The left area of the Raw Data pane is searched. Strings found are highlighted in blue in the left
and right areas.

18.3 Formatting the Raw Data Pane

To format the Raw Data pane display:
1. Right-click in the left or right areas in the Raw Data pane.
2. Set display options as per the table below:
Addresses Sets left-border addressing to hex or decimal.
Width Sets horizontal length of data displayed.
Group by Groups data in byte, word, long, or quad formats.
Left Area Formats the left area in character, hex, binary, decimal, or octal.
Right Area Formats the right area in character, hex, binary, decimal, or octal.
Text Size Sets text size to small, medium, or large.
To copy data from the Raw Data pane:
1. Right-click in the left or right areas in the Raw Data pane.
2. Select Edit.
3. Select Copy as Displayed (Ctrl+C) to copy data in the format presently displayed.
or
4. Select Copy as Binary Data (Ctrl+Shift+C) to copy data in a binary data format.
or
Select Copy as Generator Hex Array to copy in a format used by the USB Explorer 280
Generator. Note: This feature not yet implemented.
Copy actions will copy all data from the left area of the Raw Data pane, unless a
mouse selection is made over specific data, in which case only the selected data
is copied.
