slaves and GPS Masters can be installed in the RTU. With more than one GPS Master
installed in the system, each of them will generate time synchronisation signal for the GPS
Slaves in parallel, providing system redundancy if it is required.
Hardware Manual Version 7.16
Risques Électriques
Seul le personnel qualifié et formé peut installer et entretenir cet
Toujours mettre hors tension les tensions d'entrées dépassant les
limites de la Très Basse Tension de Sécurité (TBTS) (DC 60 V ou
AC 42 V par rapport à la terre du système et/ou du sol)
POINTE
avant d'effectuer toute opération sur ce produit, y compris le
Ne pas le faire peut provoquer un incendie et peut entrainer
des blessures graves ou même la mort du personnel.
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
équipement.
câblage.
rd
party GPS device. Any number of GPS
