All displays and panes are updated.
8.7

Instant Spectrum Display Filter

The Instant Spectrum view (see Chapter 10, Instant Spectrum View) includes display filters for
show/hide of Establishment Traffic (inquiries, pagings, and advertisements) and show/hide of
Idle Traffic (ID packets, Null, Poll packets or empty packets). These filters are available from
the Display button located on the Instant Spectrum toolbar, below. This filter applies only to
the Instant Spectrum view.
8.8

Instant Spectrum Keep-Only Filter

The Instant Spectrum view provides a convenient Keep-Only filter that allows the user to select
specific communications for display throughout the application, while hiding all other
communications.
To enable the Instant Spectrum Keep-Only filter:
1. Select a packet in the Instant Spectrum view.
2. Right-click and select the Keep Only option, as shown below.
All panes in the application update to show only the selected communications.
To clear the Instant Spectrum Keep-Only filter:
1. Select the down-arrow associated with the Filtering button on the Tool Bar.
The Filtering menu appears:
2. Select Exclude Background.
110 of 201 | Display Filters
