Server Overview - Oracle SPARC S7-2 Installation Manual

Steps Description
9. Connect the power cords to the server, configure the Oracle
ILOM on the SP, power on the server for the first time, and set
up the operating system.
Related Information
SPARC S7-2 Server Product Notes
■
SPARC S7-2 Server Safety and Compliance Guide
■
Servers Administration
■
Server Service
■

Server Overview

This topic provides a high-level introduction to the main components and capabilities of the
server.
Component
Chassis
CPU
Memory
I/O expansion
Storage devices
USB ports
Ethernet ports
Power supplies
Cooling fans
SP
Links
"Powering On the Server for the First Time" on page 57
Description
Rack-mountable server.
One or two processors are supported: 8-core, 4.267GHz, 130W each, installed on the
motherboard assembly.
16 DDR4 DIMM slots are supported:
■ Each processor module supports either 4 or 8 DIMMs for a total of 8 or 16 DIMMs in two
processor systems.
■ Mixing of memory types or sizes is not supported.
Three low profiles x8 PCIe Gen3 slots. All slots support x8 PCIe cards, two slots support x16
PCIe cards mechanically.
For internal storage, the server provides:
■ Eight 2.5-inch drive bays accessible through the front panel, support SFF SAS/SATA
drives with 4 slots NVMe enabled.
■ Internal SAS HBA card.
■ Support for non-RAID LSISAS3008 HBA.
Two external USB 2.0 ports (front panel).
Four 10GbE 100/1000/10000 Mbps, RJ-45-based ports on the rear panel.
Two hot-swappable A266 1.2kW (N+1).
Four hot-swappable, redundant fans at chassis front (top-loading).
Oracle Integrated Lights Out Manager (Oracle ILOM) on motherboard.

Server Overview

Understanding the Server 11
