Injected HCI on the specific UDP port can be viewed in the HCI Overview (Injection) once the
Ellisys Injection API recording is initiated Any user debug messages are displayed in the
Message Log Overview.
To initiate recording of Injected HCI traffic:
1. Select Record | Select an analyzer from the menu or alternatively select the drop-down
arrow located on the Record
The Available analyzers dialog appears:
2. Select Ellisys Injection API.
3. Click on OK.
6.5

Initiating a Recording

A recording can be initiated from the toolbar, keyboard, or the menu.
To initiate a recording:
1. Click on Record
(Ctrl+R) from the menu.
Recording is initiated according to settings in the Record | Recording Options menu.
6.6

Stopping a Recording

A recording can be manually stopped from the toolbar, keyboard, or the menu.
To stop a recording:
1. Click on Stop on the toolbar or alternatively, select Record | Stop Recording
(Ctrl+Shift+R) from the menu.
The recording is stopped. Any traffic remaining in the analyzer's memory is uploaded to the PC
hosting the analyzer application.
Clicking the Stop button a second time cancels the upload of any remaining
traffic still located on the analyzer's memory.
68 of 201 | Capturing Traffic
button located on the toolbar.
on the toolbar or alternatively, select Record | Start Recording
