TEL REL 003: SPST Relay Board

13.3.1 Overview

• 16 SPST Relay Outputs
• Common for each channel
• 5 kV coil to contact isolation
• Can switch AC or DC voltages
• Higher inductive rating than other TEL REL 002
(1 A @ 125 V as opposed to 0.4 A @ 125 V)
The TEL REL 003 board is designed to be used in conjunction with the DO-6 (or superseded
DO-5) and provides superior inductive load rating than the TEL REL 002.
LED indicators are provided for each relay on the relay board. LED ON = relay active.

13.3.2 TEL REL 003 Specifications

Outputs per Terminal Board
Commons
Relay Type (per channel)
Rated Load (per contact)
Maximum Operating Voltage
Maximum Switching Power -
Resistive
Contact Resistance
Relay Operations
Operating Temperature
Humidity
Isolation
Coil Rated Voltage
Coil Resistance
Dimensions
Mounting
Interface Cable Length
Connection Terminals
Hardware Manual Version 7.16
TEL REL 003 SPST Relay Board Specifications
16
#
16 (1 common per channel)
SPST (Single Pole, Single Throw)
8 A at 250 V Resistive
AC
8 A at 30 V Resistive
DC
1 A at 125 V Inductive
DC
380 V , 125 V
AC DC
2000 VA, 240 W
100 mΩ maximum
100,000 minimum at 1800 operations per hour at rated resistive
load
50,000 minimum at 360 operations per hour at rated inductive load
-20 to +70 °C (no icing)
5 to 95 % RH (non-condensing)
5 kV coil to contacts
12 V @ 66 mA
DC
180 Ω @ 12 V
DC
253 mm(L) x 90 mm(W) x 70 mm(H)
(280 mm long with 2 end clamps)
35 mm DIN rail
1.5 m (for connection to the DO-6 module)
Weidmuller single height PCB 3-way terminal unit (please see
wiring diagram). These terminals can take wire sizes up to 4 mm
