12.4.2 DO-2 Module LEDs
12.4.3 DO-2 Specifications
DO-2 16 Channel Digital Output Module Specifications
Outputs per Module
Commons
Relay Type
Maximum Switched Voltage
Maximum Switched Current
Minimum Load
Contact Resistance
Operating Temperature
Storage Temperature
Operating Humidity
Relay Operations
Fuse Monitor LED
Relay Part Number
Hot Swap
If input voltage is expected to exceed Safety Extra Low Voltage (SELV) levels
#) CAUTION!
(DC 60 V or AC 42 V
be connected to a single power source and no other power sources are allowed to be
connected to this module.
Hardware Manual Version 7.16
LED
OK
FU
1-16
16
#
2 (each common supplies 8 outputs)
SPST (Single Pole Single Throw, Normally Open)
30 V , 250 V
DC
5 A per common
10 mA @ 5 V
100 mΩ maximum
-20 to +70 °C
-40 to +85 °C
5 to 95 % RH (non-condensing)
Altitude 2000 m max
Maximum working voltage in respect to system earth/ground
must not exceed 250 V
Isolation
Transient voltage: 3 kV
70,000 minimum at 1800 operations per hour at rated load
Enabled when the common is wired to pins 10 and 20.
CAUTION! When wired, a maximum voltage of 30 V AC or DC
can be used to power the common.
Omron G6D-1A 12 V
(G6D datasheet is available from http://components.omron.eu/)
Yes. Module can be swapped while RTU is running. Hot swap will
not cause a Warm Start. Outputs will be restored within 2
seconds once module is replaced.
relative to system earth and/or ground) then both commons must
PEAK
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
State
OFF Module fault (no power)
ON Normal
OFF Fuse OK
ON Fuse fail
OFF Digital output OFF (open)
ON Digital output ON (closed)
#
AC
(wetting current)
DC
/ 130 V
AC DC
DC
Description
