3. Click on OK.
If a recording is initiated without having first selected an Analyzer, the
will pop up to request the user to select an Analyzer. Selecting the default checkbox in this
dialog will conveniently force the automatic selection of the specified Analyzer on each new
recording.

10.3 Initiating a Recording

A recording can be initiated from the toolbar, keyboard, or the menu.
To initiate a recording:
1. Click on Record on the toolbar.
Or
Select Record | Start Recording (CTRL+R) from the menu.
Recording is initiated according to settings in the Record | Recording Options menu.

10.4 Stopping a Recording

A recording can be manually stopped from the toolbar, keyboard, or the menu.
automatically based on settings made in the Recording Options | Trigger menu.
To stop a recording:
1. Click on Stop on the toolbar.
Or
Select Record | Stop Recording (CTRL+SHFT+R) from the menu.
The recording is stopped. Traffic remaining in the Analyzer's memory is uploaded to the PC hosting the Analyzer
application.

10.5 Restarting a Recording

A recording in progress can be restarted from the toolbar or from the Record menu. When restarting a recording, a
dialog will give the user the option to save or discard traffic presently captured in the Analyzer's memory.
To restart a recording:
1. Click on Restart on the toolbar.
Or
Select Record | Restart Recording from the menu.
The capture in progress is halted, traffic captured is discarded, and a new recording is initiated.
Available Analyzers
Recording may also stop
Managing Analyzer Recordings
dialog
| 91 of 157
