Ellisys Bluetooth Explorer 400 User Manual page 162

Timestamp End
Span
Options
To view per-channel statistics:
1. Place the mouse over the histogram associated with the desired channel.
A statistical summary of the selected channel appears:
To use the Navigator bar to pan:
1. Position the mouse over the middle of the Navigator window. The Navigator window will
reflect the entire contents
2. Press and hold the left mouse button, and drag left or right as desired to pan left or right.
To use the Navigator bar to zoom:
1. Position the mouse over the left or right edge of Navigator window:
2. Press and hold the left mouse button, and drag left or right as desired to zoom in or out.
162 of 201 | Instant Channels
Tracks Navigator selection and can also be used
to manually enter a timestamp end.
Tracks Navigator selection and can also be used
to manually enter a display span.
Enables and disables display options.
