Adding Details Fields To An Overview - Ellisys Bluetooth Explorer 400 User Manual

17.2 Adding Details Fields to an Overview

To place a Details field into the Overview:
1. Select the event desired in the Overview.
The Details pane repopulates to show details on the event selected.
2. Select the desired field in the Details pane.
3. Select the Show in Overview
or
4. Left-click and drag the desired field from the Details pane and drop in the Overview.
The field from the Details pane is now shown in the Overview.
Adding fields from the Details pane into the Overview is especially powerful
when combined with Instant Filters. This can be done during or after
recording.
186 of 201 | Details Pane
button in the Details toolbar.
