8. IO MODULES OVERVIEW

This chapter contains general overview of and wiring guidelines applicable to IO modules in
the Kingfisher Plus+ range. The types of available IO modules are listed in the table below.
Part Number
AI-1 Analogue Input Module
AI-10 Analogue Input Module (High Performance)
AO-3 Analogue Output Module
DI-5 Digital DC Input Module
DI-10 Digital AC/DC Input Module
DO-1
Digital Relay Output Module (
DO-2 Digital Relay Output Module (
DO-6 Digital Solid State Module
IO-2 Combination Digital I/O Module
IO-3 Combination Analogue/Digital I/O Module
IO-4 Combination Analogue/Digital I/O Module
IO-5 Combination Analogue/Digital I/O Module
IO Modules Field Connector
Each IO module has a removable 20-terminal I/O connector block mounted on the front of
the module for connections from user devices. This allows the IO module to be swapped
without having to detach the field wiring from the I/O connector. The I/O connector is
secured to the module using two fastening screws as shown on the picture below.
Hardware Manual Version 7.16
Description of Module
ANALOGUE MODULES
DIGITAL MODULES
NO/NC)
NO
)
COMBINATIONAL I/O MODULES
http://www.servelec-semaphore.com/
Kingfisher Plus+ Hardware Manual
Commons per
I/O Points
8
8
4
16
16
8
16
16
16
13
12
13
Module
1
1
4
1
1
4
2
2
2
4
3
4
