Pointer Mode
Pan Mode (Hold Shift)
Zoom Mode (Hold Ctrl)
Enable/Disable Smooth Scrolling
Highlighting Options
Highlight Active Overview
Selection
Highlight Bluetooth BR/EDR
Overview Selection
Highlight Bluetooth Low
Energy Overview Selection
Follow Overview Selection
Origin Box
Span Box
Scale
MHz
BR/EDR Channels
Low Energy Channels
802.11 Channels
Higher Frequency on Top
Display
Show Establishment Traffic
Show Idle Traffic
Export Image
Switches to Pointer Mode.
Switches to Pan Mode.
Switches to Zoom Mode.
Enables and disables the smooth scrolling
feature.
When enabled, the Instant Timing pane will be
synchronized to the active Overview selection.
When enabled, the item selected in the BR/EDR
Overview is highlighted in the Instant Timing
pane.
When enabled, the item selected in the Low
Energy Overview is highlighted in the Instant
Timing pane.
When enabled, the Instant Timing pane is
synchronized to the active Overview selection.
Displays the timestamp origin of the Instant
Timing pane. Allows for user input of
timestamp for jumping.
Displays the time span (zoom level) of the
Instant Timing pane. Allows for user input to
adjust span.
Display a scale showing the Bluetooth spectrum
in MHz.
Display a scale showing the Bluetooth spectrum
by Bluetooth channels.
Display a scale showing the placement of Low
Energy channels.
Display a scale showing the placement of
802.11 channels.
Reverses the scaling to show highest
frequencies at the top of the scales.
Shows/hides inquiries, pagings, and
advertisements.
Shows/hides ID, Null, Polling and empty
packets.
Exports the Instant Timing pane to an image
file.
