3.2

Main Toolbar

The table below shows the Bluetooth Explorer 400 Analyzer toolbar buttons and their actions:
New
Open
Save
Save Filtered
Search
Start Recording
Stop Recording
Restart
Set Time Reference
Reset Time Reference
Navigate Backward
Navigate Forward
Markers
Find Previous Marker
Find Next Marker
Filtering
Save & Continue
User Manual
24 of 201 | User Interface Reference
Creates a new empty capture file.
Opens a previously saved capture file.
Saves a capture file.
Saves a filtered capture file (by selected devices).
Opens the Search dialog.
Starts a recording on the selected analyzer.
Stops the current recording.
Aborts current recording and restarts a new one.
Sets the line selected in an Overview at 0.000 000 000
Resets the time reference to its original value.
Navigate to the previous selection history.
Navigate to the next selection history.
Opens the Markers menu.
Jumps to previous marker.
Jumps to next marker.
Opens the Device Traffic Filters menu.
Saves the current capture and starts the next.
Opens the User Manual.
