Navigation Bar
9.3

Panning Left and Right

Various methods are available to pan (scroll) the Instant Timing pane to the left or right,
including use of the mouse, the keyboard, and the Navigator bar.
To use the mouse to pan:
1. Position the mouse over the time scale at the bottom of the Instant Timing pane
(recommended) or alternatively, click on Pan
The pointer changes to a pan (hand) symbol.
2. Press and hold the left mouse button, and drag left or right as desired.
The mouse cursor automatically rolls around the screen, such that the user can
smoothly scroll large amounts of time without having to press and release the
mouse button several times.
To use the keyboard to pan:
1. Press LEFT or RIGHT Arrow to move incrementally left or right.
To use the Navigator bar to pan:
1. Position the mouse over the middle of the Navigator window, as shown below.
2. Press and hold the left mouse button, and drag left or right as desired to pan left or right.
To jump to another location:
1. Press HOME to jump to the start of the capture, or END to jump to the end of the capture.
Global overview allowing for pan, zoom, and
jump.
.
Instant Timing Pane | 115 of 201
