DIGITAL INPUTS
Rated Voltage
Inputs per Module
Input Characteristics
Input Current
Isolation
DIGITAL OUTPUTS
Outputs per Module
Commons
Relay Type
Maximum Switched Voltage
Maximum Switched Current
Isolation
Minimum Load
Contact Resistance
Relay Operations
Relay Part Number
CAUTION! Contacts should be protected with appropriate suppression devices when wired with
inductive loads to increase the service life of relays (please see the
section for more details). Contacts should also be protected with external fusing.
* Analogue inputs can be modified from current inputs to voltage inputs by lifting one pin (or by the
complete removal) of the 250 Ω channel resistor. Each channel has its own resistor, so any
combination of channels can be converted. It is recommended that modules be returned to
Semaphore for factory conversion if required. No responsibility will be taken by Semaphore for
damage caused to boards during modification performed by clients. The circuit board resistors to
change are: R85 and R41 (channels 1 and 2 correspondingly).
Hardware Manual Version 7.16
12 to 24 V (can use reverse polarity)
AC/DC
8
ON-state Voltage
OFF-state Voltage
ON-state Current
OFF-state Current
ON Response Time
OFF Response Time
4 mA (typical) at rated voltage
1000 V between field and logic
RMS
2
1 (common supplies both outputs)
SPST (Single Pole Single Throw)
30 V , 42 V
DC AC
5 A per common
3 kV coil to contacts
10 mA @ 5 V
DC
100 mΩ maximum
70,000 minimum at 1800 operations per hour at rated load
Omron G6D-1A 12 V
DC
(G6D datasheet is available from http://components.omron.eu/)
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
11.5 to 30 V maximum
DC
0 to 4 V
DC
3.2 mA minimum
1 mA maximum
10 ms typical
17 ms typical
