2. Click on the down-arrow associated with the Protocol: drop-down menu.
3. Select the Single selection feature from the Protocol: drop-down menu:
4. Select the Packets icon.
The Overview updates to show only individual packets.
8.3

Instant Piconet Keep-Only Filter

The Instant Piconet pane provides filtering that enables the user to show/hide selected piconets,
scatternets, paging events, and inquiry events. This filter will update all displays and panes.
For more information on the Instant Piconet pane, see Chapter 12 Instant Piconet Pane.
To set an Instant Piconet Keep-Only Filter:
1. Position the mouse pointer over the desired piconet or scatternet and right-click.
Navigate to a particular piconet event (so that it will be displayed in the Instant
Piconet pane) by selecting an associated event in the Overview (or the Instant
Timing or Security panes) or by using the navigation buttons located at the
bottom-left of the Instant Piconet pane.
