15.3 Proper Entry of Link Key

Entry of a link key into the Security pane may be needed to decrypt traffic, especially for SSP
pairings. This can be done during a capture or after a capture is saved. Different methods for
proper entry of a link key are discussed below.
To enter a link key in hex (lowest order byte on left):
1. Specify each byte of the Link Key in hex, starting with the lowest order byte on the left. In
this case DO NOT use ":" as a separator and use either "0x" for every byte, or do not use it
at all, as shown below:
0x01 0x02 0x03 0x04 0x05 0x06 0x07 0x08 0x09 0x0A 0x0B 0x0C 0x0D 0x0E 0x0F 0x10
To enter a link key in hex (highest order byte on left):
1. Specify the Link Key as a big hex number, with highest order byte on the left. Use ":" as a
separator and/or specify a single "0x" at the beginning, as shown below:
DO NOT enter a link key like this:

15.4 Synchronization to Overviews

Each displayed security event is linked to the pertinent Overview by a timestamp column,
includes an indication of the applicable master/slave connection, shows the calculated (or
provided) link key, the PIN code (as applicable), and the authenticated ciphering offset (ACO).
To synchronize the Overview to a security event:
1. Left-click on the timestamp associated with any security event shown in the Security pane.
2. The Overview jumps to the location of the selected timestamp.

15.5 Indicators and Icons

Various background colors are used to provide the user with an at-a-glance understanding of
each security event.
01 02 03 04 05 06 07 08 09 0A 0B 0C 0D 0E 0F 10
0x100F0E0D:0C0B0A09:08070605:04030201
100F0E0D:0C0B0A09:08070605:04030201
0x100F0E0D0C0B0A090807060504030201
01020304:05060708:090A0B0C:0D0E0F10
