Installing the Server

These topics describe how to install the server into a rack using the rail assembly in the
rackmount kit. Perform these procedures if you purchased the rail assembly.
In this guide, the term rack means either an open rack or a closed cabinet.
Note -
Step Description
1. Install optional components.
2. Ensure that your rack is compatible with the server
requirements.
3. Review the cautions for working with racks.
4. Use anti-tilt mechanisms to ensure that the rack does
not tip when the server is installed.
5. Prepare the slide rails, mounting brackets, and slide rail
assemblies for server installation.
6. Install the server in the rack.
7. (Optional) Install the CMA.
8. Review cabling requirements and port information.
Attach data and management cables to the server.
9. Prepare to power on the server for the first time.
Related Information
"Preparing for Installation" on page 21
■
"Cabling the Server" on page 51
■
Links
"Optional Components" on page 26
"Rack Compatibility" on page 26
"Rack Cautions" on page 27
"Stabilize the Rack" on page 29
"Install Mounting Brackets Onto the Server" on page 30
"Mark the Rackmount Location" on page 31
"Install AC Power Cables and Slide-Rails" on page 33
"Attach Tool-less Slide-Rail Assemblies" on page 34
"Install the Server Into the Slide-Rail Assemblies" on page 37
"Install the Cable Management Arm" on page 39
"Cabling the Server" on page 51
"Powering On the Server for the First Time" on page 57
Installing the Server 25
