To use the Instant Piconet cursor:
1. Right click in the Instant Timing pane and select Place Instant Piconet Cursor here, or
alternatively double-click over any packet in the Instant Timing pane.
The Instant Piconet cursor appears:
2. Select and drag the Instant Piconet cursor while observing the Instant Piconet pane.
The Instant Piconet pane updates according to the position of the Instant Piconet cursor.
Ensure the Follow in Real Time button
selected (not bordered) in order to use the Instant Piconet cursor.

9.12 Exporting Images

The Instant Timing display can be exported into various graphics formats.
To export the Instant Timing display to a graphics format:
1. Click on the Export Image icon located on the Instant Timing toolbar.
in the Instant Piconet pane is not
Instant Timing Pane | 129 of 201
