Page 1 OPERATOR'S MANUAL ELECTRONIC CHART DISPLAY AND INFORMATION SYSTEM (ECDIS) FMD-3200 FMD-3200-BB FMD-3300 Model www.furuno.com...
Page 2 ・FURUNO Authorized Distributor/Dealer 9-52 Ashihara-cho, Nishinomiya, 662-8580, JAPAN A : APR 2012 Printed in Japan All rights reserved. H1 : MAR . 01, 2017 Pub. No. OME-44730-H1 ( GREG ) FMD-3200/3200BB/3300 0 0 0 1 7 6 1 2 5 1 7...
Page 3: Important Notices
How to discard a used battery Some FURUNO products have a battery(ies). To see if your product has a battery, see the chapter on Maintenance. Follow the instructions below if a battery is used. Tape the + and - terminals of bat- tery before disposal to prevent fire, heat generation caused by short circuit.
Page 4 Do not place liquid filled containers Unit. Do not remove any label. If a label is on the top of the equipment. missing or damaged, contact a FURUNO agent or dealer about replacement. Fire or electrical shock can result if a Name: Warning Label (1) liquid spills into the equipment.
Page 5: Table Of Contents
TABLE OF CONTENTS FOREWORD ......................... xiii SYSTEM CONFIGURATION ..................xvi INTRODUCTION ....................1-1 1.1 System Configuration ....................1-1 1.2 Processor Unit EC-3000.....................1-1 1.3 How to Turn the Power On/Off ...................1-2 1.4 The Silent Mode ......................1-2 1.5 ECDIS Control Unit RCU-024..................1-3 1.5.1 Control description ..................1-3 1.5.2 Operator fitness ....................1-4 1.6 Trackball Control Unit RCU-026 .................1-5...
Page 6 TABLE OF CONTENTS 2.1.12 Context-sensitive menus................2-15 2.1.13 How to enter alphanumeric data ..............2-16 2.2 How to Select the Display Mode ................2-18 2.3 How to Select the ECDIS Operating Mode .............. 2-18 2.4 How to Select the Chart Scale ................. 2-19 2.5 How to Select the Presentation Mode..............
Page 7 TABLE OF CONTENTS 3.15.2 How to view status of chart cells ..............3-23 3.16 How to Open Charts ....................3-24 3.17 How to Print Chart List, Cell Status List..............3-24 3.17.1 How to print the chart list ................3-24 3.17.2 How to print the cell status list ..............3-25 3.18 How to Delete Charts ....................3-26 3.19 How to Show Publishers Notes for ENC Charts............3-27 3.20 How to Find the Chart Type..................3-28...
Page 8 TABLE OF CONTENTS RASTER (ARCS) CHARTS ...................6-1 6.1 ARCS Charts......................6-1 6.1.1 Chart legend of ARCS chart................6-1 6.2 Datum and ARCS Charts ................... 6-5 6.3 Permanent Warnings of ARCS .................. 6-5 6.4 ARCS Subscriptions....................6-6 6.4.1 ARCS Navigator..................... 6-6 6.4.2 ARCS license information ................
Page 9 TABLE OF CONTENTS 9.10.2 How to export route data in FEA-2x07, RTZ, CSV, ASCII format ....9-22 9.11 How to Delete Routes....................9-22 9.12 Route Transfer Feature ....................9-23 9.12.1 How to turn route transfer on/off..............9-23 9.12.2 How to send and receive monitored routes ..........9-24 9.12.3 How to send and receive planned routes .............9-25 9.13 Reports ........................9-26 10.
Page 10 TABLE OF CONTENTS 12.2.7 How to adjust PI line length................12-4 12.3 Look-ahead ......................12-5 12.4 Ring.......................... 12-5 12.5 Predictor........................12-7 12.6 Anchor Watch......................12-8 12.7 UKC (Under Keel Clearance)................... 12-9 12.7.1 UKC overview ....................12-9 12.7.2 How to set UKC..................12-10 12.7.3 UKC window....................
Page 11 TABLE OF CONTENTS 15.2.2 How to delete received Navtex messages ...........15-5 16. RADAR OVERLAY ....................16-1 16.1 Introduction.......................16-1 16.2 How to Setup the Radar Overlay................16-2 16.3 How to Adjust the Radar Signal Fed From the Radar Connection Box....16-3 16.4 Error Between Radar Echo Image and Chart............16-7 16.5 Error Sources for Radar Echo Image and TT Mismatch ..........16-8 17.
Page 12 TABLE OF CONTENTS 20.4 How to Acknowledge an Alarm or Warning.............. 20-5 20.5 Alert List ........................20-6 20.6 Alert Log........................20-7 20.7 Alert Reception from Connected Sensors..............20-8 20.8 List of Alerts ......................20-9 21. PARAMETERS.....................21-1 21.1 Ship and Route Parameters..................21-1 21.2 Forwarding Distances ....................
Page 13 TABLE OF CONTENTS 25.9 How to Temporarily Silence the Buzzer ..............25-9 25.10Buzzer Patterns .......................25-9 25.11Alert Priority, Alert State ..................25-10 25.12Aggregated Alert ....................25-11 25.13Responsibility Transfer Alert ..................25-12 25.14Backup Configuration ....................25-13 25.15Alert and Alert-related Icons ..................25-15 25.16AMS Mode Operations ..................25-16 25.16.1How to select the AMS mode ..............25-16 25.16.2AMS mode windows ...................25-16 26.
Page 14 TABLE OF CONTENTS APPENDIX 5 ALERT LIST..................AP-35 SPECIFICATIONS .....................SP-1 INDEX.......................... IN-1...
Page 15: Foreword
• Continuous monitoring of ship’s position through multi-sensor Kalman filter processing using GPS, DGPS, SDME. • Route planning and route monitoring facilities. • Radar image can be overlaid on electronic charts. (Requires a FURUNO FAR-2xx7, FAR-3xx0 or FCR-2xx9 radar.) • Grounding warnings, safe depth contours.
Page 16 GPL or LGPL as published by the Free Software Foundation. Please access to the following URL if you need source codes: https://www.furuno.co.jp/cgi/cnt_oss_e01.cgi. This product uses the software module that was developed by the Independent JPEG Group.
Page 17 FOREWORD Reverse engineering Reverse engineering (reverse assemble, reverse compiler) of the software of this equipment is strictly prohibited.
Page 18: System Configuration
1ø, 50/60 Hz *: MU-190: Standard supply for FMD-3200 MU-231: Standard supply for FMD-3300 MU-270W: Standard supply for FMD-3300 HD26T21-MMD-MA4-FAGA: Standard supply for FMD-3300 The following monitors are available for use with the FMD-3200 BB. Viewing Viewing Maker Model distance...
Page 19 *: MU-190: Standard supply for FMD-3200 MU-231: Standard supply for FMD-3300 MU-270W: Standard supply for FMD-3300 HD26T21-MMD-MA4-FAGA: Standard supply for FMD-3300 The following monitors are available for use with the FMD-3200 BB. Viewing Viewing Maker Model distance Maker...
Page 20 SYSTEM CONFIGURATION This page is intentionally left blank. xviii...
Page 21: Introduction
INTRODUCTION System Configuration This ECDIS series is comprised of the components shown in the illustration on the System Configuration page. The Processor Unit is connected to various sensors, and performs navigation calcu- lations, route planning and route monitoring. The Sensor Adapters interface between the Processor Unit and external equipment.
Page 22: How To Turn The Power On/Off
1. INTRODUCTION How to Turn the Power On/Off Normally, leave the power switches at the front of the Processor Unit on and control the power with the power key on a Control Unit (RCU-024, RCU-026). The Monitor Unit is powered independently. How to power the system Push the Mains switch on the Processor Unit for the "I"...
Page 23: Ecdis Control Unit Rcu-024
1. INTRODUCTION ECDIS Control Unit RCU-024 The RCU-024 consists of controls, keys, alphabet keyboard and trackball module (trackball, scrollwheel and left and right mouse buttons). The trackball module func- tions like a PC mouse. The operator rolls the trackball and operates the left and right mouse buttons and the scrollwheel to do various functions.
Page 24: Operator Fitness
1. INTRODUCTION Description ALARM ACK Alert acknowledgement for alerts generated by chart, navigation, etc. InstantAccess knob Selects and processes the functions on the InstantAccess bar™. ESC key Rotate: Selects item. Push: Confirms selection. ESC key: Goes back one step in the current operating sequence on the InstantAccess bar™.
Page 25: Trackball Control Unit Rcu-026
1. INTRODUCTION Trackball Control Unit RCU-026 The RCU-026 has a power key, a trackball module (trackball, scrollwheel and left and right mouse buttons), a status LED, and a USB port. The trackball module functions like a PC mouse; the user rolls the trackball and operates the left and right buttons and the scrollwheel to do various functions.
Page 26: How To Select A Color Palette
1. INTRODUCTION How to Select a Color Palette The system provides three sets of color and brilliance sets (palette), day, dusk and night, to match any ambient lighting condition. The default specifications of each set are as shown in the table below. The panel dimmer setting is automatically changed, and the number of steps depends on the color palette selected.
Page 27: How To Adjust The Display Brilliance, Control Unit Backlighting
1. INTRODUCTION How to Adjust the Display Brilliance, Control Unit Backlighting The monitor brilliance setting is defined according to the color palette setting. Howev- er, manual adjustment of the brilliance is also possible. The backlighting for the control unit can be adjusted from the monitor brilliance adjust- ment window.
Page 28: Control Unit Backlighting
1. INTRODUCTION Manual brilliance adjustment with the trackball module 1. Click the [BRILL] button on the InstantAccess bar™ to show the brilliance adjust- ment window. 2. For coarse adjustment, put the cursor on a location within the slider bar area then push the left button.
Page 29: How To Select Sensor Settings
1. INTRODUCTION How to Select Sensor Settings This ECDIS system accepts navigation data input two ways: System or Local. System shares sensor data among multiple ECDIS in network. Sensor priority is also com- monly shared among the ECDIS. Local selects a sensor outside the network. 1.
Page 30: How To Enter Ship Speed
The speed can be entered from a log (STW) or GPS (SOG), or manually on the menu. Note that FURUNO GPS Navigator GP-150 provides both COG and SOG. 1. Right-click anywhere in the [Own ship information] box to show the context-sensi- tive menu.
Page 31 1. INTRODUCTION Check for automatic speed input Speed sensor list Stabilization mode LOG/GPS selection Check for manual speed input SPD page, system sensor 5. For automatic input, follow the procedure below. For manual input, go to step 1) Check [Sensors]. 2) Set the priority for the speed sensors in case of Local sensor.
Page 32: How To Enter Heading
1. INTRODUCTION 1.11 How to Enter Heading Heading can be entered manually or automatically. Note: When the vessel is in high latitudes (over 85°), data from the gyrocompass is not used. The internal filter data is used for heading calculation. In this case, the head- ing source in the sensor information box appears as "FILT".
Page 33: How To Mark Mob Position
1. INTRODUCTION 5. For automatic input follow the procedure below. For manual input, go to step 6. 1) Check [Sensors]. 2) For local system settings, set the priority for each sensor connected, referring to section 1.10. 3) Go to step 7. Note: For the local sensor, an offset can be applied to the gyro reading if it is wrong.
Page 34: How To Select Time Format, Set Local Time
1. INTRODUCTION 1.13 How to Select Time Format, Set Local Time The time indication on the Status bar shows either UTC time and date, or on-board time and date, and cannot be adjusted. On-board time display requires synchroniza- tion with the on-board clock. For further details, consult your local dealer. You can switch between the local time and the UTC time by left-clicking the Current time format indication (requires synchronization with local time, consult your local dealer for details).
Page 35: The Settings Menu
1. INTRODUCTION 1.15 The Settings Menu The [Settings] button gives you access to the user profiles and the [Settings] menu. The [Settings] menu has facilities for screenshot management, file management, di- agnostic tests and customizing. See chapter 23. [Settings] button 1.16 How to Manage User Profiles Ten sets of [Chart Display], [Symbol Display] and [Chart Alert] menu settings can be...
Page 36: How To Erase The Settings For A Profile
1. INTRODUCTION 1.16.4 How to erase the settings for a profile 1. Click [ ] on the Status bar then click [Manage Profile]. 2. Select a profile number from the “Profile” drop-down list. 3. Click [Clear Profile]. The confirmation message "This profile will be cleared. Do you wish to continue?" appears.
Page 37 1. INTRODUCTION Item Settings Tracking page CCRP Checked Primary Checked Secondary Checked Pivot Checked Length 720 min Labels 30 min Mariner page Labels Checked Lines Checked Clearing Lines Checked Tidals Checked Areas Checked Circles Checked [Chart Alert] menu Chart Alert page Safety Contour Keeps previous setting Safety Depth...
Page 38: How To View System Information, Operator's Manual
1. INTRODUCTION 1.17 How to View System Information, Operator's Manual You can show the system information and the operator's manual. Click the [?] button on the Status bar, then click the [Manual] or [About] button. [Manual] shows the Operator’s Manual. [About] shows the system information, prepared in four tabs.
Page 39: Split Screen
1. INTRODUCTION 1.18 Split Screen You can split the screen in two, horizontally or vertically, in the Voyage navigation mode. 1.18.1 How to activate, deactivate the split screen To activate the split screen or return to the full screen, click the [DISP] and [TWO DISP] buttons on the InstantAccess bar™...
Page 40: Function Availability
1. INTRODUCTION 1.18.2 Function availability Viewable Operable Item Main Main AIS target Anchor watch Chart display Danger highlight Divider EBL, VRM Parallel index lines Radar overlay Range rings Weather overlay 1.18.3 Split screen usage characteristics • If the sub view is not displayed correctly, restore the full screen display then try to activate the split screen again.
Page 41: Tips
1. INTRODUCTION 1.19 Tips This ECDIS provides operational tips for the display area and the InstantAccess bar™. To get a tip, simply put the cursor on an object. The tip appears to the right of the ob- ject. For example, put the cursor on the [BRILL] button on the InstantAccess bar™. The tip "Adjust brilliance"...
Page 42 1. INTRODUCTION This page is intentionally left blank. 1-22...
Page 43: Operational Overview
OPERATIONAL OVERVIEW ECDIS Display The ECDIS (Electronic Chart Display and Information Systems) screen is divided into several areas, as illustrated below. (The layout may be slightly different depending on your monitor’s resolution.) The ECDIS operational area has no limitations. That is, high latitudes (85°...
Page 44: Electronic Chart Area
2. OPERATIONAL OVERVIEW 2.1.1 Electronic chart area The ECDIS can use the following types of charts: • S-57 (IHO) • S-63 (IHO) (S-63 encrypted) • ARCS (UKHO) • C-MAP The following information can also be displayed: • Cursor (moved by trackball) •...
Page 45 "Non-ENC" charts in this manual. Note: Some eToken dongles from the FEA-2xx7 can be used with this system. These are labeled "JeT FURUNO XXXXX". Contact your dealer for details. This ECDIS accepts the following C-MAP chart types: ENC SERVICE, PROFES- SIONAL+ and ENC+ SERVICE.
Page 46 2. OPERATIONAL OVERVIEW ARCS raster format ARCS charts are digital reproductions of British Admiralty (BA) paper charts. They re- tain the same standards of accuracy, reliability and clarity as paper charts. Zooming into the ARCS chart can be useful for magnifying a complex detail, however this decreases the density of the data displayed, and can give a false impression of the distance from danger.
Page 47: Status Bar
2. OPERATIONAL OVERVIEW 2.1.2 Status bar The Status bar runs across the top of the ECDIS display. The bar mainly provides for selection of display mode, ECDIS operating mode, chart type and chart display set- ting. Button or item Description Display mode Selects the display mode, [ECDIS], [RADAR], [CONNING], or [AMS].
Page 48 2. OPERATIONAL OVERVIEW How to operate the buttons on the Status bar There are two types of buttons on the Status bar: Toggle button and Drop-down list button. You operate the buttons with the trackball module. Button type Operating procedure Toggle button A toggle button alternately selects one of two functions assigned to a button.
Page 49: Instantaccess Bar
2. OPERATIONAL OVERVIEW ™ 2.1.3 InstantAccess bar ™ The InstantAccess bar runs vertically along the left edge of the screen. The bar con- tains all the operating functions related to the selected ECDIS operating mode (Voy- age planning, Voyage navigation and Chart maintenance). The bar is divided into two sections, upper and lower.
Page 50 2. OPERATIONAL OVERVIEW Button Description Voyage navigation mode bar  ™ Minimizes the InstantAccess bar To restore the maximized bar, click anywhere on the Click minimized bar. arrow Click anywhere on the minimized Voyage Route selects/deselects routes, and moves route to Voyage planning mode (for editing).
Page 51 2. OPERATIONAL OVERVIEW Button Description Guide Box Shows or hides the guide box, which provides range and bearing measurement between waypoints when creating a route. Note: The distance between waypoints can be calculated by the [Rhumbline] or [Great Circle] method. Open the [NAV Tools] menu, select [Geometry], then se- lect desired method.
Page 52: Sensor Information Box
2. OPERATIONAL OVERVIEW ™ How to operate the buttons on the InstantAccess bar ™ The InstantAccess bar has four types of buttons: toggle button, drop-down list but- ton, slider bar button, and specialty button. (The MOB, Capture and Undo buttons are specialty buttons that provide a single-action function.) The buttons can be operated with the trackball module or the InstantAccess knob.
Page 53 2. OPERATIONAL OVERVIEW Color of nav data indications and sensor name The color of the nav data indications and sensor name change according to the state of the sensor data. The table shown below provides basic information. For detailed in- formation, see Appendix 4.
Page 54: Own Ship Functions Box
2. OPERATIONAL OVERVIEW 2.1.5 Own ship functions box The own ship functions box shows information about own ship, enables offset, and does TM reset. Offset button ENC info WGS84 button appears here. RNC info appears here. TM/CU status • [Offset] button: See section 18.8.1. This button is only operative in the Voyage navi- gation mode.
Page 55: Route Information Box
2. OPERATIONAL OVERVIEW 2.1.6 Route information box Asterisks appear in data locations when no route is selected for navigation. Minimize button • Route: Name of monitored route • Plan Speed: Planned speed to approach "To WPT". • Plan Course: Planned course between previ- ous WPT and "To WPT".
Page 56: Overlay/Nav Tools Box
2. OPERATIONAL OVERVIEW 2.1.7 Overlay/NAV Tools box The [Overlay/NAV Tools] box sets up Minimize button Page name the following objects and consists of the following pages. • TT•AIS Page • Echo selection • Parallel index lines buttons • Range rings •...
Page 57: North Mark
2. OPERATIONAL OVERVIEW 2.1.11 North mark The north mark appears at the top left of the Chart for Radar display, is North always visible, and points in the northerly direction. At high latitudes where north is not in a set direction, the north mark appears with the text "at own ship"...
Page 58: How To Enter Alphanumeric Data
2. OPERATIONAL OVERVIEW Mode and availability Item Functions NAVI CHART PLAN Electronic chart area Own ship mark (or cursor posi- tion) to screen center; pick report; chart legend; manual update*; di- vider, hide MOB, message dialog box, weather info**, chart UP*** *NAVI mode only.
Page 59 2. OPERATIONAL OVERVIEW ™ 1. On the InstantAccess bar , press the [DISP], [ ] and [ON] buttons to show the software keyboard. The [BS], [Enter], [], [],[ ], [] and [Spacebar] on the key- board function the same as those keys on the keyboard of the Control Unit. Space bar 2.
Page 60: How To Select The Display Mode
2. OPERATIONAL OVERVIEW How to Select the Display Mode Click the Display mode button at the far left side of the Status bar to select the display mode, among [ECDIS], [RADAR], [CONNING] and [AMS] (option). [ECDIS]: Displays electronic charts. [RADAR]: Shows the radar display. (See the radar manual, issued separately.) [CONNING]: Provides comprehensive navigation displays, like wind direction and rud- der angle, in analog and digital formats.
Page 61: How To Select The Chart Scale
2. OPERATIONAL OVERVIEW How to Select the Chart Scale When you open a chart it is displayed with the default scale, called the compilation scale. To change the chart scale, do one of the procedures shown below. The scale range is 1:1,000 to 1:70,000,000. •...
Page 62: How To Select The Presentation Mode
2. OPERATIONAL OVERVIEW How to Select the Presentation Mode There are seven presentation modes available. However, depending on whether voy- age navigation mode or voyage planning mode is active, some presentations modes are not available. Voyage Voyage Presentation navigation planning Mode mode mode...
Page 63: Cursor Position Box
2. OPERATIONAL OVERVIEW Cursor Position Box The Cursor position box shows • Cursor position in latitude and longitude • Time to go to the cursor position • The bearing (True or Relative) and range to the cursor position, or x-y coordinates of cursor position.
Page 64: True Motion Reset
2. OPERATIONAL OVERVIEW True Motion Reset In the true motion mode, the chart is stationary and own ship moves on the screen. With TM reset active, own ship moves until it reaches the true motion reset border- line(s), then the chart is redrawn and own ship jumps back to an opposite position on screen based on its course.
Page 65: How To Control Route And User Charts In Voyage Navigation And Voyage Planning Modes
2. OPERATIONAL OVERVIEW How to Control Route and User Charts in Voyage Navigation and Voyage Planning Modes Click for Voyage navigation mode Click for Voyage planning mode Functions in Voyage navigation mode Functions in Voyage planning mode Click the appropriate chart mode button [PLAN] or [NAVI] at the top of the display to go to respective mode.
Page 66: How To Use The Vrm And Ebl
2. OPERATIONAL OVERVIEW How to Use the VRM and EBL The VRM measures the range to an object and the EBL measures the bearing to an object. There are two each of VRMs and EBLs. The lengths of the dashes on the EBL2 and VRM2 are longer than those of the EBL1 and VRM1 to distinguish them.
Page 67: Ebl, Vrm Functions Available With The Context-Sensitive Menu
2. OPERATIONAL OVERVIEW 2.9.4 EBL, VRM functions available with the context-sensitive menu The EBLs and VRMs have additional functions that are accessed from the context- sensitive menu. Right-click any VRM or EBL box to show the context-sensitive menu. Function Description Centered Centers the origin of the EBL and VRM on the current position.
Page 68: Datum
2. OPERATIONAL OVERVIEW 2.9.5 How to select range calculation method The range calculation method for the EBL and VRM can be selected to Rhumbline or Great Circle. Do as follows to select a calculation method. 1. Open the menu, then select [NAV Tools] and [Geometry] to show the [Geometry] page.
Page 69: Positioning Devices And Datum
2. OPERATIONAL OVERVIEW 2.10.4 Positioning devices and datum In early days of electronic positioning devices, datum received little attention because the commonly used systems utilized special charts (like Decca charts). Later on, data output was added to these systems, but still no attention was paid to datum and the position errors were considered as an inaccuracy of the system.
Page 70: Create Or Update A Route
2. OPERATIONAL OVERVIEW 2.11.2 Create or update a route Create a new route or modify an existing one. See chapter 9. Check your route against chart alerts Before you sail your route, you should always check your route against chart alerts. This is important because your S57 charts and manual updates may contain chart viewing dates information.
Page 71 2. OPERATIONAL OVERVIEW  Name of the Notes to be used during route monitoring together with this planned route, on the [User Chart] dialog box. Recalculate timetable and ETA values Timetable and ETA values can be recalculated from the [Optimize] page in the [Route Plan] dialog box.
Page 72: How To Check And Prepare The Route, User Chart To Monitor
2. OPERATIONAL OVERVIEW 2.11.3 How to check and prepare the route, user chart to monitor Select the route to monitor, view linked user charts Select a route for the voyage: In the Voyage navigation mode, click the [Voyage], [Route] and [Select] buttons, or right-click the route indication in the [Route Informa- tion] box (right edge of screen) then select [Select Route].
Page 73 2. OPERATIONAL OVERVIEW Select confirm conditions of the route plan Check the setting on the [Chart Alert] dialog box; click the [DISP], [SET] and [Chart Alert] buttons to show that dialog box. Select the user chart(s) to monitor A user chart can be monitored without linking it to a route. You can select a user chart two ways.
Page 74: Check Configuration Of Navigation Sensors
2. OPERATIONAL OVERVIEW 2.11.4 Check configuration of navigation sensors You can check the configuration of your navigation sensors in the [System Sensor Settings] page and [Local System Settings] page in the [Sensor] menu. Check speed settings ([SPD] page) Open the menu and click the [SPD] tab in the [System Sensor Settings] page or [Local System Settings] page.
Page 75: How To Reset Odometer And Trip Meter
2. OPERATIONAL OVERVIEW Check position sensors (POSN page) Open the menu and click the [POSN] tab in the [System Sensor Settings] page or [Lo- cal System Settings] page. The [PRIM] and [Second] labels indicate the type of the position sensor. [PRIM] and [Second] indicate sensor status and priority. The indication for the second sensor appears even when only one position-fixing equipment is connected.
Page 76 2. OPERATIONAL OVERVIEW This page is intentionally left blank. 2-34...
Page 77: How To Manage Charts
HOW TO MANAGE CHARTS This chapter mainly shows you how to install the public keys, licenses and charts, manually update chart objects, and synchronize charts. All chart-related operations begin from the Chart maintenance mode, which you access by clicking the [CHARTS] button on the Status bar.
Page 78: How To Install Enc Licenses, Charts
3. HOW TO MANAGE CHARTS 4. Find the .pub file then click the [Open] button. The [Public Key] dialog box reap- pears. 5. Click the [Display Content] button on the [Public Key] dialog box to show the dis- play contents. 6.
Page 79: How To Install Enc Charts
3. HOW TO MANAGE CHARTS 5. Find the license (permit.txt) then click the [OK] button to install the license. The [Licenses] dialog box then shows cell name, date of expiration, data server name and subscription type of the license. 6. Click the [Close] button to finish. Manual installation If you do not have the medium which has your ENC license, you can enter the license number manually.
Page 80 3. HOW TO MANAGE CHARTS 2. Get into the Chart maintenance mode then click the [AUTO Import] button on the ™ InstantAccess bar . A prompt informs you that it may take a while to do the instal- lation and are you sure to continue. Click the [OK] button to continue. A message informs you that the system is searching the medium (in the figure below the me- dium is a DVD) for chart data.
Page 81: How To Install Arcs Licenses, Charts
3. HOW TO MANAGE CHARTS 4. When the installation is Result completed, information about the installation ap- pears in the [Result] win- dow. Click the [Confirm] button to finish. 5. If applicable, set the next sequential medium and repeat steps 2-4 to install the next charts.
Page 82: How To Install Arcs Charts
3. HOW TO MANAGE CHARTS 3. Click the [Import Licenses] button. 4. Find the medium that contains the license then click the [Open] button. 5. Click the [OK] button to install the license. 4937 31 Mar 2015 3249 31 Mar 2015 4937 31 Mar 2015 1473...
Page 83 3. HOW TO MANAGE CHARTS 1. Set the medium that contains the ARCS charts. 2. Get into the Chart maintenance mode then click the [AUTO Import] button on the ™ InstantAccess bar . A prompt informs you that it may take a while to do the instal- lation and are you sure to continue.
Page 84: How To Delete Enc, Arcs Licenses
3. HOW TO MANAGE CHARTS 4. When the installation is completed, information about the installation appears in the [Result] window. Click the [Confirm] button to finish. Result 5. If applicable, set the next sequential medium then repeat steps 2-4 to install the next charts.
Page 85: How To Find Enc Chart Manufacturer Info
3. HOW TO MANAGE CHARTS How to Find ENC Chart Manufacturer Info The ENC chart manufacturer information shows if your installed ENC charts are offi- cial or unofficial. To find this information, use the [Producer Code] button in the [Li- censes] dialog box.
Page 86: How To Install The C-Map Database And Licenses
3. HOW TO MANAGE CHARTS 2. Click the [C-MAP] tab to the show the [Licenses] dialog box for C-MAP. 3. Click the [C-MAP Setup] button. 4. You are asked if you are sure to continue; click the [OK] button to continue and register the eToken.
Page 87 3. HOW TO MANAGE CHARTS To show details during the installation, click the [Show detail] button. 1/100: Installing C-MAP database ‘Professional+’ version 598 2/100: Installing C-MAP database ‘Professional+’ version 598 3/100: Installing C-MAP database ‘Professional+’ version 598 4/100: Installing C-MAP database ‘Professional+’ version 598 5/100: Installing C-MAP database ‘Professional+’...
Page 88 3. HOW TO MANAGE CHARTS 6. Click the [Close] button to finish. 7. Reset the power. Manual installation: 1. Click the [CHARTS] button on the Status bar to go the Chart maintenance mode, ™ then click the [License] button on the InstantAccess bar 2.
Page 89: How To Generate, Order And Apply An Update File
3. HOW TO MANAGE CHARTS 3.6.3 How to generate, order and apply an update file How to generate and order an update file To update the C-MAP chart database, you have to generate an update file, and e-mail the file directly to C-MAP. The update file defines coverage of charts you can display on your chart radar.
Page 90: How To Confirm License Status
3. HOW TO MANAGE CHARTS 3.6.4 How to confirm license status If you cannot display a C-MAP chart, follow the procedure below to check license sta- tus. Database and license should be installed beforehand. 1. Get into the Chart maintenance mode, then click the [License] button on the InstantAccess bar™.
Page 91: How To Enable And Set Up The C-Map Dl
3. HOW TO MANAGE CHARTS 6. Select the USB flash memory, then click the [Save] button to save the order file to the USB flash memory. 7. Send the order file to updates@c-map.com. Within a few minutes you will receive a file that includes the terms for using the chart service and the chart updates.
Page 92: How To Export A List Of Charts
3. HOW TO MANAGE CHARTS • [Confirmation Date] is the date when you receive the confirmation answer for your request via e-mail. • [Confirm before open new chart], if checked, a confirmation window asks for con- firmation before opening charts that require issuing a new license. A chart denied is added to the list of protected charts, so the confirmation request will not be repeated for that chart.
Page 93: How To Show The Enc Permit, Arcs License
3. HOW TO MANAGE CHARTS 3.11 How to Show the ENC Permit, ARCS License 1. Get into the Chart maintenance mode then click the [License] button. 2. Click the [ENC] or [ARCS] tab as applicable. 3. Click the [ENC User Permit] or [ARCS Licenses] button as applicable to show per- mit or license.
Page 94: How To View Permit Expiration Date
3. HOW TO MANAGE CHARTS 3.13 How to View Permit Expiration Date Permits are used to control the right to use chart data in the ECDIS. A permit is con- nected to the edition of a chart. Permits are issued in two different types: •...
Page 95: How To Display Install/Update History
3. HOW TO MANAGE CHARTS 3.14 How to Display Install/Update History ™ You can see a history of chart installations and updates. On the InstantAccess bar click the [Log] and [Update Log] buttons followed by the [ENC], [ARCS] or [C-MAP] button.
Page 96: Catalog Of Chart Cells
3. HOW TO MANAGE CHARTS 3.15 Catalog of Chart Cells A catalog is used to view graphical coverage of the charts stored in your SSD. Avail- able charts are displayed showing their border limits. Note that sometimes the real coverage of the charts may be considerably less than the declared limits of it. To display the catalog, get into the Chart maintenance mode then click the [Manage ™...
Page 97 3. HOW TO MANAGE CHARTS 5) C-MAP Collections A collection is a pre-defined dataset, the contents of which can be defined by zone, individual chart or any of those combinations. Applicable to C-MAP charts also. 6) Official Display official or unofficial charts. 7) Up-to-date Display charts which are or are not up to date.
Page 98: How To Group Chart Cells
3. HOW TO MANAGE CHARTS 3.15.1 How to group chart cells You can define groups of like-format chart cells. This means you can collect related charts, for example, all cells that cover a route from Liverpool to New York or all cells available from a National Hydrographic Office.
Page 99: How To View Status Of Chart Cells
3. HOW TO MANAGE CHARTS 6. Click [Save] then [Close] to finish. How to delete a group of chart cells You can delete group of chart cells as follows: 1. In the Chart maintenance mode, click the [Manage Charts] button on the ™...
Page 100: How To Open Charts
3. HOW TO MANAGE CHARTS 3.16 How to Open Charts In the Chart maintenance mode, click the [Manage Charts] button on the ™ InstantAccess bar to display the dialog box shown below. Select the chart to open then click the [Open Chart] button. 3.17 How to Print Chart List, Cell Status List 3.17.1...
Page 101: How To Print The Cell Status List
3. HOW TO MANAGE CHARTS Description of chart list printout Item Description Ship Name Name of ship IMO Number Ship’s IMO number Call Sign Ship’s call sign MMSI Ship’s MMSI number Printing Date Date list printed Data Location Location of charts; normally “Internal”. Filter Settings of the items in the [Filter] window.
Page 102: How To Delete Charts
3. HOW TO MANAGE CHARTS Description of cell status printout Item Description Ship Name Name of ship IMO Number Ship’s IMO number Call Sign Ship’s call sign MMSI Ship’s MMSI number Printing Date Date list printed Content Full: The report shows the status for all cells listed in the [Cell Status] dialog box.
Page 103: How To Show Publishers Notes For Enc Charts
3. HOW TO MANAGE CHARTS 3.19 How to Show Publishers Notes for ENC Charts You should read the text file associated with each catalog, which you can view when installing a chart from a medium. Click the [Note] button in the [Manage Charts] dialog box.
Page 104: How To Find The Chart Type
3. HOW TO MANAGE CHARTS 3.20 How to Find the Chart Type The electronic chart system can display more than one ENC chart cell at a time. This feature is called multi-cell display. If one ENC chart cell does not cover the whole dis- play, the system opens more ENC chart cells for display, if appropriate cells for the displayed area are available.
Page 105: How To Insert Update Symbols
3. HOW TO MANAGE CHARTS 3.21.1 How to insert update symbols A manual update symbol can be added as shown in the procedure below. Note 1: If the system freezes when updating the drawing type [area], reset the power. Note 2: An update symbol that straddles the international date line cannot be edited. In this case, insert the same symbol on each side of the line.
Page 106: How To Copy Objects From An Official Chart And Insert Them
3. HOW TO MANAGE CHARTS 9. To add textual information to an attribute, select the attribute from the [Attributes] window then add text in the [Edit Attribute’s Value] window. The [Date end] factory default is set to three months from the date of insertion and applies to all chart items.
Page 107: How To Delete (Hide) A Chart Object
3. HOW TO MANAGE CHARTS 3.21.4 How to delete (hide) a chart object You can hide a manually inserted chart object by doing the following: 1. Referring to step 1 and step 2 of section 3.21.1, show the [Manual Update] dialog box.
Page 108: How To Synchronize Chart Data
3. HOW TO MANAGE CHARTS 3.22 How to Synchronize Chart Data This section shows you how to synchronize chart data between FMD-3xx0, FAR-2xx9 and FCR-2xx9 units, so that all units share the same chart data. Synchronization can be done automatically or manually (see section 3.22.2), however all units selected for synchronization must be powered to complete the synchronization.
Page 109: How To Check Synchronization Status
3. HOW TO MANAGE CHARTS 2. To select a unit for synchronization: Put a checkmark next to the unit’s name in the [Not Synchronize with This Unit] window then click the << button. That unit’s name is moved to the [Grouped with This Unit] window. To deselect a unit from synchronization: Put a checkmark next to the unit’s name in the [Grouped with This Unit] window then click the >>...
Page 110: Manual Updates And Synchronization
3. HOW TO MANAGE CHARTS Note 1: In normal operation do not disable synchronization. If you accidentally disable synchronization, try to synchronize by clicking the [Enable Sync] button. If that does not work, reset the power of all units selected for synchronization then click the [Urge Sync] button to synchronize.
Page 111: How To Control Chart Objects
HOW TO CONTROL CHART OB- JECTS This chapter provides the information necessary for controlling chart features. How to Browse Your Charts You can view your charts using different positions and different scales. The basic tools for browsing charts are the RANGE key, chart offcenter, and scroll. RANGE - and RANGE + change the chart scale.
Page 112 4. HOW TO CONTROL CHART OBJECTS MULTI-COLOR presentation Chart zero Shallow contour Safety contour (input value) Safety contour (exisiting in ENC) Deep contour Non-navigable area Navigable area In the multi-color presentation four colors are used for depths. If the value entered as the safety contour does not exist in the electronic chart, the system automatically se- lects the next available deeper depth contour as the safety contour.
Page 113: Basic Setting Menu
4. HOW TO CONTROL CHART OBJECTS 4.2.2 Basic Setting menu To display this menu, click [DISP], [SET] and [Basic Setting] on the InstantAccess ™ Light Popup: Show or hide light sectors information. Light sector center Light sector center [ON] provides light sector information (including length of arc of visibility) when the cursor is put on a light or light sector.
Page 114: Chart Display Menu
4. HOW TO CONTROL CHART OBJECTS 4.2.3 Chart Display menu To access the [Chart Display] menu and its pages, click [DISP], [SET] and [Chart　 ™ DISP] on the InstantAccess bar . then select [General], [Standard], [Other], [Text], or [NtoM] page as appropriate. To access the [Chart Display] menu and its pages, click [DISP], [SET] and [Chart ™...
Page 115: Display Base
4. HOW TO CONTROL CHART OBJECTS Highlight Date Dependent: Put a highlight mark on the chart object which carries a date dependent attri- bute. Highlight mark Highlight INFO, Highlight Document: Put a highlight (date dependent) mark on a chart object that has information or docu- ment attribute.
Page 116: How To Control Visibility Of Symbols, Features
4. HOW TO CONTROL CHART OBJECTS How to Control Visibility of Symbols, Features Control of symbols and features is divided into five pages in the [Symbol Display] menu, which you can access by clicking the [DISP], [SET] and [Symbol DISP] buttons ™...
Page 117: Tracking Page
4. HOW TO CONTROL CHART OBJECTS Velocity Vectors Ship Vectors: Show or hide own ship vector. Target Vectors: Show or hide target vectors. Style: Select the vector style. The [std ECDIS] vector is a speed-referenced vector symbol. [Conventional] is a simplified symbol. Time Increments: Check to show ticks of velocity vector.
Page 118 4. HOW TO CONTROL CHART OBJECTS Events Events marks are based on the [Voyage] log records. User Events: Display event symbols on the chart. User events are recorded by click- ™ ing [Log], [Event Log] and [User Event] on the InstantAccess bar Auto Events: Display automatically entered event symbols, where the system has re- corded an event based on conditions you have set.
Page 119: Route Page
4. HOW TO CONTROL CHART OBJECTS 4.3.3 Route page The [Route] page selects the route parts of the monitored and planned routes to show on the ECDIS. XTD Limit: The distance from the centerline to one side of the nav lane. Safety Margin: The distance from one side of the channel limit to the safety margin distance.
Page 120: Mariner Page
4. HOW TO CONTROL CHART OBJECTS 4.3.4 Mariner page Description Labels: Check to show labels on user charts. Lines: Check to show lines on user charts. Clearing Lines: Check to show clearing lines (for marking dangerous areas) on user charts. Tidals: Check to show tidal symbols and tidal data on user charts.
Page 121: Targets Page
4. HOW TO CONTROL CHART OBJECTS Point Circle Area Line The Navtex page can be opened from the context-sensitive menu. Right-click the MSI mark, then select [NAVTEX MSG]. See section 15.2.1. 4.3.5 Targets page Color: Select color of target (TT and AIS, common) from the list box. AtoN Symbol Color: Select color of target (TT and AIS, common) from the list box.
Page 122: How To Control Predefined Imo Chart Display Settings
4. HOW TO CONTROL CHART OBJECTS How to Control Predefined IMO Chart Display Settings There are three sets of predefined chart display settings that can be used to display charts with certain chart features. The predefined chart display settings are •...
Page 123: Vector (S57) Charts
VECTOR (S57) CHARTS Theoretically a chart can be coded for use on a computer as a vector chart. Vector- coded charts are coded using a variety of techniques. One technique is called S57ed3 and it has been chosen by IMO as the only alternative for SOLAS compliant electronic charts.
Page 124: Definitions Of Terms
5. VECTOR (S57) CHARTS 5.1.1 Definitions of terms Cell A cell is a geographical area containing ENC data and it is the smallest di- vision of ENC data. Each cell has a separate unique name. Hydrographic Offices divide their responsibility area by the cells that they publish. S57 chart A database, standardized as to content, structure and format, is issued for use with this system without any authority of government-authorized Hydro-...
Page 125: Permanent Warnings For S57 Charts
5. VECTOR (S57) CHARTS Edition: Edition number of the chart. Edition Date: Date the edition was published. Update Number: Update number Update Date: Date of update Compilation Scale: The scale of the original paper chart is shown here. Projection: Projection of current chart. Horizontal Datum: Horizontal datum used with current chart.
Page 126: Chart Viewing Dates And Seasonal Features Of The S57 Chart
5. VECTOR (S57) CHARTS Chart Viewing Dates and Seasonal Features of the S57 Chart 5.2.1 Introduction S57 charts contain date-dependent features. Updating in general, including reissues, new editions and updates, creates date dependency. In addition to the obvious date de- pendency, some features of the S57 charts create additional date dependency.
Page 127: About Chart Viewing Date Dependency Of S57 Standard
5. VECTOR (S57) CHARTS 3. Click the date button to show the [Set date] dia- log box. 4. Select the appropriate date from the calendar, then click [OK] to close the [Set date] dialog box and return to the [Viewing Dates] dialog box. 5.
Page 128: How To Highlight Updated Data
5. VECTOR (S57) CHARTS 5.2.4 How to highlight updated data You can highlight updated data by setting a date (or date period) and creating a report. ™ 1. On the InstantAccess bar , click the [Chart INFO] and [Viewing Dates] button. The [Viewing Date] dialog box appears.
Page 129: Symbology Used In S57 Charts
5. VECTOR (S57) CHARTS Symbology Used in S57 Charts You can familiarize yourself with the symbology used by browsing IHO Chart 1, which is included in this system. Note that it behaves as any S57 chart and it follows your selections.
Page 130: How To Find Information For S57 Chart Objects
5. VECTOR (S57) CHARTS How to Find Information for S57 Chart Objects The ability to cursor-pick an object to find additional information about the object is an important function of the system. However, an unprocessed cursor pick, which does not discriminate or interpret and merely dumps on the interface panel all the informa- tion available at that point on the display, will normally result in pages of unsorted and barely intelligible attribute information.
Page 131: Admiralty Information Overlay (Aio)
5. VECTOR (S57) CHARTS Admiralty Information Overlay (AIO) The Admiralty Information Overlay includes all Admiralty Temporary and Preliminary Notices to Mariners (T&P NMs) and provides additional navigationally significant in- formation from UKHO's ENC validation programme. The AIO is displayed as a single layer on top of the basic ENC and is available free of charge as part of the Admiralty S57 Chart Service and within Admiralty Value Added Resellers' services.
Page 132: Catalog Of Aio Cells
5. VECTOR (S57) CHARTS 5.5.3 Catalog of AIO cells A catalog of AIO (NtoM) cells is maintained in the [Manage Charts] dialog box. To show this box, get into the Chart maintenance mode then click the [Manage Charts] ™ button on the InstantAccess bar .
Page 133: How To Find Aio Chart Object Information
5. VECTOR (S57) CHARTS 5.5.4 How to find AIO chart object information Do the following to find chart object information contained in the AIO. 1. Right click a red hatched area in the chart area, then select [Pick Report] to show the [Select Object] dialog box.
Page 134: How To Select The Information To Display
5. VECTOR (S57) CHARTS 5.5.5 How to select the information to display Select what type of notices to display as follows: ™ 1. Click the [DISP], [SET] and [Chart DISP] buttons on the InstantAccess bar 2. Click the [NtoM] tab. 3.
Page 135: Raster (Arcs) Charts
RASTER (ARCS) CHARTS ARCS Charts Approximately 2,700 ARCS charts are available on 11 chart CD-ROMs, covering the world's major trading routes and ports. Regionally based chart CD-ROMs RC1 to RC10 contain standard BA navigation charts. RC11 contains ocean charts at scales of 1:3,500,000 and smaller.
Page 136 6. RASTER (ARCS) CHARTS Update Date: Issue date of Update CD-ROM used to update the system Latest NM: Date of the latest Notice to Mariners included in the chart. Compilation Scale: The scale of the original paper chart is shown here. Projection: Projection of current chart.
Page 137 6. RASTER (ARCS) CHARTS Warnings There could be warnings not included in Notices to Mariners. British Admiralty may re- lease textual warnings for any chart and they are available here. Click the [Warnings] button to display the [Warnings] window. How to set preference for inset (panel) If there are the different insets with the same position, the operator can select pre- ferred inset, which displays your ship's position.
Page 138 6. RASTER (ARCS) CHARTS How to display notes of ARCS chart The operator can select a desired item from the combo box in the [ARCS Details] di- alog box in order to view notes for that item. Select an item on the [Notes] combo box then click the [Show Notes] button to show the notes for the selected item.
Page 139: Datum And Arcs Charts
6. RASTER (ARCS) CHARTS Datum and ARCS Charts The difference between ARCS chart local datum and WGS 84 datum is known as WGS 84 shift. This difference is known and the system does the conversion automat- ically. If the WGS shift for a chart is defined, the amount of shift is indicated. If the WGS shift is not defined, "Undefined"...
Page 140: Arcs Subscriptions
6. RASTER (ARCS) CHARTS ARCS Subscriptions ARCS customers can subscribe to one of two service levels, ARCS Navigator or ARCS Skipper. Note: If you receive an ARCS chart permit on a floppy disk, copy the contents of the disk to a USB flash memory and then install the permit files. 6.4.1 ARCS Navigator ARCS Navigator operators receive a comprehensive weekly updating service on a...
Page 141: C-Map Charts
C-MAP CHARTS Your chart system has the capability of using and displaying the latest C-MAP world- wide vector chart database. These charts are fully compliant with the latest IHO S-57 3.1 specifications. In order to prepare the system for use with the C-MAP database, there are a number of things that must be done.
Page 142: Troubleshooting
7. C-MAP CHARTS Troubleshooting If you are having problems installing your software or charts please check the follow- ing before contacting C-MAP: • Check that the charts are available, with the chart management function. • Check that the license is correctly installed, with the license function Contact Information: For information please call you're nearest C-MAP Office (de- tails can be found on the reverse side of the C-MAP chart CO box) or contact C-MAP.
Page 143 7. C-MAP CHARTS Chart Legend Type Name: Name of chart. Type: Type of chart. Edition: Edition number of the chart. Edition Date: Date the edition was published. Update Number: Update number Update Date: Date of update Compilation Scale: The scale of the original paper chart is shown here. Projection: Projection of current chart.
Page 144: Permanent Warnings
7. C-MAP CHARTS Permanent Warnings Permanent warnings help you keep the C-MAP up-to-date and these are shown at the bottom of the screen. Permanent warnings appear if the system detects a condition that may cause a chart to be not up-to-date. Message Meaning, Remedy [C-MAP]: Database not up to date...
Page 145: Notice To Mariners (Nm)
7. C-MAP CHARTS Notice to Mariners (NM) The NM has been developed to ensure mariners can simply view the information they need - in addition to the standard chart - to navigate safely and compliantly. By clearly showing where important Temporary or Preliminary changes may impact a voyage, the NM will give seafarers the same consistent picture of the maritime environment on their charts as they have always had.
Page 146 7. C-MAP CHARTS This page is intentionally left blank.
Page 147: Chart Alerts
CHART ALERTS The ECDIS can detect areas where the depth is less than the safety contour or detect an area where a specified condition exists. If prediction of own ship movement goes across a safety contour or an area where a specified condition exists, the system does the following: •...
Page 148: Chart Alerts
8. CHART ALERTS Chart Alerts Official S57 chart material contains depth contours that can be used for calculation of chart alerts. A chart database also includes different types of objects that the operator can use for chart alerts. The procedure for setting chart alerts is outlined below. 1.
Page 149: How To Select Objects Used In Chart Alerts
8. CHART ALERTS 8.1.2 How to select objects used in chart alerts You can also include calculation areas that have to be noted when sailing (for exam- ple, restricted areas). To include these areas in chart alerts, do the following: ™...
Page 150: How To Activate Own Ship Check
8. CHART ALERTS How to Activate Own Ship Check Calculation of own ship predicted movement area is done using a check area ahead, or around, own ship position. Set the check area as follows: 1. Select the [Look-ahead] page from the [Overlay/ NAV Tools] box.
Page 151: Route Planning
8. CHART ALERTS Route Planning The system will calculate chart alerts using user-defined channel limit for routes. Dan- ger areas are shown highlighted if safety contour or user-chosen chart alert areas are crossed by the planned route. For more information on route planning, see chapter 9. Note: If your voyage is going to take a long time or you are planning it much earlier than it is to take place, use the Display Date and Update Review dates corresponding to the dates you are going to sail.
Page 152 8. CHART ALERTS Note: When alerts are unchecked at step 3 in the above procedure, one or more of the following messages appear in the permanent warning box. • [Safety Contour] unchecked: "Indication of crossing safety contour if Off. (in planning)"...
Page 153: Routes
ROUTES Route Planning Overview A route plan defines the navigation plan from starting point to the final destination. The plan includes: • Route name • Name, latitude and longitude of each waypoint • Radius of turn circle at each waypoint •...
Page 154: Main Menu For Route Planning
9. ROUTES Main Menu for Route Planning The main parameters for the route planning are: • Latitude and longitude of the waypoint • Channel (XTD) limits to the waypoint • Turning radius of the waypoint • Maximum speed limit and planned speed for each leg There are two phases for a route: Route Plan and Route Monitor.
Page 155: How To Create A New Route
In this condition you can make a route and use it for navigation, but you cannot save it. Contact a FURUNO dealer for instruction. 4. Use the cursor to select a position for the first waypoint then push the left mouse button.
Page 156 9. ROUTES 5. Repeat step 4 to enter other waypoints. 6. After you enter the final waypoint, right-click the display to show the context-sen- sitive menu then select [Finish]. 7. Click the [Save] button. Enter a name (max. 63 characters) for the route, using the keyboard on the Control Unit or software keyboard.
Page 157: How To Use The Waypoints Page
9. ROUTES 9.4.1 How to use the Waypoints page The following fields and boxes can be found in the [Waypoints] page. Scroll the list rightward to see hidden items. WPT: Each waypoint has a number. XTD LIM/m: The radio button [XTD LIM] de- Name: You can name each waypoint.
Page 158: How To Use The User Chart Page
9. ROUTES Note: You can select the route information data to display on the [Waypoints] page with the context-sensitive menu. Right click the “Edit Columns” to show the context- sensitive menu. Check or uncheck items as appropriate then click the [OK] button. 9.4.2 How to use the User Chart page The [User Chart] page lets you link user charts to routes.
Page 159: How To Use The Optimize Page
9. ROUTES 9.4.3 How to use the Optimize page After all waypoints are inserted and you have made safe water calculation, you can optimize your route, on the [Optimize] page. If not chosen, then optimization will be done automatically with max. speed. If you want do optimization with a specific strat- egy, see section 9.8 for how to optimize a route.
Page 160: How To Use The Alert Parameters Page
9. ROUTES 9.4.4 How to use the Alert Parameters page The [Alert Parameters] page sets the alert conditions to use when checking a route. Put a “W” for an item to highlight on the chart. ([Safety Contour] is fixed to “A” (Alarm). If you do not require the highlight display for an item, put a “C”...
Page 161: How To Use The Check Results Page
9. ROUTES Item Description Item Description Permit Permit for chart has expired. Not Up-to-date Chart not up to date. Expired Context sensitive menus A context-sensitive menu for setting the Set “ALL” setting to all legs draught is available on the [Alert Parame- Clear setting ters] page.
Page 162: How To Modify An Existing Route
9. ROUTES How to Modify an Existing Route 9.5.1 How to change waypoint position To change position of a waypoint you have the following choices: • Enter latitude and longitude on the [Waypoints] page in the [Route Plan] dialog box. •...
Page 163: How Insert A Waypoint
9. ROUTES 9.5.4 How insert a waypoint How to insert a waypoint between waypoints from the electronic chart area 1. Put the cursor anywhere on the route where you want to insert a waypoint. 2. Right-click to show the context-sensitive menu then click [Edit]. 3.
Page 164: Sar Operations
9. ROUTES SAR Operations The SAR feature facilitates search and rescue and MOB operations. To use the SAR feature, get into the Voyage planning mode then do the following: 1. Click the [Planning] and [Route] buttons on the InstantAccess bar™ to show the [Route Plan] dialog box then click the [SAR] button.
Page 165 9. ROUTES Search Options Sample pattern type Parallel tracks Search Pattern Heading Direction: Select the direction to (North ref.) start the search, Clockwise or Anti- Track space clockwise. Search Pattern Heading: See the Start Point right figure. Start Leg Length: Enter the start leg length.
Page 166: Route Bank
9. ROUTES • The route must have been checked. 9. To save the route, click the [Save] button and enter a name for the route, using the keyboard on the Control Unit or the software keyboard. If necessary you can drag waypoints to new position, like with an ordinary route. Route Bank The route bank stores all the routes you have created.
Page 167 9. ROUTES 6. Select the route that has the waypoint(s) you want to insert into the active route, then click the [Open] button. In the example below, some waypoints of Untitled 3 will be inserted into Untitled 1. 7. At [Insert Position], select where you want to insert waypoints into the active route, [Before] or [After] the waypoint selected in the next step.
Page 168: Route Optimization
9. ROUTES Route Optimization 9.8.1 Available route optimization strategies After all waypoints are inserted, the route is optimized from the [Optimize] page in the [Route Plan] dialog box. If no optimization strategy is chosen, the optimization is done with "max. speed," defined in ship parameters. Optimization calculates all parameters for route steering (course and distance between two waypoints, maneuvering start point, WOP, etc.).
Page 169: How To Optimize A Route
9. ROUTES 9.8.2 How to optimize a route You can define Estimated Time of Departure (ETD), desired number of waypoints and Estimated Time of Arrival (ETA) on the [Optimize] page in the [Route Plan] dialog box to optimize your route. 1.
Page 170: How To Plan A Speed Profile
9. ROUTES 3) For [Time table], the [Set ETA] window appears. Set the ETA to use for each waypoint. To enter the Time and Date, click the [Date] window to show the [Set date] dialog box. Click the appropriate date. The date entered appears in the [Set ETA] window.
Page 171: How To Import Routes
9. ROUTES How to Import Routes 9.9.1 How to import route data from another unit You can import a route created on another FMD-3xx0, FAR-3xx0, FCR-2xx9. 1. Set the USB flash memory that contains the route data to import into the USB port on the Control Unit.
Page 172: How To Import Rtz, Csv, Ascii Format Route Data
9. ROUTES 9.9.3 How to import RTZ, CSV, ASCII format route data 1. Set the USB flash memory to the USB port on the Control Unit. 2. Activate the Voyage planning mode. 3. On the InstantAccess bar™, click the [Manage Data] and [Route] buttons to show the [Route Data Management] dialog box.
Page 173: How To Export Route Data
9. ROUTES 9.10 How to Export Route Data 9.10.1 How to export FMD-3xx0 route data You can export route data to share the data with other FMD-3xx0, FAR-3xx0, FCR- 2xx9. 1. Set a USB flash memory in the USB port on the Control Unit. 2.
Page 174: How To Export Route Data In Fea-2X07, Rtz, Csv, Ascii Format
9. ROUTES 9.10.2 How to export route data in FEA-2x07, RTZ, CSV, ASCII format 1. Activate the Voyage planning mode then set a USB flash memory to the USB port on the Control Unit. 2. On the InstantAccess bar™, click the [Route], [Route] and [Route Data Management] buttons to show the [Route Data Management] dia-...
Page 175: Route Transfer Feature
9. ROUTES 9.12 Route Transfer Feature The route transfer feature lets you send and receive route data (RRT sentence) among the units connected in the LAN. Information about transmitted and received route data is stored in the route transfer log (see section 19.6). 9.12.1 How to turn route transfer on/off To turn the route transfer feature on or off, do the following:...
Page 176: How To Send And Receive Monitored Routes
9. ROUTES 4. Click the [Save] button to save your settings, then click the [Close] button to finish and close the dialog box. With route transfer selected to ON, the option [Route Transfer (LAN)] is added to the drop down list box in the [Route Data Management ]dialog box. 9.12.2 How to send and receive monitored routes Sending monitored routes...
Page 177: How To Send And Receive Planned Routes
9. ROUTES • [Save for later use]: Route data is saved. (You can write over existing route data or save received route data under a new name.) • [Start Monitoring]: Moves the received route to the Route Monitor. This button is not selectable until the route is checked.
Page 178: Reports
9. ROUTES 9.13 Reports This ECDIS generates reports for waypoints in the selected route. If connected to a printer, reports can be printed by clicking the [Print Text] button. Text in reports can be searched with the [Find] button. To generate a report, do the following: 1.
Page 179 9. ROUTES WPT report The WPT report contains the following information for each waypoint in the route se- lected. • Route name • Date of report • Waypoint no. • Position in latitude and longitude • Length of waypoint • Distance remaining in route •...
Page 180 9. ROUTES Full WPT report You can generate a full waypoint report for the route selected. The report includes the following for each waypoint • Route name • Date of report • Waypoint no. • Position in latitude and longitude •...
Page 181 9. ROUTES Passage plan report The passage plan report generates waypoint information for each waypoint in the route selected. • Route name • Date of report • Waypoint no. • Position in latitude and longitude • Length • Cumulative length •...
Page 182 9. ROUTES This page is intentionally left blank. 9-30...
Page 183: 10. User Charts
10. USER CHARTS 10.1 Introduction User charts are overlays that the user creates to indicate safety-related objects and areas. They can be displayed on both the radar overlay and the electronic chart. These charts are intended for pointing out safety-related items like position of import- ant navigation marks, safe area for the ship, etc.
Page 184: How User Charts Are Synced
10. USER CHARTS These areas can be used to specify safe areas as defined by the master or by the policy of the ship's owner. They are always available regardless of the type of chart material used. • Circle: The operator can define an area with a circle, which can define a location to avoid.
Page 185: How To Create A User Chart
10. USER CHARTS 10.3 How to Create a User Chart You can create and modify a user chart in the Voyage planning mode. To make a complete user chart, do the following: 1. Click the [PLAN] button on the Status bar to go to the Voyage planning mode. 2.
Page 186 10. USER CHARTS (3) Click (1) Click (2) Click (4) Right-click; select Finish. (2) Drag cursor; (1) Click click to set. 1) Put cursor where to locate center of circle then click. 2) Drag cursor to set radius; click to set. How to create a line How to create a circle (1) Click...
Page 187 10. USER CHARTS • P: Message appears when your ship is 10NM beyond the user chart object object. • Blank: No message display. 3) For a line, enter the distance from the line position in the [Range of notes] input box.
Page 188 10. USER CHARTS • The Line with the name "Coast" is a coastline. • The Notes for the Circle is “E”. The message that was input in the [Description] box will appear in a pop-up window when your ship arrives inside the Circle. •...
Page 189: How To Edit Objects On A User Chart
10. USER CHARTS 10.4 How to Edit Objects on a User Chart 1. Do steps 1 and 2 in section 10.3 to show the [User Chart] dialog box. 2. Click the [Select] button to show the [Select User Chart] dialog box. 3.
Page 190: How To Delete Objects From A User Chart
10. USER CHARTS 3) Select [Insert Before] or [Insert After] to insert the point before or after the se- lected point. 4) Change latitude and longitude position of new point if necessary. 5. Click the [Save] button to save, then click the [Close] button to close the dialog box.
Page 191: How To Select The User Chart Objects To Display
10. USER CHARTS 10.7 How to Select the User Chart Objects to Display User charts can be displayed on the electronic chart. On the Instant Access bar, click [DISP], [SET], and [Symbol DISP]. Open the [Mariner] page and check the user chart items to display.
Page 192: User Chart Created With Ecdis Fea-2X07
10. USER CHARTS 10.8.2 User chart created with ECDIS FEA-2x07 User charts created at the ECDIS FEA-2x07 can easily be imported to this ECDIS. Copy the user charts to a folder (see chapter 17 in the operator’s manual of the FEA- 2x07) in a USB flash memory then do as follows.
Page 193: How To Export A User Chart
10. USER CHARTS 10.9 How to Export a User Chart 10.9.1 User chart created on FMD-3xx0 Do as follows to import user charts created on other units (FMD-3x00, FCR-2xx9, FAR-3xx0). 1. Insert a USB flash memory in the USB port on the control unit. 2.
Page 194: 10.10 How To Delete User Charts
10. USER CHARTS 10.10 How to Delete User Charts 1. Click the [PLAN] button on the Status bar to get into the Planning navigation mode. 2. Click the [Manage Data] button on the InstantAccess bar™ followed by the [User Chart] button. 3.
Page 195 10. USER CHARTS Full report The full report contains information about each tidal, line, clearing line, label, area and circle in the user chart selected. Check or uncheck the boxes at the top of the display to select the report(s) to display. Check the report(s) to display.
Page 196 10. USER CHARTS Line report The Line report provides the following information. • Name of line • Latitude and longitude position of each point on a line • [On Radar] appears with those lines selected to show on the radar overlay. (Check- mark in the [Radar] column of [User Chart] dialog box.
Page 197 10. USER CHARTS Area report The area report provides the following information • Name of area • Latitude and longitude position of each point on the area • [On Radar] appears with those areas selected to show on the radar overlay. (Checkmark in the [Radar] column of [User Chart] dialog box.
Page 198: How To Select The User Chart(S) To Use In Route Monitoring
10. USER CHARTS Label report The Label report provides the following information. • Name of label • Latitude and longitude position of each label. • [On Radar] appears with those labels selected to show on the radar overlay. (Checkmark in the [Radar] column of [User Chart] dialog box. See section 10.3.) •...
Page 199 10. USER CHARTS and shows the user charts selected for use in route monitoring. Click a user chart name to see details, in the [Contents] window. How to cancel use of a user chart during route monitoring To cancel only a user chart during route monitoring, get into the Voyage navigation mode, then click the [Voyage], [User Chart], [Select/Unselect] buttons on the Instant- Access bar™...
Page 200 10. USER CHARTS This page is intentionally left blank. 10-18...
Page 201: 11. How To Monitor Routes
11. HOW TO MONITOR ROUTES Route monitor is a means for permanent monitoring of the ship's behavior relative to the monitored route. The [Monitor Information] box displays the data on the ship's po- sition relative to the monitored route. The monitored route consists of the following in- formation, displayed in the electronic chart area: •...
Page 202 11. HOW TO MONITOR ROUTES Method 2: Selection from the Route information box Right-click the route name location in the [Route Information] box then select [Select Route] to show the [Select Route] dialog box. Select a route then click the [Open] but- ton.
Page 203: How To Stop Monitoring A Route (Manual, Auto)
• Other alerts unchecked: "Indication of some prohibited areas or areas with special conditions is Off. (in monitoring)"  If this ECDIS is connected in the network to an FMD-3200/3300 ECDIS that is inter- faced with an IEC 62065 Ed.2 compliant TCS (YOKOGAWA PT-900, Tokyo Keiki PR-9000, EMRI FAP-3000), the alert 174 (WPT Approach) is generated at each waypoint if the TCS is not connected to the ECDIS in route monitoring.
Page 204: How To Select What Parts Of A Route To Display
11. HOW TO MONITOR ROUTES 11.3 How to Select What Parts of a Route to Display You can specify what parts of the monitored route to display. Click the [DISP], [SET] and [Symbol DISP] buttons on the InstantAccess bar™. Click the [Route] tab.
Page 205: How To View Linked User Chart Information
11. HOW TO MONITOR ROUTES Check ETA Parameters for checking ETA. The arrow to the left of [Check ETA] collapse window or display the [Waypoints], [Linked User Chart] and [Check Results] abs. WPT, Distance Select a WPT to find the distance to that waypoint from current position. Plan When planned speed is used in navigation, ETA to selected waypoint ap- pears.
Page 206: How To View User Chart Object Information In Route Monitoring
11. HOW TO MONITOR ROUTES 11.6 How to View User Chart Object Information in Route Monitoring In route monitoring, you can cursor pick user chart objects to show their information. Put the cursor on the user chart symbol to show the pop-up menu. Select [User Chart INFO] from the pop-up menu.
Page 207: Safe Off Track Mode
11. HOW TO MONITOR ROUTES [Back to Track]. This mode creates a track to follow to return to the monitored route when the vessel goes outside the channel limits. The mode is automatically selected according to whether a monitored route is active or not and the amount of off course.
Page 208: Back To Track Mode
11. HOW TO MONITOR ROUTES 3. Roll the trackball to select the angle of approach to the destination then click. Current position Monitored route Instant track WPT2 WPT2 (orange) Instant track waypoints Destination (orange) Click a location to set desired angle of Click destination point .
Page 209 11. HOW TO MONITOR ROUTES 2. Click a leg or a waypoint on the monitored route. The location must be within 50 NM of current position. Monitored route Current position WPT2 WPT2 Instant track Click a leg on monitored route. Instant track (orange) waypoints...
Page 210: Instant Track Messages
11. HOW TO MONITOR ROUTES 11.8.3 Instant track messages The table below shows all the instant track messages and their meanings. Message Meaning Color (1) Instant Track mode "Back to Track" Back to track mode White "Safe Off Track" Safe off track mode White (2) Check result, error message "Could not create the Track."...
Page 211: Instant Track Details
11. HOW TO MONITOR ROUTES 11.8.4 Instant track details You can see the location and alert type found in an instant track by clicking the [De- tails] button on the [Instant Track] dialog box. Note: If the Status is not [OK], an alert (alarm or warning priority, depending on set- ting) appears in the Alert box.
Page 212 11. HOW TO MONITOR ROUTES To close the [Instant Track] dialog box, click the [Close] button. (The system continues monitoring the instant track route.) The following occurs when sensor data is lost while using the instant track function. Monitoring condition Result Instant track route monitor- •...
Page 213: How To Return To A Monitored Route When Following An Instant Track Route (Safe Off Track Mode Only)
11. HOW TO MONITOR ROUTES 11.8.6 How to return to a monitored route when following an instant track route (safe off track mode only) Do the following to return to a monitored route while following an instant track route. 1. While monitoring an instant track route, click the [Original Route] dialog box and its [Monitoring] page in the [Instant Track] dialog box to show the [Select Route] dialog box.
Page 214: Button Label And Equipment State
11. HOW TO MONITOR ROUTES 11.8.7 Button label and equipment state The label on the button at the position circled in the figure below changes according to the state of the instant track. Instant track TCS state Button label state Creating Monitoring Execute (same function as Monitoring)
Page 215: How To Share A Monitored Route
11. HOW TO MONITOR ROUTES 11.9 How to Share a Monitored Route With multiple units (FMD-3xx0, FCR-2xx9, FAR-3xx0) connected, the master unit can share a monitored route with the units mentioned above. Follow the procedure below to enabling the route sharing feature. 1.
Page 216 11. HOW TO MONITOR ROUTES This page is intentionally left blank. 11-16...
Page 217: 12. Navigation Tools
12. NAVIGATION TOOLS This chapter presents the various navigation tools available with the system. With the exception of the divider, the tools listed below are in the [Overlay/NAV Tools] Box. • TT/AIS (see chapters 13 and 14) • Predictor • Echo (see chapter 16) •...
Page 218: Parallel Index (Pi) Lines
12. NAVIGATION TOOLS 12.2 Parallel Index (PI) Lines The parallel index lines are useful for keeping a constant distance between own ship and a coastline or a partner ship when navigating. There are six sets of PI lines (PI- P6) on the [PI] page and you can turn them on or off individually. Select the PI line to process with the [Display] pull-down list then click the [ON] or [OFF] button as appro- priate.
Page 219: How To Adjust Pi Line Orientation, Pi Line Interval
12. NAVIGATION TOOLS 12.2.5 How to adjust PI line orientation, PI line interval There are two ways to adjust PI line orientation and PI line interval: through the menu and on the screen. How to adjust PI line orientation, PI line interval from the menu 1.
Page 220: How To Adjust Pi Line Length
12. NAVIGATION TOOLS 12.2.7 How to adjust PI line length You can adjust the forward and backward lengths of a PI line when [Index Lines] is set to 1. 1. Open the main menu and select [NAV Tools], [PI Lines] and [Truncate]. 2.
Page 221: Look-Ahead
12. NAVIGATION TOOLS 12.3 Look-ahead [Look-ahead] sets the area ahead and around own ship for which to check for safe navigation. See section 8.2 for how to activate own ship check. 12.4 Ring The range rings are the concentric set of rings on the ECDIS display. They provide an estimation of the range to an object.
Page 222 12. NAVIGATION TOOLS How to select range calculation method The range calculation method for the EBL and VRM can be selected to Rhumbline or Great Circle. Do as follows to select a calculation method. 1. Open the menu, then select [NAV Tools] and [Geometry] to show the [Geometry] page.
Page 223: Predictor
12. NAVIGATION TOOLS 12.5 Predictor The predictor is a tool for estimating your ship's future positions and behavior. The on- screen predictor graphic consists of three pieces of your ship, drawn in true scale to successive future positions. The position of the third symbol will be your approximate position at the end of the time interval selected.
Page 224: Anchor Watch
12. NAVIGATION TOOLS 12.6 Anchor Watch The anchor watch feature checks to see if your ship is drifting when it should be at rest. The anchor mark appears at the location of your ship’s anchor. You can adjust the lo- cation for the anchor (see section 23.13).
Page 225: Ukc (Under Keel Clearance)
12. NAVIGATION TOOLS 12.7 UKC (Under Keel Clearance) 12.7.1 UKC overview UKC is the distance between the deepest point of the vessel's hull and the seabed. The Actual UKC feature continuously checks the ship's draught setting (UKC), and ac- tual depth. When a look-ahead area is set and the depth within the set area gets shallower than the UKC, the Alert 30173 “UKC Limit”...
Page 226: How To Set Ukc
12. NAVIGATION TOOLS 12.7.2 How to set UKC 1. Select the [UKC] page from the [Overlay/NAV Tools] box. 2. Use [Echo Alarm Limit] to set the distance for the echo alarm. To activate the alarm, click the [ON/OFF] button to show [ON]. 3.
Page 227: Curved Ebl
12. NAVIGATION TOOLS 12.8 Curved EBL The [Curved EBL] function shows the planned steering radius. You can use this func- tion to determine the best location to begin a turn. You can also use the [Curved EBL] function to determine whether a turn is conduct as planned. To show/hide the [Curved EBL], click the [ON]/[OFF] button on the [Curved EBL] page of the [Overly/NAV Tools] box.
Page 228: Divider
12. NAVIGATION TOOLS 12.9 Divider The divider performs the following calculations: • Range and bearing between two points • TTG between two points • Total TTG from start to end • Total distance from start to end The divider is available in the Voyage navigation and Voyage planning modes. Only one divider can be displayed.
Page 229: Usage Characteristics, Limitations
12. NAVIGATION TOOLS 00:13 2.75NM 11.63NM 00:26 00:13 358.6° 261.1° 22.60NM 00:26 22.60NM 11.63NM 11.63NM 170.6° 170.6° Drag here 00:13 00:13 00:13 00:13 10.57NM 10.57NM 10.97NM° 10.97NM 213.6° 213.6° 00:00 00:00 00:00 00:00 Note: If you drag a point to the edge of the displayed area, the chart scrolls in that direction.
Page 230: How To Select The Range Calculation Method
12. NAVIGATION TOOLS 12.9.4 How to select the range calculation method The range calculation method for the EBL and VRM can be selected to Rhumbline or Great Circle. Do as follows to select a calculation method. 1. Open the menu, then select [NAV Tools] and [Geometry] to show the [Geometry] page.
Page 231: Tracked Target (Tt) Functions
13. TRACKED TARGET (TT) FUNC- TIONS With connection to a radar, the movement of a maximum of 200 radar-tracked targets can be shown on the chart. Note: The following conditions must be met to use the TT function: • The TT data from the radar must be true bearing referenced. •...
Page 232: Tt Symbols And Tt Attributes
13. TRACKED TARGET (TT) FUNCTIONS 13.2 TT Symbols and TT Attributes 13.2.1 TT symbols The symbols used in this equipment comply with IEC 62288 Ed.2. Symbol Default color Name Description Green Past position point Marks a past position of a TT. Green Target under A target acquired manually is initially indicated...
Page 233: How To Filter Tt Targets
13. TRACKED TARGET (TT) FUNCTIONS 13.3 How to Filter TT Targets When there is a large number of TT targets tracked at one time, the screen can be- come crowded. You can limit the TT targets display on your screen, based on distance from your vessel.
Page 234: How To Set Vector Length And Vector Motion
13. TRACKED TARGET (TT) FUNCTIONS 13.4 How to Set Vector Length and Vector Motion Ground stabilization and sea stabilization Target vectors can be ground stabilized or sea stabilized in the True Motion mode. To select speed over the ground or speed through the water data, open the [SPD] page from the [System Sensor Settings] or [Local System Settings] menu.
Page 235 13. TRACKED TARGET (TT) FUNCTIONS Relative vector Relative vectors on targets that are not moving over the ground such as land, naviga- tional marks and ships at anchor will represent the reciprocal of own ship's ground track. A target whose vector passes through own ship is on a collision course. (Dotted lines in the figure are for explanation only.) Current (Set and drift)
Page 236: How To Display Tt Data
13. TRACKED TARGET (TT) FUNCTIONS 13.5 How to Display TT Data 13.5.1 How to display target data for individual TT By Control Unit Put the cursor on a TT then push the TARGET DATA key. By trackball Click the target for which you want to show its data. TT data To erase TT data from a data box, click the appropriate close data button.
Page 237: Displaying Past Positions Of Tt
13. TRACKED TARGET (TT) FUNCTIONS 13.6 Displaying Past Positions of TT The past position display shows equally time-spaced dots marking past positions of TT. A new dot is added at preset time intervals until the preset number is reached. If a TT changes its speed, the spacing will be uneven.
Page 238: How To Set The Tt Source
13. TRACKED TARGET (TT) FUNCTIONS 13.7 How to set the TT Source 13.7.1 TT source for configurations compliant with the latest regula- tions When the connected radar is compliant with the latest regulations, the TT source can be set as one of the antennas (ANT_1 etc.) from the [TT Source] drop-down box. Normally, select the radar antenna which is selected to display radar echoes as the TT source.
Page 239: Tt Source For Non-Compliant Configurations
13. TRACKED TARGET (TT) FUNCTIONS 13.7.2 TT source for non-compliant configurations For retro-fits and configurations where the connected radar does not comply with the latest regulations, you can select one of the antennas listed as “other antennas” (RA0201, etc.) as the TT source. From the drop-down box, select the antenna SFID (set at installation) for the antenna to use as the TT source.
Page 240 13. TRACKED TARGET (TT) FUNCTIONS This page is intentionally left blank. 13-10...
Page 241: 14. Ais Target Functions
14. AIS TARGET FUNCTIONS 14.1 Introduction An AIS transponder can be connected to the ECDIS to display AIS targets received from an AIS transponder. The ECDIS can store up to 2,000 AIS targets in its storage buffer. When this buffer becomes full of AIS targets, Alert 190 “AIS Target Capacity 100%”...
Page 242: Ais Symbols
14. AIS TARGET FUNCTIONS There can be several hundreds or several thousands AIS targets, and of those only a few will be significant for your ship. To remove unnecessary AIS targets from the EC- DIS display, the feature "active and sleeping AIS targets" is available. Initially any new AIS target received by an AIS transponder is not-active (="sleeping").
Page 243 14. AIS TARGET FUNCTIONS Default Symbol Name Description color Green SAR Vessel SAR (Search And Rescue) vessel Green Non HDG/COG sleeping The AIS symbol has dashed lines in the AIS target following instances: • No STW or SOG. If speed data be- Green Non HDG/COG activated comes invalid, all AIS symbols are...
Page 244 14. AIS TARGET FUNCTIONS AIS Physical AIS Virtual Default Meaning AtoN Symbol AtoN Symbol Color Blue Basic shape Blue RACON Blue Emergency wreck mark Blue North cardinal mark Blue East cardinal mark Blue South cardinal mark Blue West cardinal mark Blue Port hand mark Blue...
Page 245: Voyage Data
14. AIS TARGET FUNCTIONS 14.3 Voyage Data Before you embark on a voyage, set your navigation status, ETA, destination, draught and crew, on the [Voyage Data] page in the [NAV Status] menu. The data entered here is reflected to the AIS transponder. 1.
Page 246: How To Show, Hide Ais Targets
14. AIS TARGET FUNCTIONS 14.4 How to Show, Hide AIS Targets Targets that are being tracked by an AIS transponder can also be displayed on the ECDIS display. To show or hide AIS target, select the [TT/AIS] page from the [Overlay/ NAV Tools] box.
Page 247: How To Filter Ais Targets
14. AIS TARGET FUNCTIONS 14.5 How to Filter AIS Targets 1. Right-click [AIS] on the [TT/AIS] page in the [Overlay/NAV Tools box], select [Set- ting] and open the [Setting] page. Note: The Setting page can also be opened as follows: •...
Page 248: Activated Targets
14. AIS TARGET FUNCTIONS 14.6 Activated Targets When you change a sleeping target to an activated target, the target’s course and speed are indicated with a vector. The vector can be monitored to find vessel move- ment. To activate a sleeping target, put the cursor on the target then press the ACQ/ACT key.
Page 249: How To Display Ais Target Data
14. AIS TARGET FUNCTIONS 14.8 How to Display AIS Target Data Standard data Put the cursor on a target then press the TARGET DATA key to show the [AIS Info] box. (1/2) Title bar Normal/Expand button MMSI Scroll buttons* Vessel name Close button Bearing Heading...
Page 250 14. AIS TARGET FUNCTIONS Expanded data Left click an active AIS target to show the AIS info box. Click the [Expand] button on the [AIS Info] box to show expanded AIS data. (1/2) Title bar Normal/Expand button MMSI Scroll buttons* Vessel name Close button Heading...
Page 251: Vector Length, Vector Stabilization In True Motion Mode
14. AIS TARGET FUNCTIONS 14.9 Vector Length, Vector Stabilization in True Mo- tion Mode Ground stabilization and sea stabilization Target vectors can be ground stabilized or sea stabilized in the True Motion mode. To select speed over the ground or speed through the water data, open the [SPD] page from the [System Sensor Settings] or [Local System Settings] menu.
Page 252: 14.10 How To Display Ais Target Past Positions
14. AIS TARGET FUNCTIONS 14.10 How to Display AIS Target Past Positions The past position display shows equally time-spaced dots marking past positions of activated AIS targets. A new dot is added at preset time intervals until the preset num- ber is reached.
Page 253: 14.11 Tt, Ais Target Association
You can see own ship's data on the [Own Ship] page in the [NAV Status] menu. Open the menu then click both [NAV Status] in the [TT/AIS] menu and the [Own Ship] tab. MMSI: 457804356 Length(LOA): 223.2 m Name: FURUNO Voyager Width: 31.8 m Call Sign: JZ5890312 Ref Bow: 3.3 m...
Page 254 14. AIS TARGET FUNCTIONS This page is intentionally left blank. 14-14...
Page 255: Ais Safety, Navtex Messages
15. AIS SAFETY, NAVTEX MESSAG- 15.1 AIS Safety Messages You can send and receive messages via the VHF link, to a specified destination (MMSI) or all AIS-equipped ships within communication range of your ship. Messages can be sent to warn of safety of navigation, for example, an iceberg sighted. Routine messages are also permitted.
Page 256: How To Display Received And Sent Ais Safety Messages
1. In Voyage navigation mode, click the [MSG] and [Safety MSG] buttons on the In- stantAccess bar™. 2. Click the [Receive Box] or [Send Box] button as appropriate. 3. Click a message to view its contents. WELCOME TO FURUNO 15-2...
Page 257: How To Delete A Received Or Sent Message
15. AIS SAFETY, NAVTEX MESSAGES 15.1.3 How to delete a received or sent message How to delete a sent or received message 1. Click the [Receive Box] or [Send Box] as appropriate. 2. Click the box that is before the date to show a check mark. (All messages can be checked or unchecked with the context-sensitive menu.
Page 258: How To Receive Navtex Messages
15. AIS SAFETY, NAVTEX MESSAGES 15.2.1 How to receive Navtex messages To display a received NAVTEX message, do the following: 1. In Voyage navigation mode, click the [MSG] and [NAVTEX MSG] buttons on the InstantAccess bar™. 2. Click the message to view. The text of the message appears in the [Description] box.
Page 259: How To Delete Received Navtex Messages
15. AIS SAFETY, NAVTEX MESSAGES • You can check the settings for the Navtex receiver (if connected). Click the [Re- ceiver] button to show the settings. 15.2.2 How to delete received Navtex messages Note: A large amount of messages may take some time to delete. How to delete received Navtex messages 1.
Page 260 15. AIS SAFETY, NAVTEX MESSAGES This page is intentionally left blank. 15-6...
Page 261: 16. Radar Overlay
The radar overlay has the radar echo image overlaid on the ECDIS chart display, in the Voyage navigation mode. The radar video signal can be fed from a FURUNO radar connected to the ECDIS via LAN, or via the optional Radar Connection Box (RCB- 002) in the case of a FURUNO radar or a non-FURUNO radar.
Page 262: How To Setup The Radar Overlay
16. RADAR OVERLAY 16.2 How to Setup the Radar Overlay Radar echoes can be output to the ECDIS and shown on its display. Like details on S57 charts, the radar overlay can be displayed or removed from the chart display. The transparency of the echo display can be set from the [Echo] page in the [Overlay/NAV Tools] box.
Page 263: How To Adjust The Radar Signal Fed From The Radar Connection Box
16. RADAR OVERLAY 16.3 How to Adjust the Radar Signal Fed From the Ra- dar Connection Box Follow the procedure below to set up the radar overlay for the radar connected via the Radar Connection Box. These adjustments are not necessary for the radar which feeds the radar signal via LAN.
Page 264 ECDIS via the Radar Connection Box. Note: For FURUNO radars, it is recommended to use the settings set on the radar in order to match the radar overlay picture with the radar picture.
Page 265 16. RADAR OVERLAY 1) [Noise Reject] suppresses white noise. 2) [Video Contrast] adjusts the video dynamic range and curve. Refer to the fig- ure below for settings and results. The gain at the center of the signal strength is low, suitable for distinguishing “Standard”...
Page 266 16. RADAR OVERLAY 6) [Heading Align]: Some positioning error may occur when the antenna unit is installed. This error can be compensated from the ECDIS. Correct bearing (relative to heading) Target Apparent position of target Antenna oriented to port Picture appears deviated clockwise.
Page 267: Error Between Radar Echo Image And Chart
16. RADAR OVERLAY 16.4 Error Between Radar Echo Image and Chart There are several reasons why the radar echo image and chart display do not match exactly. The mismatch is a combination of several reasons and removing one reason doesn't solve the mismatch perfectly. There is a fundamental difference between the radar echo image and corresponding chart feature.
Page 268: Error Sources For Radar Echo Image And Tt Mismatch
16. RADAR OVERLAY 16.5 Error Sources for Radar Echo Image and TT Mis- match There are several reasons why the radar echo image and tracked target symbols do not match exactly. 1. Different gyro value at radar overlay and at ECDIS. 2.
Page 269: 17. Weather Overlay
17. WEATHER OVERLAY 17.1 What is the Weather Overlay? The weather overlay, available in the Voyage navigation and Voyage planning modes, provides an animated display of weather information over time for the area selected. The information may include wave, ocean current, wind, temperature, cloud coverage, and precipitation rate.
Page 270: How To Select, Playback A Weather Data File
17. WEATHER OVERLAY When the weather overlay is made active, two weather overlay dialog boxes appear, [Weather Overlay Control] and [Weather Overlay]. The [Weather Overlay Control] di- alog box selects and plays back weather data files. The [Weather Overlay] dialog box controls what weather information to display and how to display it.
Page 271: How To Set Up The Weather Overlay
17. WEATHER OVERLAY 3. Select the weather data file then click the [Open] button. The message "Now Preparing... "appears while the file is being read, and "Now unmounting the media" appears when the reading is completed. The [Weather Overlay Control] dialog box shows the start and end times of the file. If the file is too large, the message "An error occurred.
Page 272 17. WEATHER OVERLAY tion] drop-down list. The choices are [Wind], [Temperature], [Cloud Coverage], [Precipitation Rate], [Wave], and [Ocean Current]. (The weather data file must contain the data selected in order to display it.) 2. The [Color] checkbox, when checked, provides a color presentation of the weath- er item selected.
Page 273: Weather Overlay Examples
17. WEATHER OVERLAY 17.5 Weather Overlay Examples 17.5.1 Wind display The wind display provides wind speed and direction. Windbarbs show both wind speed and direction. The relative wind speed is shown in colors, from blue (low) to ma- genta (high). How to read the windbarbs Windbarbs represent both wind speed and direction.
Page 274: Temperature Display
17. WEATHER OVERLAY 17.5.2 Temperature display The temperature display provides air temperature information, in colors from blue (low) to red (high). The entire area in the figure below has moderately high tempera- tures. 17.5.3 Cloud coverage display The cloud coverage display shows areas obscured by clouds, in transparent (low) to light gray (high).
Page 275: Waves Display
17. WEATHER OVERLAY 17.5.5 Waves display The waves display shows the average height of the highest waves, in colors from green (low) to red (high). The length of an arrow indicates wave height. The arrow points in the direction of the main swell. Arrow length and wave height (m) Less than 1 Less than 3...
Page 276: Weather Spot Information
17. WEATHER OVERLAY 17.6 Weather Spot Information You can get various weather information for any area with the weather spot informa- tion feature, in the Voyage navigation and Voyage planning modes. The weather over- lay must be active and position data available. 1.
Page 277: 18. Navigation Sensors
18. NAVIGATION SENSORS 18.1 CCRS This ECDIS employs a Consistent Common Reference System (CCRS) for the acqui- sition, processing, storage and distribution of sensor information. The CCRS ensures that all parts of the system uses the same source and values, e.g., speed through wa- ter, heading, etc.
Page 278: How To Select Navigation Sensors
18. NAVIGATION SENSORS 18.2 How to Select Navigation Sensors The operator can choose navigation sensors to use for navigation and view their cur- rent values on the applicable page in the [System Sensor Settings] and [Local Sensor Settings] menus. To access these menus, right-click the [Sensor information] box then click [Open MENU].
Page 279 18. NAVIGATION SENSORS Reference SPD: If checked, radar is used as the source for speed and course. Check- mark is valid when the speed measurement method is “ground”. Not available with system sensor. Set and drift: Check the [Set Drift] checkbox to manually set speed and course of drift. Note that you can select manual drift only if you deactivate the AIS function.
Page 280 18. NAVIGATION SENSORS POSN (Position) page PRIM: GPS1 LAT: 35°15.743’N LON: 139°50.064’E DGPS LAT: 35°15.743’N LON: 139°50.064’E Sensor: Name of sensor used. Position sensors have priority in order of accuracy. When a sensor is changed, the Alert 30602 "Position Source Change" appears. Manual: When a sensor cannot be used, select [Manual], then enter position manual- Other sensors page To show the [Other Sensors] page, open the menu and select [Other Sensor Settings].
Page 281: Source Of Position
18. NAVIGATION SENSORS 18.3 Source of Position The figure below shows how source for position is chosen. The position sensors have either primary or secondary as input for their calculation. DGPS position sensors are considered more accurate than other position sensors. The latitude and longitude position is shown at the top-right position on the chart dis- play, and in the example below the position source is DGPS.
Page 282: Ccrp, Primary, Secondary And Pivot Positions Of Own Ship
18. NAVIGATION SENSORS 18.4 CCRP, Primary, Secondary and Pivot Positions of Own Ship This system displays position in one of four methods • CCRP position: CCRP • Primary position: Position generated by position source chosen as highest priority. • Secondary position: Position generated by position source chosen as 2nd highest priority.
Page 283: Source Of Navigation Data
18. NAVIGATION SENSORS 18.5 Source of Navigation Data The figure below shows how various sources of navigation data are chosen. "SOG, COG" is speed over the ground and course over the ground, respectively. "SPD" is speed through the water. “Drift” is the difference between speed through the water and speed over ground.
Page 284 18. NAVIGATION SENSORS Speed used by the system is shown at the top-right position on the chart display.The figure below shows the source of water speed is used for drift calculation. Selected and Water Stabilization Manual set drift exists Speed Manual speed Mode Selected Manual...
Page 285: Switching Of Sensor And Indication
18. NAVIGATION SENSORS 18.6 Switching of Sensor and Indication When a sensor cannot be used because of some problem, the system automatically switches the sensor. When this occurs the name of the newly selected sensor appears in yellow. Speed sensor changed 18.7 Filter Status...
Page 286 18. NAVIGATION SENSORS Note: The integrity results appear in the [Local Sensor Setting] and [System Sensor Setting] menus only if the menu item [Color of own ship’s information(TEXT) will be changed by result of integrity check] is checked during installation. Passed: Data is available for comparison and data is normal.
Page 287: Position Alignment
18. NAVIGATION SENSORS • [Excluded] (automatically excluded sensor) The [Integrity] column indicates sensor integrity as either [Passed] or [Failed]. The in- tegrity evaluation is [Doubtful] when there are no other sensors to compare with. The [Comparisons] column shows the sensors compared and the integrity evaluation of compared sensors in parentheses.
Page 288: How To Cancel Position Alignment
18. NAVIGATION SENSORS 18.8.2 How to cancel position alignment Click the [Offset] button to cancel the position offset. 18.9 Wind Sensor ECDIS can display and output wind data in the following three formats: Apparent: Windmeter-measured wind speed and direction. Wind angle reference: Heading North: True wind angle, true wind speed, referenced to North Wind angle reference: True North Theoretical: True wind angle, true wind speed, referenced to heading...
Page 289: 18.10 Depth Sensor
18. NAVIGATION SENSORS Apparent, North (true wind referenced to North), Theoretical (true wind referenced to heading) may be selected from the [Other Sensor Settings] menu. If the wind indica- tion is not accurate; for example, the wind is blowing from the North but the wind di- rection displays otherwise, check if the format is Theoretical.
Page 290 18. NAVIGATION SENSORS This page is intentionally left blank. 18-14...
Page 291: Recording, Playback Functions
19. RECORDING, PLAYBACK FUNC- TIONS The ECDIS records various items during a voyage, like movement and position of your ship and dangerous radar targets (from the radar). These items are recorded in the following logs: Update log: Records the install and update history for the ENC, ARCS and C-MAP charts (see section 7.3).
Page 292: Position Events
19. RECORDING, PLAYBACK FUNCTIONS 19.1.2 Position events The purpose of a position event is to record current position data to the [Voyage] log. Position events can be shown in the chart area by checking [Positions] on the [Track- ing] page of the [Symbol Display] menu. Do as shown below to record position events. How to record position events 1.
Page 293 19. RECORDING, PLAYBACK FUNCTIONS 5. If you selected [Manual] at step 3, enter latitude and longitude position and com- ment (optional), then click the [Record] button. Manually entered Enter comment position here. The [Position Event] window shows the position at 1044 the moment the [Record] button is clicked.
Page 294 19. RECORDING, PLAYBACK FUNCTIONS timestamp on the chart. The method of transfer may be selected in the bottom of the dialog. Transfer to latest transfers the measurements as if they were all made at the time of the newest measurement. Continuous transfer transfers all measurements to real time.
Page 295: Details Log
19. RECORDING, PLAYBACK FUNCTIONS 19.2 Details Log The [Details] log contains various voyage information, recorded once per minute. • Date of entry • Time of entry • Source: No. of unit which generated log • Type: Type of position data •...
Page 296: Voyage Log
19. RECORDING, PLAYBACK FUNCTIONS 19.3 Voyage Log The [Voyage] log records all voyage-related data of the past three months. Recorded events are: • Date: Date of entry • Time: Time of entry • Type: Log entry types • Auto: Automatic entry of ship position, in 1 to 4 hr intervals, set by operator. •...
Page 297: How To Set Conditions For Voyage Logging
19. RECORDING, PLAYBACK FUNCTIONS How to view the Voyage log On the InstantAccess bar™, click the [Log], [NAV Log] and [Voyage] buttons on the InstantAccess bar™. LO O G1 Export File • To show the logs of a specific period, enter the period to show with [Period Cov- ered (UTC)] then click the [Set Period] button.
Page 298: Chart Usage Log
19. RECORDING, PLAYBACK FUNCTIONS 19.4 Chart Usage Log The [Chart Usage] log stores which charts were used on the ECDIS display. To open the log, click [Log], [NAV Log] and [Chart Usage] on the InstantAccess bar™. The fol- lowing information is recorded in the chart usage log: •...
Page 299: Danger Targets Log
19. RECORDING, PLAYBACK FUNCTIONS 19.5 Danger Targets Log The [Danger Targets] log stores information about dangerous targets (CPA/TCPA alarm) that are received from a radar (TTs) and/or AIS targets received from an AIS transponder. If a TT or AIS target is within the set CPA (Closest Point of Approach) and TCPA (Time to CPA), information of all TTs (including non-dangerous targets) are recorded into the danger target log.
Page 300: How To Filter The Danger Targets Log
19. RECORDING, PLAYBACK FUNCTIONS 19.5.1 How to filter the danger targets log You can filter the danger targets log by CPA or TCPA. When a TT or AIS target’s CPA or TCPA is lower than the setting here, the target’s details are automatically logged. To set the filter, do the following: 1.
Page 301: Route Transfer Log
19. RECORDING, PLAYBACK FUNCTIONS 19.6 Route Transfer Log The [Route Transfer] log keeps a tab of sent and received route-related communica- tions. When one or more of the following conditions are met, an entry is made in the [Route Transfer] log. •...
Page 302: How To Playback The Log
19. RECORDING, PLAYBACK FUNCTIONS 19.7 How to Playback the Log The log can be played back to check ship’s movements within a given time frame. If an AMS is connected, deactivate it to enable playback. Cautions for data recording, playback •...
Page 303 19. RECORDING, PLAYBACK FUNCTIONS • The [Select] button selects a file. Playback is stopped and a message asks if you are sure to select a different file. 14:46 05 Mar 2014 14:54 05 Mar 2014 Select button (Select different file to playback.) Time 05 Mar 2014 elapsed...
Page 304 19. RECORDING, PLAYBACK FUNCTIONS This page is intentionally left blank. 19-14...
Page 305: 20. Alerts
20. ALERTS 20.1 What is an Alert? "Alert" is a generic name for a notice to any unusual or potentially dangerous situation generated within the system. Alerts are classified according to priority and category. Alert priority There are four alert priorities: emergency*, alarm, warning and caution. * Generated when this ECDIS is connected to the optional AMS (Alert Management System).
Page 306: Alert Box
20. ALERTS 20.2 Alert Box When an alert is generated, the related alert message and alert state icon appear in the [Alert] box, which is at the bottom right corner on the screen. An audible alarm is additionally generated for emergencies, alarms and warnings. In addition to the alert message and alert state icon, the [Alert] box provides access to the [Alert List] and [Alert Log].
Page 307 20. ALERTS Alert message display format Priority of Display state Alert indication Alert state alert Emergency, - Not acknowledged, Not rectified. Black characters on red Alarm background. Off Track Alarm - Not acknowledged, Rectified. (Flashing) Displayed alternately Red characters on gray background.
Page 308 20. ALERTS Alert state icons The table shows the icons used to indicate the different alert states for the emergency, alarm, warning and caution alerts. Icon Alert state Description Emergency, Alarm alert Active - unacknowledged alarm Red triangle with black loudspeaker in center of triangle.
Page 309: How To Temporarily Silence The Buzzer For An Alarm Or Warning
20. ALERTS 20.3 How to Temporarily Silence the Buzzer for an Alarm or Warning When the buzzer for an Emergency, Alarm or Warning sounds, you can temporarily silence it by clicking the [Silence] button in the [Alert] list. The buzzer stops, however, the alert message remains in the [Alert] box and [Alert] list until acknowledged and rectified.
Page 310: Alert List
20. ALERTS 20.5 Alert List The [Alert List] displays all active alerts, with unacknowledged alerts at the top, in pri- ority order. To display the list, right-click the [Alert List/Alert Log] button in the [Alert] box then select [Alert List]. The ZDA sentence is required to display the time in the list. The list shows •...
Page 311: Alert Log
20. ALERTS The [Silence] button silences the buzzer. The [Aggregation] window can be shown by clicking an aggregate icon. The window can also be opened by clicking an aggregate icon in the [Alert] box. Unacknowledged aggregate alerts can be acknowledged by clicking the [ACK] button. Aggregate Aggregate ACK button...
Page 312: Alert Reception From Connected Sensors
20. ALERTS You can select what priority and category of alerts to display with the [Priority] and [Category] filters at the top of the list. The log can be sorted by [Priority], [Cat.], [De- scription] or [Occurred Time]. Click the corresponding column title to sort accordingly. To search the log, enter text in the [Log Search] box then click the [Find] button.
Page 313: List Of Alerts
20. ALERTS 20.8 List of Alerts The table below lists the possible alerts for this radar. Each alert is listed with priority, category and escalation. This radar can output alerts in ALF or ALR format. The alert number for each depends on the output format and may differ. Alert which are not acknowledge within the set time limit are escalated to either Alarm level, or are repeated as a warning.
Page 314 20. ALERTS Aggregated Alert Priority/ Alert name Escalation name Category Inst.* Crossing Special Submarine Transit Warning/ Repeated warning Area Lane Anchorage Area Marine Farm/ Aquaculture PSSA Area Areas to be Avoid- Buoy WPT Approach WPT Approach Warning/ Repeated warning Datum Mismatch EPFS1 Invalid/ Warning/ Repeated warning...
Page 315 20. ALERTS Aggregated Alert Priority/ Alert name Escalation name Category Inst.* 30001 HW Status Notice Main Monitor Fan4 Caution/B Rotation Speed Lowering 30001 Sub Monitor Fan1 Rotation Speed Lowering 30001 Sub Monitor Fan2 Rotation Speed Lowering 30001 Sub Monitor Fan3 Rotation Speed Lowering 30001...
Page 316 20. ALERTS Aggregated Alert Priority/ Alert name Escalation name Category Inst.* 30001 HW Status Notice Processor Unit Caution/B Fan2 Rotation Speed Lowering 30001 Processor Unit Fan3 Rotation Speed Lowering 30001 Processor Unit CPU board Battery Power Error 30001 Processor Unit CPU board Core Power Error 30001...
Page 317 20. ALERTS Aggregated Alert Priority/ Alert name Escalation name Category Inst.* 30002 HW Status Abnor- Processor Unit Warning/ Repeated Warning Fan1 Fan No Rota- tion 30002 Processor Unit Fan2 Fan No Rota- tion 30002 Processor Unit Fan3 Fan No Rota- tion 30002 Processor Unit...
Page 318 20. ALERTS Aggregated Alert Priority/ Alert name Escalation name Category Inst.* 30300 Network COM Tim- Sensor Adapter 2 Caution/B eout COM Timeout 30300 Sensor Adapter 3 COM Timeout 30300 Sensor Adapter 4 COM Timeout 30300 Sensor Adapter 5 COM Timeout 30300 Sensor Adapter 6 COM Timeout...
Page 319 20. ALERTS Aggregated Alert Priority/ Alert name Escalation name Category Inst.* 30400 CCRS COM Error EPFS 6 COM Error Caution/B 30400 EPFS 7 COM Error 30400 EPFS 8 COM Error 30400 EPFS 9 COM Error 30400 EPFS 10 COM Er- 30400 SDME 1 COM Er- 30400...
Page 320 20. ALERTS Aggregated Alert Priority/ Alert name Escalation name Category Inst.* 30400 CCRS COM Error Other Sensor 6 Caution/B COM Error 30400 Other Sensor 7 COM Error 30400 Other Sensor 8 COM Error 30400 Other Sensor 9 COM Error 30400 Other Sensor 10 COM Error 30400...
Page 321 20. ALERTS Aggregated Alert Priority/ Alert name Escalation name Category Inst.* 30431 HUB-3000 LinkUP HUB-3000 LinkUP Warning/ Repeated warning Error Error 30450 Double Gyro Sta- Double Gyro Sta- Warning/ Repeated warning tus Conflict tus Conflict 30500 Sensor Banned EPFS 1 Sensor Caution/B Banned 30500...
Page 322 20. ALERTS Aggregated Alert Priority/ Alert name Escalation name Category Inst.* 30510 No Filter Source of No Filter Source of Warning/ Repeated warning Sensor Data CTW/STW 30510 No Filter Source of Heading 30510 No Filter Source of 30520 Drift comp error Drift comp error Warning/ Escalated to Alarm...
Page 323 20. ALERTS Aggregated Alert Priority/ Alert name Escalation name Category Inst.* 30800 RM Stop RM Stop - Exceed Alarm/A Max XTD 30800 RM Stop - Sensor lost 30800 RM Stop - Internal Error 30801 Depth Limit Depth Limit Alarm/A 30802 Anchor Watch Anchor Watch Warning/...
Page 324 20. ALERTS This page is intentionally left blank. 20-20...
Page 325: 21. Parameters
21. PARAMETERS 21.1 Ship and Route Parameters The purpose of the ship and route parameters is set the basic parameters for the ship. These parameters are relative to ship steering and they are very important to get cor- rect function of the integrated navigation system. They must be maintained carefully. Modification requires a good knowledge of the parameters' importance.
Page 326: Forwarding Distances
However, the operator can view the forwarding distances settings on the [For- warding Distance] display ([MENU][General][Navigation Parameter]). Note: These are the port side values. Starboard side values can also be shown. Con- tact a FURUNO dealer for details. 21-2...
Page 327: Cost Parameters
21. PARAMETERS 21.3 Cost Parameters The cost parameters are used in the optimization calculation. Therefore define these parameters before doing the calculation. Open the menu and select [Cost Parameters] from the [General] menu to show the [Cost Parameters] page. Set each item according to ship’s plan, etc. At the [Cost] window, enter the cost/hour and cost/ton for heavy fuel oil and diesel oil.
Page 328: Instant Track Parameters
21. PARAMETERS 21.4 Instant Track Parameters The instant track feature can create, in route monitoring, a simple route in the following situations: • Return to the monitored route when the vessel goes outside the channel limits. • Temporarily deviate from the monitored route (avoid collision, etc.). How to set instant track parameters Set the parameters for the instant track ([MENU][General][Ship &...
Page 329: 22. Conning Displays
22. CONNING DISPLAYS 22.1 Main Conning Display The main conning display provides relevant sensor information data (including engine data) from external equipment, on one display to facilitate safe and efficient monitor- ing. The ECDIS accepts sensor information data in analog, serial and contact signal formats.
Page 330 22. CONNING DISPLAYS Conning display Status bar SILENT Button Description Display mode Selects the display mode. See section 2.2. Conning display Selects the conning display sheet to use, Sheet.1 - Sheet.6. (Sheet name sheet is decided at installation. “Sheet x” (x=sheet number) is the default sheet name.) SILENT Goes to the Silent mode.
Page 331: Conning Display Examples
22. CONNING DISPLAYS 22.2 Conning Display Examples Six conning display sheets are available, and the content, layout and name of each sheet can be customized, by the service technician. Below are some examples con- ning display sheets. Example 1 (General navigation) Example 2 (General navigation) 22-3...
Page 332 22. CONNING DISPLAYS Example 3 (General navigation) Example 4 (General Navigation) 22-4...
Page 333 22. CONNING DISPLAYS Example 5 (All waters, navigation) Silence Example 6 (All waters, harbor) 27 May 2016 Silence 22-5...
Page 334 22. CONNING DISPLAYS Example 7 (Ocean, navigation) 27 May 2016 Silence Example 8 (Ocean, harbor) 27 May 2016 Silence 22-6...
Page 335 22. CONNING DISPLAYS Example 9 (Offshore Service Vessel, Fore 1) Silence Example 10 (Offshore Service Vessel, Fore 2) 27 May 2016 Silence 22-7...
Page 336 22. CONNING DISPLAYS Example 11 (Offshore Service Vessel, Aft1) Silence Example 12 (Offshore Service Vessel, Aft2) 27 May 2016 Silence 22-8...
Page 337: Mini Conning Display
22. CONNING DISPLAYS 22.3 Mini Conning Display The mini conning display, available in the Voyage navigation mode, provides various navigation information and is set during the installation. The display example below shows heading, doppler log speed and rudder angle. To show or hide the mini conning display, click the [Mini Conning] button on the InstantAccess bar™.
Page 338: Side Conning Display (Landscape Monitor Only)
22. CONNING DISPLAYS 22.4 Side Conning Display (landscape monitor only) With the landscape monitor, the side conning display can be shown in the information area, in the radar mode. The presence or absence of the display is determined during the installation. Four side conning sheets are preset during the installation according to expected us- age, possible navigation conditions, etc.
Page 339: 23. Settings Menu
23. SETTINGS MENU The [Settings] menu provides file import, export and maintenance, testing facilities (display, keyboard, self test), data sharing, customizing, screenshot processing, user default restoration, and CCRP selection. 23.1 How to Access the Settings Menu Click the Settings button ( ) on the Sta- tus bar then select [Settings].
Page 340: File Export
23. SETTINGS MENU 23.2 File Export The [File Export] page exports setting data, route/user charts, and playback data*, to a USB flash memory. Data is exported in .zip files. * Disable AMS to enable export. Playback data Name Description Data selection Check the data to export;...
Page 341: File Import
23. SETTINGS MENU 23.3 File Import The [File Import] page lets you import FMD-3xx0 series created setting data, routes/ user charts, and playback data*, from a USB flash memory. .*Disable AMS to enable import. Playback data Name Description Select file to import Click to show the [OPEN FILE] dialog box, where you can button select the file to import.
Page 342: File Maintenance
23. SETTINGS MENU 23.4 File Maintenance The [File Maintenance] page lets you restore the last-saved route/user chart applica- tion and Route/user chart system. Name Description Route/User chart Check to restore last-saved route/user chart application. Application backup Route/User chart Check to restore last-saved route/user chart system. System backup [Restore] button Click to restore item selected.
Page 343: Alert Setting
23. SETTINGS MENU 23.5 Alert Setting The [Alert Setting] page sets how long to wait before the priority of an alert is raised to Warning or Alarm, when the alert goes unacknowledged. Click the [Escalation Setting] button to show the escalation settings. Alerts can be escalated to alarm level or re- peated as a warning.
Page 344 23. SETTINGS MENU Name Description Page selection Select alert page. : Go to first page; : Go to previous page buttons : Go to last page; : Go to next page [Save] button * Save settings. [CANCEL] Cancel settings and restore all previous settings. button * [DEFAULT] but- Restore factory settings.
Page 345: Self Test
23. SETTINGS MENU 23.6 Self Test The [Self Test] page is mainly used to check the equipment. The ECDIS function is inoperative during the test. [Processor Unit] ECDIS Software Version: 2450074-xx.xx COMMON Software Version: 2450077-xx.xx [Monitor1] Software Version: FW100001-0A00 : Version numbers subject to change. Name Description Test results, program...
Page 346: Data Sharing
23. SETTINGS MENU 23.7 Data Sharing The [Data Sharing] page shares the same brilliance setting between main and slave displays (ECDIS and conning applications). 23-8...
Page 347: Customize
23. SETTINGS MENU 23.8 Customize The [Customize] page lets you set buzzer volume, key beep volume, and scrollwheel rotation direction. Name Description Wheel rotation Set the direction of scrollwheel rotation direction. Normal: Downward to increase value, upward to decrease value. Reverse: Reverse of "Normal".
Page 348: Display Test
23. SETTINGS MENU 23.9 Display Test The [Display Test] page displays various test patterns to check the monitor for proper display of colors. Click the [Display Test] button to start the test. The buzzer sounds at the start of the test. Self Test Data Sharing Left-click to proceed in the numerical order shown below;...
Page 349: 23.10 Keyboard Test
23. SETTINGS MENU 23.10 Keyboard Test The [Keyboard Test] page checks the controls and keys on the ECDIS Control Unit and the trackball module on the ECDIS Control Unit and Trackball Control Unit. Data Sharing Customize Display Test Keyboard Test Name Description EBL, BRILL, GAIN and...
Page 350 23. SETTINGS MENU Name Description Trackball module Check the trackball module of a Control Unit: 1) Spin the scrollwheel and rotate the track- ball. The indication above the operated control shows the setting value. 2) Push each button. The window above a pushed button lights in light blue.
Page 351: 23.11 Screenshots
23. SETTINGS MENU 23.11 Screenshots The [Screenshot] page processes screenshots saved to the SSD. Name Description List List of screenshots taken. Screenshots are automatically assigned a file name consisting of the time and date the screenshot was taken. Check boxes Put a checkmark in the box of the screenshot to process.
Page 352: 1How To Export Screenshots
23. SETTINGS MENU 23.11.1 How to export screenshots You can export screenshots to a USB flash memory as follows: 1. Insert a USB flash memory in the USB port on the Control Unit. 2. Open the [Screenshot] page. 3. Put a checkmark in the checkbox of the screenshot(s) to export. 4.
Page 353: 23.12 User Default
23. SETTINGS MENU 23.12 User Default The [User Default] page restores all default settings for the [Chart Display] and [Sym- bol Display]. Click the [Restore User Setting] button. You are asked "All setting data will be restored to the default. Do you wish to continue?" appears. Click the [Yes] but- ton to restore default settings and reset the power.
Page 354: 23.13 Ccrp
23. SETTINGS MENU 23.13 CCRP The [CCRP] page provides for selection of CCRP (Consistent Common Reference Point) and shows the location of various sensors. Name Description CCRP Select the CCRP to use in the case of multiple CCRPs. Anchor Enter anchor installation position (X and Y values from CCRP).
Page 355: Maintenance And Troubleshooting
24. MAINTENANCE AND TROUBLE- SHOOTING Periodic checks and maintenance are important for proper operation of any electronic system. This chapter contains maintenance and troubleshooting instructions to keep optimum performance and the longest possible life of the equipment. Before attempt- ing any maintenance or troubleshooting procedure please review the safety informa- tion below.
Page 356: How To Replace The Fuse
24. MAINTENANCE AND TROUBLESHOOTING 24.2 How to Replace the Fuse The fuse in the Processor Unit, Monitor Unit and Sensor Adapter protects those units from overvoltage (overcurrent) and internal fault. If a unit cannot be turned on, check if its fuse has blown. If a fuse has blown, find out the cause before replacing the fuse. If the fuse blows again after replacement, contact your dealer for advice.
Page 357: How To Clean The Filter In The Processor Unit
24. MAINTENANCE AND TROUBLESHOOTING swab regularly so that dirt and dust build-up is easily removed. Use a dry swab to wipe away moisture. Swab Lens Supports Retaining ring - inner side Trackball housing 5. Re-set the ball and retaining ring. Be sure the retaining ring is not inserted re- versely.
Page 358: Troubleshooting
“There is • dongle is not connected. • Connect dongle. no dongle or an error • data in the dongle is corrupted. • Contact FURUNO for assistance. has occurred in the dongle. The system will automatically shut down.” appears monitored route is •...
Page 359 24. MAINTENANCE AND TROUBLESHOOTING If… then… Remedy ENC chart cannot be • no ENC chart for area. • Open ENC chart from [Manage displayed Charts] dialog box. • dongle is not connected. • Connect dongle. past track is not • past track is not selected to be vis- •...
Page 360: Consumable Parts
24. MAINTENANCE AND TROUBLESHOOTING 24.6 Consumable Parts The table below lists the consumable parts in the Processor Unit, Sensor Adapters and Monitor Units. Replace the parts before their expected expirations. Unit Part Type Life Processor Unit CPU Fan KTA-555-01 8.5 years EC-3000 Power Fan 109P0612H761...
Page 361: Color Differentiation Test For S57 Charts
24. MAINTENANCE AND TROUBLESHOOTING 24.7 Color Differentiation Test for S57 Charts The color differentiation checks if the ECDIS monitor can distinguish between the var- ious color-coded areas, lines and symbols. 1. Click the [Chart INFO] and [Chart 1] buttons on the InstantAccess bar™ to show the [ECDIS Chart 1] menu.
Page 362 24. MAINTENANCE AND TROUBLESHOOTING This page is intentionally left blank. 24-8...
Page 363: Alert Management System (Option)
25. ALERT MANAGEMENT SYSTEM (option) 25.1 What is an Alert Management System (AMS)? An AMS warns the navigator, with audio-visual indications, when safety parameters are violated or there is a failure of connected equipment. The AMS also transfers un- acknowledged Alarm level alerts to the BNWAS. The main functions of the AMS are •...
Page 364 25. ALERT MANAGEMENT SYSTEM (option) Category of alerts Each alert is further put into category A, category B, or category C. Category Description of alert Category A Category A alerts, which must acknowledged at the unit generating the alert, are as follows •...
Page 365: Alert Category And Alert Acknowledgement From Connected Equipment, Ams
25. ALERT MANAGEMENT SYSTEM (option) 25.4 Alert Category and Alert Acknowledgement From Connected Equipment, AMS Category A alert Acknowledged from the equipment that generated the alert: The alert is acknowl- edged at both the equipment and the AMS and their buzzers stop. Category B alert Acknowledged from the equipment that generated the alert: The alert is acknowl- edged at the equipment and the buzzer is temporarily silenced.
Page 366: Alert-Related Sentences
25. ALERT MANAGEMENT SYSTEM (option) 25.6 Alert-related Sentences 25.6.1 ACK/ALR sentences Overview of alert acknowledgment flow The function of the AMS is to coordinate exchange of alerts and acknowledgement of alerts between equipment connected to the AMS. This AMS is designed according to the IEC’s recommendations for Alert Handling (80/ 520/INF).
Page 367: Acn/Alc/Alf/Arc/Hbt Sentences
25. ALERT MANAGEMENT SYSTEM (option) No-alerts message The no-alerts message to informs the AMS that the sensor has no active alerts. It is sent at an interval not greater than 60 seconds, and may be used to clear the AMS alert list.
Page 368 25. ALERT MANAGEMENT SYSTEM (option) HBT sentence Both external equipment and the AMS output the HBT sentence periodically to confirm normal operation between each other. The sentence is output regardless of whether an alert is generated or not. External External Equipment Equipment When the HBT sentence is not received within the interval set, an appropriate alert is...
Page 369 ACN sentence, a category A or cat- egory C alert cannot be acknowledged at the external equipment. The external equipment sends the ARC sentence. In some cases, acknowledgement is refused. (FURUNO devices output the ARC sentence.) (ARC) External...
Page 370: How An Alarm Is Transferred To The Bnwas
25. ALERT MANAGEMENT SYSTEM (option) 25.7 How an Alarm is Transferred to the BNWAS Alarms are transferred to the BNWAS in the following sequence. Note: For a DNV class vessel, only category A Alarms are transferred. 1) An Alarm generated by an equipment connected to the AMS is transferred to the BNWAS if it is not acknowledged within 30 seconds.
Page 371: Change Of Priority For Unacknowledged Warning
25. ALERT MANAGEMENT SYSTEM (option) 25.8 Change of Priority for Unacknowledged Warning IMO MSC302(87) requires that a Warning be changed to an Alarm if it is not acknowl- edged within 60 seconds*. For how to change priority, see section 23.5. *60 seconds is the standard timeout.
Page 372: 25.11 Alert Priority, Alert State
25. ALERT MANAGEMENT SYSTEM (option) IEC 62288 Ed.2 buzzer pattern This buzzer complies with INS regulations. There are two types of buzzer patterns, Emergency/Alarm and Warning. Emergency/Alarm: The buzzer sounds three times in 7-second intervals. Emergency/Alarm generated. 7 seconds Buzzer ON Buzzer muted Time Buzzer OFF...
Page 373: 25.12 Aggregated Alert
25.12 Aggregated Alert MSC302(87) requires the use of the “aggregated alert,” which groups multiple similar alerts. The illustration below shows the grouping possible with the FURUNO AMS. Grouped alerts can be collectively temporarily silenced. Grouping of similar alerts with a single sensor...
Page 374: 25.13 Responsibility Transfer Alert
25. ALERT MANAGEMENT SYSTEM (option) 25.13 Responsibility Transfer Alert MSC302(87) requires the use of the “responsibility transfer alert,” which functions in the multiple sensor, multiple equipment installation. When one sensor or one equip- ment fails but does not disturb the system operation (other sensor or equipment is nor- mal), the AMS automatically sends the “responsibility transfer alert”...
Page 375: 25.14 Backup Configuration
25. ALERT MANAGEMENT SYSTEM (option) 25.14 Backup Configuration The FURUNO AMS supports backup configuration. The following configuration is pos- sible. Master AMS: 1 set Backup AMS: 4 sets Alert information is controlled by the Master AMS. The Master AMS distributes alert information to Backup AMS via the network to share alerts among all AMS.
Page 376 25. ALERT MANAGEMENT SYSTEM (option) After synching alert information Return to master Return to backup Backup Backup Backup Backup Main No.1 No.3 No.4 No.2 Synchronize alert status information 25-14...
Page 377: 25.15 Alert And Alert-Related Icons
25. ALERT MANAGEMENT SYSTEM (option) 25.15 Alert and Alert-related Icons The table below shows all the alert and alert-related icons that may appear in the AMS mode windows (see paragraph 25.16.2). The numbers in the left-hand column are the icon numbers, which are referenced in several of the icon descriptions in the table. Icon Alert state Description...
Page 378: 25.16 Ams Mode Operations
25. ALERT MANAGEMENT SYSTEM (option) 25.16 AMS Mode Operations 25.16.1 How to select the AMS mode Select [AMS] with the Display mode button (the leftmost button on the Status bar) to activate the AMS mode. The configuration of the button depends on the monitor con- figuration.
Page 379 25. ALERT MANAGEMENT SYSTEM (option) ACTIVE ALERT window The [ACTIVE ALERT] window shows the status of all active alerts. A maximum of 20 alerts is shown per page. When there are more than 20 active alerts, a new page is created to hold the new alerts.
Page 380 25. ALERT MANAGEMENT SYSTEM (option) Item name Description Contact signal transfer "Transfering" is shown during alert transfer. status [], [] These buttons appears when there are more than 20 alerts. The (page selection buttons) buttons are greyed out if there is only one page of alerts. : Go to first page;...
Page 381 25. ALERT MANAGEMENT SYSTEM (option) ALERT LOG window The [ALERT LOG] window provides a comprehensive list of generated alerts. Item name Description Current Alert box This box shows the name of the active alert that has the highest priority. You can acknowledge the alert by clicking the box. Priority Filter the list by the alert priority;...
Page 382 25. ALERT MANAGEMENT SYSTEM (option) ALERT LIST window The [ALERT LIST] window is a context-based list of generated alerts, providing alert sources and aggregation. Alert sources are Navigation, Communication and External. To show alert source or aggregation, click the [Alert Source] or [Aggregation] tab, re- spectively.
Page 383 25. ALERT MANAGEMENT SYSTEM (option) Aggregation tab Item name Description Current Alert box This box shows the name of the active alert(s), in order of pri- ority.The box can be clicked to acknowledge alerts. Alert Source tab, Aggre- Double click tab to show associated data. gation tab Aggregate list Click to show aggregate list.
Page 384 25. ALERT MANAGEMENT SYSTEM (option) This page is intentionally left blank. 25-22...
Page 385: 26. Autopilot Operations
26. AUTOPILOT OPERATIONS This chapter covers the type approval testing for the following autopilots: • Type Approval TC-3000 (IEC 62065 Ed. 1.): EMRI FAP-2000, EMRI FAP-3000, TOKYO KEIKI PR-6000, YOKOGAWA PT-500A • Type Approval TC-3001 (IEC 62065 Ed. 2.): EMRI FAP-3000, TOKYO KEIKI PR-9000, YOKOGAWA PT-900 26.1 Configuration...
Page 386: Controls
26. AUTOPILOT OPERATIONS 26.2 Controls 26.2.1 EMRI FAP-2000 Control Panel FURUNO GYRO ALARM LIGHT MEDIUM RESET LOADED MANUAL ECONOMY SPEED MEDIUM PRECISE OFF COURSE ON LIMIT FUNC. HEADING SETUP ROUTE TRACK TURN RUD.LIMIT DEG. SPEED KNOTS HEADING RAD. ROT. READY N.M.
Page 387 26. AUTOPILOT OPERATIONS Status indicator - Shows selected mode and state of readiness: • ROUTE: FAP-2000 route steering • TRACK: FAP-2000 control mode • TURN: FAP-2000 track controlled turn • HEADING: FAP-2000 control mode • READY: FAP-2000 in operation Alert indicator and buzzer control: •...
Page 388: Emri Fap-3000
26. AUTOPILOT OPERATIONS 26.2.2 EMRI FAP-3000 Steering Control Unit Description PROGRAM NEXT button: Shows next heading, next course, next radius, next rudder limit field. CALL REMOTE CTRL button: Initiates integrated control with external navigation equipment (ECDIS, etc.) CALL COURSE CTRL button: Heading-controlled course change using set radius CALL HEADING CTRL button: Immediate heading-controlled course change using set rud- der angle limit.
Page 389: Tokyo Keiki Pr-6000
26. AUTOPILOT OPERATIONS 26.2.3 TOKYO KEIKI PR-6000 Steering Control Unit 1: Mode selection unit 11: Repeater switch 2: Mode selection switch 12: Helm unit 3: Non-follow-up unit 13: Steering wheel 4: Non-follow-up steering lever 14: System selection unit 5: Auto steering control knobs 15: System selection switch 6: HCS unit (see next page) 16: Order rudder angle indicator...
Page 390 26. AUTOPILOT OPERATIONS Bar graph Steering Power System Bar graph display selection Data selection mode indicator indicator indicator indicator Data display Data display indicator No.1 AUTO SET COURSE Group display alarm Rudder limit indicator angle indicator Individual alarm HCS Unit indicator Beneath lid ADPT control (course-keeping mode, OPN, CNF)
Page 391 26. AUTOPILOT OPERATIONS PILOT WATCH control: Set the amount of course deviation to allow in automatic steering. An alert is generated at the Autopilot when the deviation is more than the val- ue set. RUDDER LIMIT control: Limit the rudder motion to the least necessary rudder angle during AUTO steering.
Page 392 26. AUTOPILOT OPERATIONS FU Override NFU Controller Starting steering override: 1) Confirm that the Ready lamp in the NFU controller is ON. Override steering 2) Pull out the pin stopper inserted lever in the override NFU controller and turn the lever to the desired direction.
Page 393: Tokyo Keiki Pr-9000
26. AUTOPILOT OPERATIONS 26.2.4 TOKYO KEIKI PR-9000 Heading Control Unit (HCU) Description ALARM lamp: Flashes (red) or lights when the HCU receives an alarm. POWER lamp: Lights (green) when the HCU starts. HDG key: Select the heading sensor used for steering. TC/HC key: Switch between the TC and HC modes, in automatic steering.
Page 394: Yokogawa Pt-500A
26. AUTOPILOT OPERATIONS 26.2.5 YOKOGAWA PT-500A Steering Control Unit Control Description Steering Repeater Compass Shows heading. Heading Steering Dial Rotate to set heading. Auto Steering Unit Provides controls for automatic steering functions. Steering Mode Selector Select NAVI, AUTO, HAND, or RC (Remote Control) steering mode.
Page 395: Yokogawa Pt-900
26. AUTOPILOT OPERATIONS 26.2.6 YOKOGAWA PT-900 Upper Panel Control, item name Description Mode Selector Select the mode, MAN(HAND) or AUTO. Select AUTO to start track control. Non-Follow-Up Steering Lever Steers the rudder in the direction selected, port or star- board. System Selector Switch Selects the system to use: OFF, FU-1 (No.1 operating system), FU-2 (No.2 operating system, NFU (Non-follow-...
Page 396 26. AUTOPILOT OPERATIONS AP CDU Control, item name Description LCD & Touch Panel Shows various autopilot data. Course Setting Dial Press and turn this control to set heading/course. HOME key Go to the home screen. SELECT key Selects, deselects this unit. The LED (green) lights when this unit is selected.
Page 397: Steering Modes
26. AUTOPILOT OPERATIONS 26.3 Steering Modes 26.3.1 EMRI FAP-2000, FAP-3000 The FAP-2000, FAP-3000 receives position, heading and speed data, compares them with the track section to be steered, and applies that information to calculate and com- mand the necessary rudder angle. Hand (manual) steering modes The following hand steering modes are available without the autopilot: Steering wheel, Wing steering control, and Override tiller.
Page 398: Tokyo Keiki Pr-6000, Yokogawa Pt-500A, Pt-900
26. AUTOPILOT OPERATIONS 26.3.2 TOKYO KEIKI PR-6000, YOKOGAWA PT-500A, PT-900 Steering functions are available when the ECDIS system is connected to the Autopilot. To use a steering mode, set your Autopilot’s system selection switch to the FU-1 or FU-2 (PT-500A, PT-900), No.1 or No.2 (PR-6000) position. PR-6000: No.1, No.2 position PT-500A, PT-900: FU-1, FU-2 (Follow Up) position Hand (manual) steering mode (Mode selector: HAND)
Page 399 26. AUTOPILOT OPERATIONS Non-follow-up steering mode (Mode selector: NFU) (PR-6000) The operator sets the steering mode selector to NFU and steers with the Non-Follow- Up lever. While in the NFU steering mode the ECDIS system displays both the rudder angle and the steering mode. Remote hand steering mode (Mode selector: RC) (PR-6000) When the Mode selection switch mode is Steering mode...
Page 400: Tokyo Keiki Pr-9000
26. AUTOPILOT OPERATIONS 26.3.3 TOKYO KEIKI PR-9000 The PR-9000 receives position, heading and speed data, compares them with the track section to be steered, and applies that information to calculate and command the necessary rudder angle. Hand (manual) steering mode Manual steering by UID (User Input Device).
Page 401 26. AUTOPILOT OPERATIONS Summary of autopilot steering modes (FAP-2000, FAP-3000) Program Heading Radius Program Item Heading Control Control Track Change Set heading Set radius Radius control Design before execution Wind, current, etc. compensation Needs a gyrocompass Needs a log Needs precise position-fixing equipment Needs direct SOG/COG sensor 26-17...
Page 402: Track Control Functions At The Ecdis
26. AUTOPILOT OPERATIONS 26.4 Track Control Functions at the ECDIS Track control functions are available in the Voyage navigation mode. Click the [NAVI] button to get into this mode. [Track Control Status] Preconditions for Track Control Start are missing: AP connection error. [Route Information] TCS buttons [Track Control Status] window...
Page 403: How To Select The Ecdis To Control The Autopilot
26. AUTOPILOT OPERATIONS 26.5 How to Select the ECDIS to Control the Autopilot If the ship has more than one ECDIS, you can select the ECDIS to control the Autopi- lot. The ECDIS are connected to the Autopilot via a hardware switch to permit manual switching of the ECDIS.
Page 404: How To Activate, Deactivate The Track Control System (Tcs) From The Ecdis
26. AUTOPILOT OPERATIONS 26.6 How to Activate, Deactivate the Track Control System (TCS) from the ECDIS 26.6.1 How to activate the TCS The TCS cannot be activated if the route steering preconditions have not been met. A related alert and status message appear on the ECDIS. See section 26.7.2 for the status messages.
Page 405: Route Steering Related Indications, Alerts And Messages Generated By Ecdis
26. AUTOPILOT OPERATIONS 26.7 Route Steering Related Indications, Alerts and Messages Generated by ECDIS 26.7.1 Route steering related information in Route Information box The route steering indications shown depends on the autopilot connected. See the fig- ure and table below for the route steering indications. Route: Scenario4 Route: Scenario4 Route: Scenario4...
Page 406: Alerts And Messages When Precondition For Route Steering Are Not Complete
26. AUTOPILOT OPERATIONS Indication Meaning Comments GoSEA Turn Turning in the GoSEA mode. GoSEA Turn Enabled Shown between the time of the prewarning ac- knowledgement and the beginning of the turn. Mode is different from GoAW or GoSEA. Not Ready TCS not ready;...
Page 407 26. AUTOPILOT OPERATIONS Messages The message in the [Track Control Status] window (at the top of the display) states the reason why the preconditions for the start of track control are not complete. [Track Control Status] Preconditions for Track Control Start are missing: AP connection error.
Page 408: Other Route Steering Indications And Alerts
26. AUTOPILOT OPERATIONS 26.7.3 Other route steering indications and alerts Route steering indications in the Route Information box Permanent alerts appear in the [Route Information] box in red in any the steering mode. In the example below the [XTD] value is shown in yellow when the vessel is outside the channel.
Page 409: Alerts Given When Approaching A Waypoint
26. AUTOPILOT OPERATIONS 26.8 Alerts Given When Approaching a Waypoint 26.8.1 Track Control System (TCS) testing standard and Autopilot There are two TCS testing standards, IEC 62065 Ed. 1.0 and IEC 62065 Ed. 2.0. The Autopilots that can be connected to this ECDIS conform to the following TCS stan- dards: IEC 62065 Ed.
Page 410 26. AUTOPILOT OPERATIONS 90 sec. 30 sec. 30 sec. before WOL before WOL after WOL No ACK No ACK No ACK (1) ECCI (2) CCA (3) Backup released released navigator alarm released IEC 62065 Ed. 2.0 1. The vessel’s position is 240 seconds from the WOL. 2.
Page 411 26. AUTOPILOT OPERATIONS 7. When the vessel passes the WOL, the ECDIS releases the Course Change Alarm (CCA), which is the Alert "152 Wheel Over Line". 8. The CCA is not acknowledged. 9. 30 seconds after the vessel passes the WOL, the ECDIS outputs the Backup Nav- igator Alarm (contact signal, N/O or N/C) to the BNWAS.
Page 412: About The Backup Navigator Alarm
26. AUTOPILOT OPERATIONS 26.8.3 About the Backup Navigator Alarm The Backup Navigator Alarm alerts the bridge to an unacknowledged alarm by trans- ferring the alarm within the TCS to the BNWAS. For unacknowledged alarms that require output of the Backup Navigator Alarm, the TCS sends the Backup Navigator Alarm to the BNWAS.
Page 413: Route Steering Operations
26. AUTOPILOT OPERATIONS 26.9 Route Steering Operations 26.9.1 How to stop or change a pre-enabled turn in route steering There are two conditions where an automatic turn in a route must be stopped or changed: • The turn cannot be done to the last value. •...
Page 414: Collision Avoidance Maneuver In Route Steering
26. AUTOPILOT OPERATIONS 26.9.2 Collision avoidance maneuver in route steering Route steering is often interrupted by a collision avoidance maneuver, but there are also several other reasons to interrupt route steering. There are several possibilities to set the collision avoidance or any other maneuver: •...
Page 415: 2Expected Steering Performance For Turns
26. AUTOPILOT OPERATIONS * The Track Control System can compensate drift up to 45 degrees. If the drift is larger, your ship may go outside the channel limit. 26.10.2 Expected steering performance for turns Mode GoAW (FAP-2000/3000) GoAW (FAP-2000/3000) Environmental Heading control= GoAW+RC(PR-6000) GoAW+RC(PR-6000)
Page 416: 3Expected Steering Performance Under Critical Failure
26. AUTOPILOT OPERATIONS 26.10.3 Expected steering performance under critical failure Below is a summary of the system behavior in different failures in the GoSEA or GoAW steering mode. Lost heading to Autopilot Related Expected system Operator alerts performance action Immediately •...
Page 417 26. AUTOPILOT OPERATIONS Lost speed (IEC 62065 Ed. 1) Associated Expected system Operator alerts performance action • Speed log data, VTG • Acknowledge alerts. sentence lost. Alert • Monitor situation. "30510 No FIlter Source of COG/ SOG", Alert "30510 No Filter Source of CTW/STW"...
Page 418 26. AUTOPILOT OPERATIONS Low speed Associated Expected system Operator alerts performance action • Alert "159 Low Speed • Acknowledge alerts. Alarm". • Monitor situation. Lost communication between Autopilot and ECDIS and vice versa Associated Expected system Operator alerts performance action Within 15 •...
Page 419: 4When Track Control Is Stopped
26. AUTOPILOT OPERATIONS Total lost position (position from ALL GPS navigators is unreliable) Associated Expected system Operator alerts performance action • Alert "30400 EPFS1 • Acknowledge alerts. COM Error" (example). • Monitor situation. • The Kalman filter de- tects position jump, etc. Within 30 •...
Page 420 26. AUTOPILOT OPERATIONS This page is intentionally left blank. 26-36...
Page 421 APPENDIX 1 MENU TREE Main Menu General Ship Ship & Ship & Route MENU MAX Speed (0.1 to 80 kn, 22.1) Route Parameters MAX Height (0.0 to 100 m, 16.1) (click) MAX Draught (0.0 to 50 m, 20.0) Route MAX R.O.T* * Set at installation WPT Approach* WPT Prewarning*...
Page 422: Appendix 1 Menu Tree
APPENDIX 1 MENU TREE (Con’t from previous page) DISP Basic Light Popup (OFF, ON) Attributes Display (List Box, Text) Setting TM Reset (20-99%, 80) Chart General (Symbols (Paper Chart, Simplified), Boundaries (Plain, Symbolized), Four Shades, Full Light Lines, Scale MIN, Shallow Pattern, Shallow Water Dangers, Unknown, Accuracy, Display Highlight Date Dependent, Highlight INFO, Highlight Document, Contour Labels, LAT/LON (Checkbox for...
Page 423 APPENDIX 1 MENU TREE (Con’t from previous page) Set Route Monitoring and WARNING or CAUTION for (Safety Contour Chart Navigational Hazard, Areas To Be Avoided, User Chart Danger, Traffic Alert Separation Zone, Inshore Traffic Zone, Restricted Area, Caution Area, Setting Offshore Production Area, Military Practice Area, Seaplane Landing Area, Submarine Transit Lane, Anchorage Area, Marine Farm / Aqua Culture, PSSA Area, No Vector Chart, Too Many Dangers, UKC Limit, Sounding...
Page 424 APPENDIX 1 MENU TREE Settings Menu File Export Select data to export ( Setting data, Route/User chart, Playback data* ) Settings DB export * Disconnect (Click) AMS to use. File Import Select file to import Select data to import ( Setting data, Route/User chart, Playback data* ) File Maintenance (Restores last-saved route/user chart application and Route/user chart system.) Alert Setting (Escalation Setting) Self Test (Check various components of the system.)
Page 425: Appendix 2 Abbreviations, Symbols
APPENDIX 2 ABBREVIATIONS, SYMBOLS Abbreviations Abbreviation Meaning Acknowledge Acquire Activate Adjustment Admiralty Information Overlay Automatic Identification System Antenna April ATON Aid To Navigation August AUTO Automatic Blackbox Bow Cross Range Bow Cross Time Blue Bearing Bottom Tracking Caps Capital (letters) Category CCRP Common Consistent Reference Point...
Page 426 APPENDIX 2 ABBREVIATIONS, SYMBOLS Abbreviation Meaning December DEMO Demonstration DISP Display Dead Reckoning English East Electronic Bearing Line Estimated Time of Arrival External February FILT Filter Global Positioning System Green Gray Gyro Gyrocompass Heading hour International Hydrographic Organization International Maritime Organization Indication Integrated Navigation System Japanese...
Page 427 APPENDIX 2 ABBREVIATIONS, SYMBOLS Abbreviation Meaning Maximum Middle minute Minimum MMSI Maritime Mobile Service Identity Man Overboard Monitor Message North Navigation, Navigator Navtex Navigational Telex Nautical miles Number November NtoM Notice to Mariners October Operation Own Ship Personal Computer PERPENDIC Perpendicular Parallel Index (lines) POSN...
Page 428 APPENDIX 2 ABBREVIATIONS, SYMBOLS Abbreviation Meaning Select September Statute Miles Speed Over the Ground Speed SPEC Specification Solid State Drive, Solid State Device S.SRC Sensor Source STAB Stabilization STBY Stand-by Standard Switch SYNC Synchronization True True Bearing Track Control TCPA Time to Closest Point of Approach Track Control System TGT, TGTS...
Page 429 APPENDIX 2 ABBREVIATIONS, SYMBOLS Abbreviation Meaning Wheel Over Point Waypoint Water Tracking Cross Track Distance Yellow ECDIS Symbols Symbol name and description Symbol graphic(s) Own ship - true scaled outline This can be displayed when based on user se- lection either beam width or length is more than 3 mm.
Page 430 APPENDIX 2 ABBREVIATIONS, SYMBOLS Symbol name and description Symbol graphic(s) Velocity vector - stabilization indicator Ground stabilization is indicated by double ar- rowhead and water stabilization is indicated as single arrowhead. Past track System past track is indicated by thick line. Raw sensor primary past track is indicated by thin line.
Page 431 APPENDIX 2 ABBREVIATIONS, SYMBOLS Symbol name and description Symbol graphic(s) Radar targets in acquisition state 5 mm in diameter Tracked radar targets TT: Std or small user selection by Symbol Dis- play 3 mm in diameter Tracked radar targets - alternative TT: Std or small user selection by Symbol Dis- play 1 mm in diameter...
Page 432 APPENDIX 2 ABBREVIATIONS, SYMBOLS Symbol name and description Symbol graphic(s) Activated AIS targets - heading lines - turn indicators Velocity vectors Radar target velocity vectors AIS target velocity vectors Sarah J Sarah J Associated target velocity vectors Sarah J Sarah J Target past positions Radar target past positions AIS target past positions...
Page 433 APPENDIX 2 ABBREVIATIONS, SYMBOLS Symbol name and description Symbol graphic(s) AIS aid to navigation (ATON) Real ATON is without "V" and virtual ATON is with "V". An ATON in off position is yellow. AIS search and rescue transmitter -SART AIS base station AIS SAR vessel AIS aircraft Selected targets...
Page 434 APPENDIX 2 ABBREVIATIONS, SYMBOLS Symbol name and description Symbol graphic(s) Next waypoint WPT4 Routes - Monitor Monitored route leg lines are dashed. Leg lines may indicate planned speed and bearing. W05a Wheel over position 1115/20 Jan 15 deg 1213 Plotted positions Plotted position includes some labels.
Page 435 APPENDIX 2 ABBREVIATIONS, SYMBOLS Symbol name and description Symbol graphic(s) Tidal stream User defined tidal stream symbols are avail- able as part of User Chart. Actual tidal stream use solid vector and pre- dicted tidal stream use dashed vector. Danger highlight Route Plan, Route Monitor and own ship Chart Alarm search area use danger highlight to in- dicate violation against user selected dangers.
Page 436 APPENDIX 2 ABBREVIATIONS, SYMBOLS Symbol name and description Symbol graphic(s) Parallel index lines Symbols on operating buttons Symbol Meaning Symbol Meaning Minimize button Screenshot capture (on InstantAccess bar™) Access AIS, Navtex Monitor brilliance; control message processing unit backlighting Access user profile, Color palette selection common settings Information (show program...
Page 437: Appendix 3 Digital Interface
APPENDIX 3 DIGITAL INTERFACE Digital Interface Input sentences: ABK, ACN, ALC, ALF, ALR, ARC, CUR, DBT, DPT, DTM, ETL, GGA, GLL, GNS, HBT, HDT, HTD, MTW, MWV, NRX, OSD, PRC, RMC, ROR, ROT, RPM, RRT, RSA, RSD, THS, TRC, TRD, TTD, TTM, VBW, VDM, VDO, VDR, VSD, VHW, VTG, XDR, ZDA Output sentences: ABM, ACK, ACN, ALC, ALF, ARC, BBM, DDC, EVE, HBT, HTC, OSD, RRT, VBW, VDR, VSD,...
Page 438 APPENDIX 3 DIGITAL INTERFACE ACN - Alert command $**ACN,hhmmss.ss,aaa,x.x,x.x,c,a*hh<CR><LF> 4 5 6 1. Time (UTC) 2. Manufacturer mnemonic code (3 digit alphanumeric code, null) 3. Alert Identifier (1 - 999 or 100000 - 9999999) 4. Alert Instance (1 - 999999) 5.
Page 439 APPENDIX 3 DIGITAL INTERFACE ALR - Set alarm state $**ALR,Hhmmss.ss,xxx,A,A,c—c,*hh<CR><LF> 2 3 4 1. Time of alarm condition change, UTC (000000.00 - 235960.99) 2. Unique alarm number (identifier) at alarm source (000 - 999) 3. Alarm condition (A=threshold exceeded, V=not exceeded) 4.
Page 440 APPENDIX 3 DIGITAL INTERFACE DTM - Datum reference $**DTM,ccc,a,x.x,a,x.x,a,x.x,ccc,*hh<CR><LF> 1 2 3 4 5 6 7 1. Local datum (W84=WGS84 W72=WGS72 S85=SGS85, P90=PE90 2. Local datum subdivision code (NULL or one character) 3. Lat offset, min (0 - 59.99999) 4. N/S 5.
Page 441 APPENDIX 3 DIGITAL INTERFACE GLL - Geographic position, latitude/longitude $**GLL,llll.lll,a,yyyyy.yyy,a,hhmmss.ss,a,x,*hh<CR><LF> 1. Latitude (0000.00000 - 9000.00000) 2. N/S 3. Longitude (0000.00000 - 18000.00000) 4. E/W 5. UTC of position (No use) 6. Status (A=data valid V=data invalid) 7. Mode indicator (A=Autonomous D=Differential E=Estimated M=Manual input S=Simulator) GNS - GNSS fix data $**GNS,hhmmss.ss,llll.lll,a,IIIII.III,a,c--c,xx,x.x,x.x,x.x,x.x,x.x,a*hh<CR><LF>...
Page 442 APPENDIX 3 DIGITAL INTERFACE HTD - Heading/Track control data $**HTD,A,x.x,a,a,a,x.x,x.x,x.x,x.x,x.x,x.x,x.x,a,A,A,A,x.x*hh<CR><LF> 2 3 4 5 6 8 9 10 11 12 13 141516 17 1. Override, A = in use, V = not in use 2. Commanded rudder angle, degrees 3. Commanded rudder direction, L/R = port/starboard 4.
Page 443 APPENDIX 3 DIGITAL INTERFACE OSD - Own ship data $**OSD,x.x,A,x.x,R,x.x,R,x.x,x.x,N*hh<CR><LF> 1 2 3 4 5 6 7 8 9 1. Heading, degrees true (0.00 - 359.99, null) 2. Heading status (A=data valid, V=data invalid) 3. Vessel course, degrees true (0.00 - 359.99, null) 4.
Page 444 APPENDIX 3 DIGITAL INTERFACE ROR - Rudder order status $**ROR, x.x, A, x.x, A, a*hh<CR><LF> 3 4 5 1. Starboard (or single) rudder order (-90 to 90.0) 2. Status (A=Valid V=Invalid) 3. Port rudder order (-90.0 to 90.0) 4. Status (A=Valid V=Invalid) 5.
Page 445 APPENDIX 3 DIGITAL INTERFACE RSD - Radar system data $**RSD,x.x,x.x,x.x,x.x,x.x,x.x,x.x,x.x,x.x,x.x,x.x,N,H*hh <CR><LF> 9 10 11 12 13 1. Origin 1 range, from own ship (0.000 - 999) (see note 2) 2. Origin 1 bearing, degrees from 0 (0.0 - 359.9) (see note 2) 3.
Page 446 APPENDIX 3 DIGITAL INTERFACE TRD - thruster data response $**TRD,x,x.x,a,x.x,a,x.x*hh<CR><LF> 1 2 3 4 5 6 1. Number of thruster, bow or stern (01 to 99) 2. RPM response (-999.9 to 999.9) 3. RPM mode indicator (P=per cent R=revolutions per min V=data invalid) 4.
Page 447 APPENDIX 3 DIGITAL INTERFACE VDM - UAIS VHF data-link message !**VDM,x,x,x,x,s--s,x,*hh<CR><LF> 1 2 3 4 5 6 1. Total number of sentences needed to transfer the message (1 to 9) 2. Message sentence number (1 to 9) 3. Sequential message identifier (0 to 9, NULL) 4.
Page 448 APPENDIX 3 DIGITAL INTERFACE VTG - Course over ground and ground speed $**VTG,x.x,T,x.x,M,x.x,N,x.x,K,a,*hh <CR><LF> 1 2 3 4 5 6 7 8 9 1. Course over ground, degrees (0.00 - 360.00) 2. T=True (fixed) 3. Course over ground, degrees (No use) 4.
Page 449 APPENDIX 3 DIGITAL INTERFACE ACK - Acknowledge alarm $**ACK,xxx,*hh<CR><LF> 1. Local alarm number (identifier) (000 - 999) ACN - Alert command $**ACN,hhmmss.ss,aaa,x.x,x.x,c,a*hh<CR><LF> 4 5 6 1. Time (UTC) 2. Manufacturer mnemonic code (3 digit alphanumeric code, null) 3. Alert Identifier (1 - 999 or 100000 - 9999999) 4.
Page 450 APPENDIX 3 DIGITAL INTERFACE ALF - Alert sentence $**ALF,x,x,x,hhmmss.ss,a,a,a,aaa,x.x,x.x,x.x,x,c--c,*hh<CR><LF> 1 2 3 5 6 7 8 9 10 11 12 13 1. Total number of ALF sentences this message (1, 2) 2. Sentence number (1, 2) 3. Sequential message identifier (0 - 9) 4.
Page 451 APPENDIX 3 DIGITAL INTERFACE DDC - Display dimming control $**DDC,a,xx,a*hh<CR><LF> 1 2 3 4 1. Brilliance preset (D=Daytime K=Dusk N=Nightime O=Backlight off setting) 2. Brilliance (%) (00 to 99) 3. Color palette preset (D=Daytime K=Dusk N=Nightime) 4. Sentences status flag EVE - General event message $ **EVE,hhmmss.ss,c--c,c--c*hh <CR><LF>...
Page 452 APPENDIX 3 DIGITAL INTERFACE VSD - UAIS Voyage static data $**VSD,x.x,x.x,x.x,c--c,hhmmss.ss,xx,xx,x.x,x.x*hh<CR><LF> 6 7 8 1. Type of ship and cargo category (0 - 255) 2. Maximum present static draught (0 to 25.5 meters, null) 3. Persons on-board (0 - 8191, null) 4.
Page 453 APPENDIX 3 DIGITAL INTERFACE Serial Interface TD-A TD-B LTC1535 ISOGND RD-A RD-B 110 ohm* * Set with jumper. 470 ohm Switchable open/close. RD-H PC-400 RD-C Processor Unit, Sensor Adapter: IEC 61162-2/1 input/output 470 ohm RD-H PC-400 RD-C Processor Unit, Sensor Adapter: IEC 61162-1 input 10 ohm 10 ohm TD-A...
Page 454: Appendix 4 Data Color And Meaning
APPENDIX 4 DATA COLOR AND MEANING Indication Sensor COG/SOG Display example color color THS-A GNS-A, D, F, P, R VBW-A VTG-A,D,P SYSTEM/ All values in GGA-1, 2, 3, 4, 5 RMC-A, D, LOCAL green. GLL-A, D and (status: A) F, P, R and RMC-A, D, F, P, R and (status: A) (status: A) DGPS update interval in GGA,...
Page 455: Appendix 5 Alert List
APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* Loss of System Warning/ Loss of communi- Check that the de- Communication cation between pro- vice is securely cessor unit and connected. external equipment. Early Course Warning/ Waypoint is soon Be careful that Change being approached.
Page 456 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* Sensor Failure Alarm/B Deviation between Make deviation be- current heading and tween current plan course is more heading and plan than set value. course smaller. Default: 30 degrees Course Difference Warning/ Waypoint is now be- Be careful that ship...
Page 457 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* Inshore Traffic Warning/ An Inshore Traffic Be careful of the Zone Zone that is set to object mentioned Warning/Caution in left, on ship's direc- chart alert is detect- tion. ed inside the check area.
Page 458 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* PSSA Area Warning/ A PSSA Area that is Be careful of the set to Warning/Cau- object mentioned tion in chart alert is left, on ship's direc- detected inside the tion.
Page 459 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* EPFS3 Invalid/ Warning/ Ship position data Check the connec- missing datum from No.3 GPS has tion with No.3 GPS been discontinued and network. for more than set time. (Set at instal- lation) Default: 60 seconds No.3 GPS is turned...
Page 460 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* EPFS8 Invalid/ Warning/ Ship position data Check the connec- missing datum from No.8 GPS has tion with No.8 GPS been discontinued and network. for more than set time. (Set at instal- lation) Default: 60 seconds No.8 GPS is turned...
Page 461 Main Monitor Fan1 Caution/B For MU-190/231: If the error fre- Rotation Speed Connected to quently occurs, Lowering COM1(Main Moni- contact FURUNO tor). and inform fre- Fan1 rotation speed quency of occur- is below threshold. rence. 30001 Main Monitor Fan2 For MU-231: Con-...
Page 462 Caution/B For MU-231: Con- If the error fre- Rotation Speed nected to COM2 quently occurs, Lowering (Sub Monitor). contact FURUNO Fan2 rotation speed and inform fre- is below threshold. quency of occur- rence. 30001 Sub Monitor Fan3 For MU-231: Con-...
Page 463 Caution/B For Main monitor, If the error fre- tence Syntax Error connected to quently occurs, COM1, value of ex- contact FURUNO ternally input sen- and inform fre- tence is out of range quency of occur- that defined by sen- rence.
Page 464 Caution/B Rotation speed of If the error fre- Fan1 Rotation fan1 in processor quently occurs, Speed Lowering unit is below thresh- contact FURUNO old. and inform fre- quency of occur- rence. 30001 Processor Unit Rotation speed of If the error fre-...
Page 465 Main Monitor LCD Warning/ For MU-190: Con- LCD unit replace- Unit Lifetime Over nected to COM1. ment is required. LCD unit operating Contact FURUNO. time exceeds 50000 hours. For MU-231: Con- nected to COM1. LCD unit operating time exceeds 50000 hours.
Page 466 Main Monitor Fan3 Warning/ For MU-231: Con- If the error fre- No Rotation nected to COM1 quently occurs, (Main Monitor). contact FURUNO Fan3 rotation speed and inform fre- is below threshold. quency of occur- rence. 30002 Main Monitor Fan4 For MU-190: Con-...
Page 467 Warning/ Rotation speed of If the error fre- Fan3 Fan No Rota- fan3 in processor quently occurs, tion unit is below thresh- contact FURUNO old. and inform fre- quency of occur- rence. 30002 Processor Unit 5 V power voltage If the error fre-...
Page 468 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30050 Processor Unit Caution/B Input from EC-3000 Check the connec- Ch.05 COM Time- serial ch.5 has been tion of Ch.5. discontinued for more than certain time. (Set at installation) Default: No timeout 30050 Processor Unit...
Page 469 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30173 Permit Expired Warning/ When Permit Ex- Be careful of the pired is set to Warn- object mentioned ing/Caution in chart left, on ship's direc- alert, a chart area tion.
Page 470 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30300 Sensor Adapter 5 Caution/B Communication er- Check the connec- COM Timeout ror with No.5 sensor tion with No.5 sen- adapter is detected. sor adapter and 30 seconds time- network.
Page 471 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30300 Sensor Adapter 11 Caution/B Communication er- Check the connec- COM Timeout ror with No.11 sen- tion with No.11 sor adapter is sensor adapter detected. 30 sec- and network. onds timeout.
Page 472 Selected Gyro sta- Warning/ When connected If the error fre- tus missing with Double Gyro quently occurs, System, instrument contact FURUNO produced by Yok- and inform fre- ogawa Electric, quency of occur- "Double Gyro" sta- rence. tus cannot be ac- quired.
Page 473 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 Gyro 3 COM Error Caution/B Data from No.3 gyro Check the connec- has been discontin- tion with No.3 gyro ued for more than and network. set time. (Set at installation) Default: 60 seconds No.3 gyro is turned off, or there is a...
Page 474 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 EPFS 1 COM Error Caution/B Ship position data Check the connec- from No.1 GPS has tion with No.1 GPS been discontinued and network. for more than set time.(Set at installa- tion) Default: 60 seconds No.1 GPS is turned...
Page 475 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 EPFS 6 COM Error Caution/B Ship position data Check the connec- from No.6 GPS has tion with No.6 GPS been discontinued and network. for more than set time. (Set at instal- lation) Default: 60 seconds No.6 GPS is turned...
Page 476 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 SDME 1 COM Er- Caution/B Speed data from Check the connec- No.1 SDME has tion with No.1 been discontinued SDME and net- for more than set work. time. (Set at instal- lation) Default: 60 seconds No.1 SDME is...
Page 477 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 Echo Sounder 3 Caution/B Input of depth data Check the connec- COM Error from No.3 echo tion with No.3 echo sounder has been sounder and net- discontinued for work.
Page 478 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 HCS 2 COM Error Caution/B Data from No.2 Check the connec- HCS has been dis- tion with No.2 HCS continued for more and network. than set time. (Set at installation) Default: 60 seconds No.2 HCS is turned off, or there is a...
Page 479 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 Wind Sensor 3 Caution/B Data from No.3 Check the connec- COM Error wind sensor has tion with No.3 wind been discontinued sensor. for more than set time. (Set at installation) Default: 60 seconds No.3 wind sensor is turned off, or there...
Page 480 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 Other Sensor 1 Caution/B Data from No.1 oth- Check the connec- COM Error er sensor has been tion with No.1 other discontinued for sensor and net- more than set work.
Page 481 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 Other Sensor 6 Caution/B Data from No.6 oth- Check the connec- COM Error er sensor has been tion with No.6 other discontinued for sensor and net- more than set work.
Page 482 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 Other Sensor 11 Caution/B Data from No.11 Check the connec- COM Error other sensor has tion with No.11 oth- been discontinued er sensor and for more than set network.
Page 483 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 Other Sensor 15 Caution/B Data from No.15 Check the connec- COM Error other sensor has tion with No.15 oth- been discontinued er sensor and for more than set network.
Page 484 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 Other Sensor 19 Caution/B Data from No.19 Check the connec- COM Error other sensor has tion with No.19 oth- been discontinued er sensor and for more than set network.
Page 485 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 Other Sensor 23 Caution/B Data from No.23 Check the connec- COM Error other sensor has tion with No.23 oth- been discontinued er sensor and for more than set network.
Page 486 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30400 Other Sensor 27 Caution/B Data from No.27 Check the connec- COM Error other sensor has tion with No.27 oth- been discontinued er sensor and for more than set network.
Page 487 Double Gyro Sta- Warning/ When connected If the error fre- tus Conflict with Double Gyro quently occurs, System, instrument contact FURUNO produced by Yok- and inform fre- ogawa Electric, two quency of occur- gyro has been dis- rence. played "Selected"...
Page 488 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30500 EPFS 4 Sensor Caution/B Own ship position Reset the filter to Banned data from No.4 GPS confirm that it isn't is determined ab- a temporal error normal by integrity value.
Page 489 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30500 EPFS 7 Sensor Caution/B Own ship position Reset the filter to Banned data from No.7 GPS confirm that it isn't is determined ab- a temporal error normal by integrity value.
Page 490 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30500 EPFS 10 Sensor Caution/B Own ship position Reset the filter to Banned data from No.10 confirm that it isn't GPS is determined a temporal error abnormal by integri- value.
Page 491 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30500 Gyro 3 Sensor Caution/B Heading data from Reset the filter to Banned No.3 Gyro is deter- confirm that it isn't mined abnormal by a temporal error integrity check. value.
Page 492 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30500 SDME 1 Sensor Caution/B Own ship speed Reset the filter to Banned data from No.1 confirm that it isn't SDME is deter- a temporal error mined abnormal by value.
Page 493 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30500 ROT Gyro 1 Sen- Caution/B Heading data from Reset the filter to sor Banned No.1 ROT Gyro is confirm that it isn't determined abnor- a temporal error mal by integrity value.
Page 494 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30510 No Filter Source of Warning/ No valid heading Check the connec- Heading sensor is available tion with all GPS. for filter. (Banned or connection error) 30510 No Filter Source of No valid position Check the connec- sensor is available...
Page 495 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30602 COG/SOG Source Caution/B COG/SOG sensor Change used in system (dis- tributed by own ship's information management) is changed. 30602 CTW/STW Source CTW/STW sensor Change used in system (dis- tributed by own ship's information management) is...
Page 496 30800 RM Stop - Sensor Error occurs inside If the error fre- lost of route monitoring quently occurs, function. contact FURUNO and inform fre- quency of occur- rence. 30800 RM Stop - Internal Required data for Check the connec- Error...
Page 497 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30802 Anchor Watch Warning/ While anchor watch Be careful of drag- alert function is en- ging anchor. abled, ship's posi- tion has been outside of alarm area centering cer- tain position for more than 3 sec- onds.
Page 498 APPENDIX 5 ALERT LIST Priority/ Alert name Meaning Remedy Category Inst.* 30960 Takeover AMS Warning/ When connection This alert appears Master with the MAIN AMS when the MAIN is lost and the AMS is turned off BACKUP AMS is also. Check the assigned as the power and connec- MAIN, this alert ap-...
Page 499 SPECIFICATIONS OF Electronic Chart Display and Information System (ECDIS) FMD-3200/3300/3200-BB MONITOR UNIT Display type MU-190 (FMD-3200) 19-inch color LCD, 1280 x 1024 pixel (SXGA) MU-231 (FMD-3300) 23.1-inch color LCD, 1600 x 1200 pixel (UXGA) MU-270W (FMD-3300) 27-inch color LCD, 1920 x 1200 pixel (WUXGA) HD26T21 MMD-MA4-FAGA (FMD-3300) 25.54-inch color LCD, 1,920 x 1,200 pixel (WUXGA)
Page 500 FURUNO FMD-3200/3300/3200-BB 2.11 Notes Create and display notes data; transferred to radar 2.12 AIS safety message Receive, create and transmit safety messages View and modify own ship information stored in AIS transponder 2.13 NAVTEX message Receive and display NAVTEX messages (position, etc.) 2.14 MOB (Man Overboard)
Page 501 FURUNO FMD-3200/3300/3200-BB TTM, VBW, VDM, VDO, VDR, VHW, VSD, VTG, XDR, ZDA Output ABM, ACK, ACN, ALC, ALF, ARC, BBM, DDC, EVE, HBT, HTC, OSD, RRT, VBW, VDR, VSD, XTE Sensor adapter (option) MC-3000S (serial) 8 ports: I/O, IEC61162-1/2: 4 ports, IEC61162-1: 4 ports...
Page 502 FURUNO FMD-3200/3300/3200-BB POWER SUPPLY Monitor unit MU-190 100-230 VAC: 0.7-0.4 A, 1 phase, 50/60 Hz MU-231 100-230 VAC: 1.0-0.6 A, 1 phase, 50/60 Hz MU-270W 100-230 VAC: 0.7-0.4 A, 1 phase, 50/60 Hz HD26T21 MMD-MA4-FAGA 115/230 VAC: 1.1-0.5 A, 1 phase, 50/60 Hz, 24 VDC: 5.2 A Processor unit 100-115/220-230 VAC: 1.5-0.7 A, 1 phase, 50/60 Hz...
Page 503 INDEX buzzer silencing........25-3 buzzer, IEC 61924-2 mode ....25-10 Abbreviations ..........AP-5 buzzer, legacy mode ......25-9 ACN sentence ......... 25-4 buzzer, silencing (temporarily) ....25-9 ACTIVE ALERT window......25-17 category and alert acknowledgement..25-3 Aggregated alert........25-11 description ..........25-1 display priority order ......
Page 504 INDEX collision avoidance .......26-30 select units to synchronize .....3-32 ECDIS unit to control autopilot .....26-19 synchronization status......3-33 functions at ECDIS.......26-18 Chart usage log........19-8 messages when preconditions not Charts met ............26-23 cell deleting ..........3-23 preconditions not met......26-22 cell editing ..........3-22 route information box ....26-18 26-21 Check area page........8-4 route steering indications .....26-21...
Page 505 INDEX context-sensitive menu ......2-25 parameters ..........21-4 hiding............. 2-24 returning to monitored route ....11-13 measuring bearing with ......2-24 safe off track.......... 11-7 showing ..........2-24 stopping monitoring ......11-12 EBL, VRM boxes........2-14 ECDIS Control Unit ........1-3 Keyboard test page .......
Page 506 INDEX Permanent warning box ......2-14 deleting...........9-22 Permanent warnings deleting waypoints........9-11 ARCS charts ..........6-5 exporting FEA-2x07, csv, ASCII ENC charts..........5-3 data .............9-22 Permit status ..........3-18 exporting FMD-3xx0, FCR-2xx9 PI (parallel index) page ......12-1 data .............9-21 Play back log..........19-12 full WPT report ........9-28 Position importing csv, ASCII data.......9-20 alignment..........18-11...
Page 507 INDEX Ship and route parameters...... 21-1 syncing ..........10-2 Silent mode ..........1-2 tidal report ........... 10-13 SPD page..........18-2 User default page........23-15 Speed input ..........1-10 User events ..........19-1 Split screen ..........1-19 User profile..........1-15 Standard page........... 4-4 Status bar..........

This manual is also suitable for:

Fmd-3200-bb Fmd-3300

Furuno FMD-3200 Operator's Manual

Foreword

System Configuration

1 Introduction

2 Operational Overview

3 How to Manage Charts

4 How to Control Chart Objects

5 Vector (S57) Charts

6 Raster (Arcs) Charts

7 C-Map Charts

8 Chart Alerts

9 Routes

10 User Charts

11 How to Monitor Routes

12 Navigation Tools

13 Tracked Target (Tt) Functions

14 Ais Target Functions

Quick Links

Troubleshooting

Related Manuals for Furuno FMD-3200

Summary of Contents for Furuno FMD-3200
