Ensure that the two Velcro straps located on the front slide bar are threaded through
Note -
the opening in the top of the slide bar. This prevents the Velcro straps from interfering with
the expansion and contraction of the slide bar when the server is extended out of the rack and
returned into the rack.
To make it easier to install the CMA, extend the server approximately 13 cm (5
4.
inches) out of the front of the rack.
5. Take the CMA to the back of the equipment rack, and ensure that you have
adequate room to work at the back of the server.
References to "left" or "right" in this procedure assume that you are facing the back of
Note -
the equipment rack.
Throughout this installation procedure, support the CMA and do not allow it to hang
Note -
under its own weight until it is secured at all four attachment points.
Install the CMA's connector A into the left slide rail.
6.
Insert the CMA's connector A into the front slot on the left slide-rail until it
a.
locks into place with an audible click (frames 1 and 2).
The connector A tab (callout 1) goes into the slide-rail's front slot (callout 2).
