A Keep-Only filter dialog appears as shown below:
2. Select the desired Keep-Only option.
The user may see more than one filter option displayed. To keep only the
selected piconet, select the first option. If the piconet is part of a scatternet,
select the second option to keep only the scatternet.
All displays and panes are updated to remove all but the selected piconet or scatternet traffic.
The Filtering button (on the Tool Bar) updates to show the selected filter:
To clear an Instant Piconet Keep-Only Filter:
1. Select the down-arrow associated with the Filtering button on the Tool Bar.
The Filtering menu appears:
2. Select Exclude Background (this is the default setting).
All displays and panes are updated.
