semaphore KINGFISHER PLUS+ Hardware Reference Manual page 43

PS-x1 LEDS
PS-11-x
LED State
ON
960 ms ON,
1
OK
80 ms OFF
OFF
ON
1,2
Vsup
OFF
ON
1
Vb
2.0 s ON,
40 ms OFF
ON
1
5V
OFF
ON
1
Vaux
OFF
ON
BATT
1
CHG
OFF
ON
1
FL
OFF
ON
1
BO
OFF
ON
LO 1
OFF
Notes:
1
) Redundant Power Supply will have all LEDs turned ON when the Power Supply module
is switched OFF.
) If the input supply source is disconnected from the redundant Power Supply, the Vsup
2
LED will go OFF.
Hardware Manual Version 7.16
Module operating normally.
No communications with RTU Processor Module.
Power OFF or Module fault.
Mains present / SMPS running
Mains not present / SMPS not running.
Battery detected (the current into or out of the battery exceeds 100 mA)
No battery nor load above 100 mA nor DC source connected to B
terminals.
Backplane power is switched ON.
Backplane power is switched OFF (either start-up or shutdown).
Auxiliary 24 V supply is installed, switched ON and output voltage is OK
Auxiliary 24 V supply is either not installed or switched OFF or output
voltage is out of range
Battery is being charged (current into battery > 100 mA)
Battery is not being charged (current into battery < 100 mA or negative)
Battery is in slow charging (Float Charge) mode.
Battery is not in Float Charge mode.
Battery is fast (Boost Charge) charging mode.
Battery is not in Boost Charge mode.
Battery voltage has reached discharge condition (< 11.5 V ± 0.2 V)
Battery voltage has reached charged condition (> 12.4 V ± 0.2 V)
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
PS-21-x
Description
Page 43
