14.4.3 IO-5 Specifications
IO-5 Analogue / Digital Combinational Module Specifications
Operating Temperature
Storage Temperature
Humidity
Output Power
Maximum W orking
Voltage on any contact of
the field connector
Hot Swap
ANALOGUE INPUTS
Input Current Ranges
Input Voltage Ranges *
Inputs per Module
Resolution
Accurac y
(includes Gain, Linearity
and Offset errors)
Update Rate
Cross-Channel Rejection
Input Impedance
Input Filter
Cutoff Frequenc y
AC noise attenuation
Output Field Power
Isolation
Hardware Manual Version 7.16
-40 to +85 °C
-40 to +85 °C
5 to 95 % RH (non-condensing)
24 V / 100 mA max, Isolated
DC
42.4 V / 60 V relative to system (backplane) ground
PEAK DC
Yes. Module can be swapped while RTU is running. Hot swap will
not cause a Warm Start.
4 - 20 mA or 0 - 20 mA
1 - 5 V or 0 - 5 V *
4
Unsigned 12 bit
± 0.25% @ 25 °C
± 0.50% @ -40 to +85 °C
120 ms
> 115 dB from DC to 1 kHz
250 Ω standard
1 MΩ optional *. The internal load resistors can be factory
removed if high impedance voltage inputs are required.
7 Hz @ -3 dB
16 dB @ 50 Hz
18 dB @ 60 Hz
24 V / 80 mA Isolated
DC
5 kV Transient
