INSTRUCTION MANUAL
SETTING AND ADJUSTMENTS
FMD-3200/FMD-3200-BB/FMD-3300/FCR-2119-BB/
Model
FCR-2129-BB/FCR-2139S-BB/FCR-2819/FCR-2829
FCR-2839S/FCR-2829W/FCR-2839SW
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
This manual is solely for use by the installer. Under no
circumstances shall this manual be released to the user.
The installer shall remove this manual from the vessel
after installation.
This manual contains no password data. Obtain password
data from FURUNO before beginning the installation.
www.furuno.com

Advertisement

Table of Contents
loading

Related Manuals for Furuno FMD-3200-BB

Summary of Contents for Furuno FMD-3200-BB

  • Page 1 The installer shall remove this manual from the vessel after installation. This manual contains no password data. Obtain password data from FURUNO before beginning the installation. www.furuno.com All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
  • Page 2 Pub. No. E42-01204-N (1907, YOSH ) FMD-3xxx/FCR-2xx9 Printed in Japan 00019485812...
  • Page 3 INTRODUCTION About this manual This manual shows how to setup ECDIS and Chart Radar after the installation. After setting, make a backup copy of configuration data onto a medium (PC, etc.). Preparation • PC (for the LAN connection) • LAN cable (for the LAN connection) Trademarks Windows and Internet Explorer are either registered trademarks or trademarks of Microsoft Cor- poration in the United States and/or other countries.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS INITIAL SETTING AND ADJUSTMENT ..............1-1 1.1 How to Access the [Common Installation Setting] Menu ........... 1-1 1.1.1 Laptop PC (LAN connection) access ............. 1-1 1.1.2 Control Unit RCU-024/025/026 ..............1-2 1.1.3 [Common Installation Setting] menu contents..........1-3 1.2 [Basic Setting] Menu ....................
  • Page 5 TABLE OF CONTENTS 1.8.7 How to edit an alert definition ...............1-67 1.8.8 How to delete an alert definition ..............1-67 1.9 [Data Sharing] Menu....................1-67 1.10 [Save and Sync] Menu .....................1-68 1.10.1 Consistency check and save the configuration ..........1-68 1.10.2 How to save the configuration data to a medium .........1-70 1.10.3 How to load the configuration data ..............1-70 1.11 [System Monitor] Menu.....................1-71 1.12 [Software Update] Menu...................1-72...
  • Page 6 TABLE OF CONTENTS This page is intentionally left blank.

  • Page 7: Initial Setting And Adjustment

    INITIAL SETTING AND ADJUSTMENT This chapter shows you how to enter the initial settings for the processor unit (EC- 3000) of ECDIS and Chart Radar after the installation. Note: Each unit has a default IP address. Enter the initial settings (Equipment ID set- ting) and change the IP address on the [Basic Setting] menu (see section 1.2.), before connecting each unit and building the network.

  • Page 8: Control Unit Rcu-024/025/026

    1. INITIAL SETTING AND ADJUSTMENT 2. Connect the PC to the LAN1 or LAN2 port of the processor unit with a LAN cable. Note: It is possible to connect to the LAN1 or LAN2 port via a LAN hub. However, to operate from the [Basic Setting] menu, turn off all units except the unit to be set.
  • Page 9 1. INITIAL SETTING AND ADJUSTMENT 4. Enter the password and click [OK]. [Service Mode] is shown at the bottom left po- sition of the [Settings] window. For RCU-024: Use the keyboard on the control unit to enter the password. For RCU-025/026: Use the software keyboard on the display to enter the pass- word.

  • Page 10: Basic Setting] Menu

    1. INITIAL SETTING AND ADJUSTMENT Basic Setting Basic Setting Own Ship Setting Own Ship Setting Installation Parameters Installation Parameters CCRS CCRS Click Click Own Ship Setting Own Ship Setting Installation Parameters Installation Parameters CCRS CCRS Alert Define List Alert Define List Tab name Feature Basic Setting...
  • Page 11 1. INITIAL SETTING AND ADJUSTMENT For the Chart Radar: Setting range: [CRA001] to [CRA004]. Do not select [CRA005] to [CRA010]. The [Equipment Name], [Equipment Type No.], and [IP Address] are automatically entered according to the Equipment ID. For details, see the Equipment ID list is at the back of this manual.

  • Page 12: Peripherals] Window

    1. INITIAL SETTING AND ADJUSTMENT 4. For the Chart Radar, select the Equipment ID of the radar processor unit from the [Equipment ID] pull-down list. Setting range: [RAS001] to [RAS004]. Do not use [RAS005] to [RAS010]. For the ECDIS, go to step 8. The [Equipment Name], [Equipment Type No.], and [IP Address] are automatically entered according to the Equipment ID.
  • Page 13 1. INITIAL SETTING AND ADJUSTMENT • [JH 20T17FUD (UXGA)] • [HD 55T22FUD (WUXGA)] • [JH 23T12FUD (UXGA)]* • [NI WA460-01.MON.01(FHD)]* • [JH 23T14FUD (UXGA)] • [NI WA460-01.MON.01(WUXGA)] • [JH 26T11MMD (WUXGA)]* • [NI WA270-01.MON.01-XXFU(FHD)]* • [NI WA270-01.MON.01-XXFU(WUXGA)] • [HD 19T21MMD (SXGA)]* •...
  • Page 14 [Connection] item. For the Chart Radar, the [Chart Service] field does not appear. Go to the next step. • [Not Connected]: Not connected to chart data storage equipment. • [FURUNO]: Connected to the FURUNO Gate-1. • [NAVTOR]: Connected to the NAVTOR NavBox. • [NeCST]: Not used.

  • Page 15: Vdr] Window

    1. INITIAL SETTING AND ADJUSTMENT 12. To connect a service gateway, select [Connected] at [Service Gateway] then the IP address and the port number appear below the [Connected] item. Do not change these settings. 13. Click [Save] on the info bar. Several confirmation messages appear. Click [OK] to reboot the system.

  • Page 16: Route Transfer] Window

    1. INITIAL SETTING AND ADJUSTMENT Menu item/ Description interactive field [Source] Set the status and information text, max. 16 characters. [Location] Set the status and information text, max. 32 characters. [Initial Value of Se- Set the initial value for the binary transmission sequence quence No.] number (IEC61162-450 compliant) to be used when transmitting video to a VDR.

  • Page 17: Ship Name] Window

    1. INITIAL SETTING AND ADJUSTMENT 3. Select the primary display mode from the [Primary] pull-down list. The primary display mode is displayed when you start the ECDIS. Also, the work- ing indicator at the upper right changes according to the setting, and the spinner can be clicked to return to the primary display mode.

  • Page 18: Language] Window

    01-999 Note 1: N/A means that the setting does not affect the operation of FMD. Note 2: When you connect the FURUNO radar, it is recommend- ed to check the checkbox. For Chart Radar: When the checkbox is checked, the TT whose ID is “100” is out- put with the ID “0”.

  • Page 19: Own Ship Setting] Menu

    1. INITIAL SETTING AND ADJUSTMENT [Own Ship Setting] Menu Enter the information for ship parameters/CCRP, antenna unit, GPS sensor, AIS tran- sponder, echo sounder (E/S), and SDME sensor. As for the symbol for sensors, there are six colors to show the priority: white (CCRP), cyan (Radar), green (GPS), magenta (AIS), orange (E/S) and blue (SDME) in that order.
  • Page 20 1. INITIAL SETTING AND ADJUSTMENT 3. Click [Radar Antenna] on the menu bar. Note: When you set the value for [Antenna Position] on the [Installation Parame- ters] menu, the setting value is shown at the right of [Equipment ID]. 4. According to the number of antenna units connected to the processor unit, check applicable checkbox to activate the antenna unit(s).

  • Page 21: Installation Parameters] Menu

    1. INITIAL SETTING AND ADJUSTMENT • [RCB00 (Main)] (: 1 to 4): Input the location information of the external radar antenna that is connected to the [RADAR SIGNAL IN No.1] port. • [RCB00 (Sub)] (: 1 to 4): Input the location information of the external radar antenna that is connected to the [RADAR SIGNAL IN No.2] port.
  • Page 22 1. INITIAL SETTING AND ADJUSTMENT 5. Click the [Details] button to set the following items, referring to the table shown be- low. For other units For [VDR] For [Other Sensor] Item Remarks [Sensor Name] Enter the appropriate sensor name. [Manufacture] Select the manufacturer of sensor from the pull-down list.

  • Page 23: Processor Unit Configuration

    1. INITIAL SETTING AND ADJUSTMENT Sensor Equipment ID Sensor Equipment ID GPS Sensor GPS001 Wind Sensor ----- Gyro Sensor GYO001 Magnet Compass ----- Sensor ROT GYRO Sensor ----- Current Sensor ----- AIS Transponder AIS001 Rudder Sensor ----- Echo Sounder ----- ----- SDME Sensor LOG001...
  • Page 24 1. INITIAL SETTING AND ADJUSTMENT 3. Click the [Details] button and set the items referring to the following table. For Chart Radar For ECDIS Item Remarks [Subsystem] Set up sharing of sensor data through HUB-3000. For subsystem de- tails, see page AP-3. When sharing sensor data: Set the value.
  • Page 25 1. INITIAL SETTING AND ADJUSTMENT Item Remarks [VNC Connection No use. Enable]* [Sub Display Mode]* [Server IP Ad- dress]* [Server Port Number]* [Server Login Password]* [Additional Pa- rameters]* [Backup EC- Check the check-box to install the Chart Radar as a Back-up ECDIS. DIS]** *: ECDIS only **: Chart Radar only...
  • Page 26 1. INITIAL SETTING AND ADJUSTMENT Item Remarks [Details] Sets the serial communication format. • [Baud rate]: Sets the baud rate. For high-speed signal input (such as AIS and Gyro) or TTD output, set the baud rate as 38,400 bps The available serial ports with communication in 38,400 bps are [Serial 01] to [Serial 04].
  • Page 27 1. INITIAL SETTING AND ADJUSTMENT Item Remarks [Output] Sets the output sentence formats from the se- rial port. • [Output sentence whose destination corre- sponds with this sensor.]: Check the check- box to activate any of the following items. • To output the ACK and HBT sentences in response to the ALR sentence from the external sensor.
  • Page 28 1. INITIAL SETTING AND ADJUSTMENT 8. Check the checkbox of [Channel No.]. 9. Set the items referring to the table shown below. Item Remarks [Data Cate- Sets the data category. Settings: [ALERT], [ACK], [BUZZER STOP], [OP- gory] ERATOR FITNESS], [OTHER], [GYRO SELECTOR], [MOB]. [+] button This appears when the [Data Category] is set to [ALERT].
  • Page 29 1. INITIAL SETTING AND ADJUSTMENT 10. Click [Digital Output] of [No.1 ECDIS] or [No.1 Chart Radar] on the menu bar. For the pin no. of J11 on the I/O board of the processor unit and the corresponding input/output channel no., see the table on step 7. 11.

  • Page 30: Activating The Connection With The Processor Unit Of The Far-28 Series Radar (Ecdis Only)

    1. INITIAL SETTING AND ADJUSTMENT Item Remarks [Details] • [Name]: Enter the appropriate sensor name. • [Data Type]: Set the contact output. [Normally Open] is for [Channel 01] to [Channel 02], [Normally Closed] is for [Channel 03] to [Channel 04]. Note: [Data Type] is not shown for the Sensor Adapter setting.
  • Page 31 1. INITIAL SETTING AND ADJUSTMENT 3. Click the [Details] button to set the following items, referring to the table shown be- low. Item Remarks [Equipment Name] Enter the name of the equipment. [Equipment Type Shows the equipment type number. No.] [SFID] Keep the default settings.

  • Page 32: Sensor Adapter Configuration

    1. INITIAL SETTING AND ADJUSTMENT 1.4.4 Sensor Adapter configuration A maximum of eight Sensor Adapter MC-3000S can be connected to the sensor net- work. In case of the redundant configuration, sixteen Sensor Adapters can be con- nected to the network. The MC-3000S can connect a max. ten additional units (MC- 3010A/3020D/MC-3030D).
  • Page 33 1. INITIAL SETTING AND ADJUSTMENT 5. Click [Serial Input/Output]. There are eight ports in the Serial Input/Output. [Serial 01] to [Serial 04] can input/output at 38,400 bps for the AIS and Gyro or TTD out- put. The connector no. on the MC-3000S board and the corresponding serial port no. are shown below.
  • Page 34 1. INITIAL SETTING AND ADJUSTMENT No.1 Sensor Adapter MC-3020D Connector No. Channel No. Connector No. Channel No. Channel 01-01 Channel 01-05 Channel 01-02 Channel 01-06 Channel 01-03 Channel 01-07 Channel 01-04 Channel 01-08 No.2 Sensor Adapter MC-3020D Connector No. Channel No. Connector No.
  • Page 35 1. INITIAL SETTING AND ADJUSTMENT 10. Check the checkbox for [Channel No.] to set the items referring to step 12 of section 1.4.2. 11. Click [Analog Input] on the menu bar. [Channel 01] to [Channel 15] are shown on the display. Each Sensor Adapter MC- 3010A has three input ports.

  • Page 36: Antenna Unit Configuration

    1. INITIAL SETTING AND ADJUSTMENT Item Remarks [Details] • [Sensor Type No.]: Enter the sensor type. • [Data Name]: Enter the appropriate data name. • [Calibration Active]: Check the check box to display the analog input data on the conning display and show the lower columns.

  • Page 37: Radar Connection Box Configuration (Ecdis Only)

    [DIP SW]: 1000 or 1001 1.4.6 Radar connection box configuration (ECDIS only) You can display echoes from non-Furuno radars by connecting them to the ECDIS through the Radar Connection Box RCB-002. A maximum of four RCB-002s can be connected to this system.

  • Page 38: Monitoring Of Hub

    1. INITIAL SETTING AND ADJUSTMENT Item Remarks [SFID] Keep the default setting. [DATA Type] Sets the RX sentence data format. Setting options: [IEC 61162-1 Ed3], [IEC 61162-1 Ed4], [IEC 61162- 1 Ed5] [Strict/Loose] Sets the integrity of sentence data. [Strict]: Confirm the validity of checksum, then receive sentence. [Loose]: Receive sentence regardless of checksum invalidity.

  • Page 39: Signal And Port Setting For External Equipment

    1. INITIAL SETTING AND ADJUSTMENT 4. Click the [Details] button to open the [Details Setting] window and enter the appro- priate items. • [Equipment Name]: Enter the name of the HUB. • [IP Address]: Select the network and IP Address of the HUB from the pull-down list. •...
  • Page 40 1. INITIAL SETTING AND ADJUSTMENT • Where [HUB Port Setting] ([Monitoring Type] = [Monitor Ports]) Item Remarks Checkbox Check the checkbox for the port which generates the alert when the connection is interrupted. [Port] HUB port number. [Alert No.] When the alert notification sentence is in ALR format, the alert number is shown.

  • Page 41: Customized Sensor Setting

    1. INITIAL SETTING AND ADJUSTMENT 1.4.9 Customized sensor setting Set the sensor types and manufacturers in the [Sensor Setting] menu. 1. Click [User Sensor Model List] on the menu bar. 2. Click the appropriate sensor to edit. The figure below shows an example where the [GPS Sensor] is selected.

  • Page 42: Settings To Activate The Shuttle Ferry Mode (Chart Radar Only)

    1. INITIAL SETTING AND ADJUSTMENT 1.4.10 Settings to activate the shuttle ferry mode (Chart Radar only) The external switch for the shuttle ferry mode should be registered as "Other Sensor". Note: When there is a FMD-300 with Radar mode activated in the same network, the shuttle ferry mode is not available.

  • Page 43: Ccrs] Menu

    1. INITIAL SETTING AND ADJUSTMENT [CCRS] Menu 1.5.1 How to select the [Data Source] 1. Access the [Common Installation Setting] menu and click [CCRS] on the tab bar. 2. Click the [Position] directly item below [Data Source Setting] on the menu bar. *: Position, Heading, STW, COG/SOG, Rate of Turn: Keep the default setting (3000).

  • Page 44: How To Set [Transmission Group]

    1. INITIAL SETTING AND ADJUSTMENT 1.5.2 How to set [Transmission Group] When connecting IEC61162-450 compatible sensors, you may need to adjust [Trans- mission Group Setting]. Under normal circumstances, you do not need to adjust these settings. When adjusting items in [Transmission Group Setting] menu, you will need to configure for all devices in the configuration.
  • Page 45 1. INITIAL SETTING AND ADJUSTMENT Default settings for each Transmission Group Transmission Group Talker Multicast Address Multicast Port MISC 239.192.0.1 60001 TGTD 239.192.0.2 60002 SATD 239.192.0.3 60003 NAVD 239.192.0.4 60004 1-39...

  • Page 46: Ccrs Setting] Window

    1. INITIAL SETTING AND ADJUSTMENT Transmission Group Talker Multicast Address Multicast Port VDRD 239.192.0.5 60005 RCOM 239.192.0.6 60006 TIME 239.192.0.7 60007 PROP 239.192.0.8 60008 USR1 239.192.0.9 60009 USR2 239.192.0.10 60010 USR3 239.192.0.11 60011 USR4 239.192.0.12 60012 USR5 239.192.0.13 60013 USR6 239.192.0.14 60014 USR7...

  • Page 47: Tcs] Menu

    [TCS] Menu The [TCS] menu adjust the settings relevant to the TCS (Track Control System). The TCS is available with the FMD-3200/FMD-3300/FMD-3200-BB only. For Chart Ra- dars, only the settings on the [Other Setting] window are required (see section 1.6.7).
  • Page 48 1. INITIAL SETTING AND ADJUSTMENT • Confirmation on the [About] screen 1. Click the [ ] button on the status bar. 2. Click [About] to show the [About] screen. 3. Click the [System1] tab. 4. Confirm if "tcs" appears in the [Function] field. •...

  • Page 49: How To Set The Tcs For Autopilot

    1. INITIAL SETTING AND ADJUSTMENT 1.6.2 How to set the TCS for autopilot 1. Access the [Common Installation Setting] menu and click [Installation Parame- ters] on the tab bar. 2. Click [HCS] on the menu bar. 3. Check the checkbox of [HCS001]. 4.
  • Page 50 1. INITIAL SETTING AND ADJUSTMENT Manufacturer Model Sentence Display example Yokogawa PT-900 • HTC Electric • XTE Corporation • VBW • VTG TOKYO KEIKI PR-6000 • HTC • XTE PR-9000 • VBW • VTG • HSC • FRN EMRI FAP-2000 •...

  • Page 51: How To Set The Navigation Parameter

    1. INITIAL SETTING AND ADJUSTMENT 16. Set [Basic Setting] referring to the table shown below. Setting Option Remarks Primary Select the Equipment ID of the primary ECDIS. ECDIS Secondary Select the Equipment ID of the secondary ECDIS. Manufacture Enter the manufacturer of the autopilot. Autopilot Model Enter the type of the connected autopilot.
  • Page 52 1. INITIAL SETTING AND ADJUSTMENT 6. When [FWD DIST NM] is different between port and starboard sides, check the checkbox of [Use different values for Port and Starboard] and then enter each set- ting value. 7. Confirm the TCS is stopped and click [Save] to save the Navigation Parameter. Note: When you click [Save] while the TCS is activated, the TCS is force-quitted.
  • Page 53 1. INITIAL SETTING AND ADJUSTMENT 4. After the turn of the vessel, click the [Service State] button again. When the turn of the vessel goes long, raise the setting value of [FWD DIST NM]. When the turn of the vessel goes sharp, lower the setting value of [FWD DIST NM].
  • Page 54 1. INITIAL SETTING AND ADJUSTMENT 2. Click [System/Local Select] on the menu. 3. Select [Local Sensor], and then click Save button. 4. Click [Local Sensor Setting] on the menu. 5. Open the [SPD] tab to set [Stabilization Mode] to [Water]. 6.
  • Page 55 1. INITIAL SETTING AND ADJUSTMENT 10. Click the [Save] button. According to the data that you entered, the information of the sensor information box is updated. Example: Sensor information box Note: For the heading data, use the data input from the heading sensor. 11.

  • Page 56: Multiple Ecdis And Autopilot Control

    1. INITIAL SETTING AND ADJUSTMENT 1.6.4 Multiple ECDIS and autopilot control The ECDIS is connected to the autopilot via a hardware switch to permit manual switching of the ECDIS units. HUB-3000 EC-3000 EC-3000 HUB-100 (ECDIS) (ECDIS) Hardware switch Autopilot For example, ECD002 is the primary ECDIS and ECD003 is secondary ECDIS. Then, to set the primary and secondary ECDIS units, do as follows.

  • Page 57: Detail Settings For The Tcs

    1. INITIAL SETTING AND ADJUSTMENT 1.6.5 Detail settings for the TCS You can set the detail settings for the TCS on the [Detail Setting] window of the [TCS] menu. Parameter Explanation Rules Enable Heading Monitor Uncheck this item. Off Course Limit Start Course difference limit to start the TCS Alert Threshold...
  • Page 58 1. INITIAL SETTING AND ADJUSTMENT Parameter Explanation Track Control Adjust the gain for the XTE. To adjust the gain val- XTE Gain - Open Sea* ue manually, activate the checkbox for [Manual] XTE Gain - All Waters* and enter the setting value. Alert Talker ID Keep the default setting.

  • Page 59: Filter Setting] Window

    Note 1: After changing this setting, reboot the system to apply the setting. Note 2: Do not select [File (HTTP)] when the manufacturer does not sign the non-disclosure agreement with FURUNO. Detailed specification depends on the disclosed information between FU- RUNO and manufacturer.

  • Page 60: Ams] Menu

    AMS operating mode. Note 1: For Chart Radars, only the settings on the [Operation Mode Setting] window are required (see section 1.7.1). Note 2: For how to set the alert definition of AMS, see the FURUNO information. 1.7.1 AMS mode operation 1.

  • Page 61: Master/Backup Ams Setting

    1. INITIAL SETTING AND ADJUSTMENT item Remarks [Transfer Category] Check the checkbox of the appropriate Category (A to C) to (A~C) transfer the alerts. [Stop Transfer Cate- Select [YES] to enable stopping of the alert transfer for Category gory A ACK] A alerts by ACK operation.

  • Page 62: Alert Transfer Setting

    1. INITIAL SETTING AND ADJUSTMENT 1.7.3 Alert transfer setting 1. Access the [Common Installation Setting] menu, then select [AMS] from the tab bar. 2. Select [Alert Transfer Setting]  [IAS Setting] on the menu bar. You can create the alert group and transfer the alert to the navigational equip- ment.
  • Page 63 1. INITIAL SETTING AND ADJUSTMENT Item Remarks Opens the [Alert No.Setting] di- ] button alog box to register the alert to the group. Select the alert source equipment from the [Equipment ID] pull-down list. Activate the radio button of the appropriate alert(s), then [OK] button to register the alert.

  • Page 64: Other Setting Window

    1. INITIAL SETTING AND ADJUSTMENT 1.7.4 Other setting window This section provides a description for the contents of the [Other Setting] window. Open the [AMS] menu and select [Other Setting] on the menu bar, then select an ap- propriate setting item. Item Remarks [Category C Silence...
  • Page 65 1. INITIAL SETTING AND ADJUSTMENT Item Remarks [Enable Silence But- Keep the default setting. ton Setting] [Redraw Interval Set- Keep the default setting. ting] [Unknown Alert Noti- Keep the default setting. fy Setting] [HBT Sentence Set- Set the options for the HBT sentence. ting] [Send Setting] •...

  • Page 66: Alert Define List] Menu

    1. INITIAL SETTING AND ADJUSTMENT Export the [AMS] menu settings 1. Access the [Common Installation Setting] menu, then select [AMS] from the tab bar. 2. Select [Export Alert Configuration] on the menu bar. 3. Click the [Export File] button to export the setting file. [Alert Define List] Menu This [Alert Define List] menu sets the alert group and the alert definition.
  • Page 67 1. INITIAL SETTING AND ADJUSTMENT Item Remarks [New Group] Add a new alert group. See section 1.8.2. button [Delete Delete an alert group. See section 1.8.4. Group] button All extension Click to open/close the detail setting window for all groups ([+]: button Open all groups, [-]: Close all groups).

  • Page 68: How To Add An Alert Group

    1. INITIAL SETTING AND ADJUSTMENT 1.8.2 How to add an alert group An alert group can be added newly. The maximum number of alert groups is 1,000. 1. Click the [New Group] on the [Alert Group Setting] window referring to the figure in step 2 of section 1.8.1.

  • Page 69: How To Edit An Alert Group

    1. INITIAL SETTING AND ADJUSTMENT 6. To set alerts for other equipment, click the [Details] button of the added alert group (see the figure in step 2 of section 1.8.1.). The [Group Details] window is shown. 7. Set the alert to the alert group with the same procedure as step 3 to step 5. 8.
  • Page 70 1. INITIAL SETTING AND ADJUSTMENT 2. Select the appropriate equipment type on the menu bar. For example, select [EC- DIS]  [FMD-3200|3300] to set the alert definitions for FMD-3200/FMD-3300. Note: The equipment and sensors shown on the menu bar depend on the [Instal- lation Parameters] menu settings.

  • Page 71: How To Add An Alert Definition

    1. INITIAL SETTING AND ADJUSTMENT Item Remarks [Details] button Show the detail window for the alert. See section 1.8.7. [Edit] button Edit the alert number. This appears when the alert notifica- tion sentence is ALF. [Import] button Import the alert definition for currently displayed equipment. [Export] button Export the alert definition for currently displayed equipment.
  • Page 72 1. INITIAL SETTING AND ADJUSTMENT Item Remarks [Input Unit] Select the input source for the alert. • For other than sensors: [Internal], [Digital] • For sensors: [CCRS], [Digital], [MODBUS] [Is Active] Activate/Deactivate the alert. [YES]: activated, [NO]: deacti- vated. [Priority] The priority of the alert group ([Emergency]/[Alarm]/[Warn- ing]/[Caution]).

  • Page 73: How To Edit An Alert Definition

    1. INITIAL SETTING AND ADJUSTMENT 1.8.7 How to edit an alert definition 1. Click the [Details] button on the alert defi- nition window of equipment type, refer- ring to the figure in step 2 of section 1.8.5. The [Alert Details] window is shown.

  • Page 74: Save And Sync] Menu

    1. INITIAL SETTING AND ADJUSTMENT 1.10 [Save and Sync] Menu After completing the settings on the [Own Ship Setting], [Installation Parameters], [CCRS], [TCS], [AMS] and [Alert Define List] menus, confirm the consistency of the configuration and save it on this menu. By saving the configuration, the configuration data can be copied to other processor units connected to the network.
  • Page 75 1. INITIAL SETTING AND ADJUSTMENT Note 2: If you did the consistency check and save after entering settings on [Own Ship Setting], reboot the unit. 5. After saving the configuration, confirm that the Equipment ID of all units are cor- rect.

  • Page 76: How To Save The Configuration Data To A Medium

    1. INITIAL SETTING AND ADJUSTMENT 1.10.2 How to save the configuration data to a medium You can save the configuration data to a medium (PC, USB memory, etc.). Set the medium and then do as follows: 1. Click [Export] at the upper right of the [Save and Sync] menu. Click [Export].

  • Page 77: System Monitor] Menu

    9876-xxxx Sync This menu displays system information of units as shown below. • Processor unit (EC-3000) • Monitor (Furuno make only) • Control unit • Radar processor unit • Sensor Adapter Click [System Log] to save the log data to a medium (PC, USB memory, etc).

  • Page 78: Software Update] Menu

    1. INITIAL SETTING AND ADJUSTMENT 1.12 [Software Update] Menu Update the software of the processor unit EC-3000, radar processor unit RPU-013, and control unit RCU-024/025/026 on the [Software Update] menu. For the update of the Sensor Adapter, see section 2.3. Note: To update the software with the update file, access the [Common Installation Setting] menu via LAN connection.

  • Page 79: Factory Test & Default] Menu

    1. INITIAL SETTING AND ADJUSTMENT 1.13 [Factory Test & Default] Menu The [Factory Test & Default] menu does the factory test to check operation and re- stores the system default settings. Factory Test Click [Start] to perform the factory test. The result of the test is shown on the display. The result of the test is shown in this area.

  • Page 80: Conning] Menu

    1. INITIAL SETTING AND ADJUSTMENT Note: When you restore the Chart Radar default, the initialization of the radar proces- sor unit needs more time than the processor unit. After completing the system reboot of the processor unit, wait for about one minute until the system reboot is completed, and the communication between processor unit and radar processor unit is estab- lished.
  • Page 81 1. INITIAL SETTING AND ADJUSTMENT Menu item Explanation Items in the view area [Name] Enter the name of the sheet displayed on the view area. The sheet name entered here appears on the status bar of the con- ning display. [Show] Check the checkbox to show the sheet name on the status bar of the conning display.

  • Page 82: How To Select The Data Source

    1. INITIAL SETTING AND ADJUSTMENT 4. Click [Ship & Route Parameter], then open the [Function2] tab. 5. Check the checkbox of [Show Side Conning at Radar mode]. 6. Click the [Save] button. 1.14.1 How to select the data source Click on the advanced settings window (see section 1.14.2.) to display the [Data Source Select] window.

  • Page 83: Advanced Settings Window

    1. INITIAL SETTING AND ADJUSTMENT 1.14.2 Advanced settings window Note: Do not use the following components: • CommonMP • Fore & AFT bridge (Wide) Havyard122 • Fore & AFT bridge (Wide) U10662/ • Fore & AFT bridge (Wide) NB802/818/ 10683/10782/1340 830/832/857 •...
  • Page 84 1. INITIAL SETTING AND ADJUSTMENT [Decimal Place]: Check the checkbox to show the value after decimal point. Zero Padding: Set the number of decimal points to show "0" in the [Source] for each object. [Unit]: Enter the unit. [5 lines]: Check the checkbox to show 5 lines data on the component. •...
  • Page 85 1. INITIAL SETTING AND ADJUSTMENT • Graph [Title]: Enter the title of the component. [Type]: Set the graph type. • [(2x)Time/Y-graph]: The [Primary (Y1)] and [Secondary (Y2)] are used as Y-coor- dinate for two independent graphs. The time is used as the X-coordinate for both graphs.
  • Page 86 1. INITIAL SETTING AND ADJUSTMENT [Primary Source]: Select the data source of the green bar. [Secondary Source]: Select the data source of the triangle below the bar. [Start Value]: Set the minimum value of the bar. [End Value]: Set the maximum value of the bar. [Decimal Place]: Check the checkbox to show the value after decimal point.
  • Page 87 1. INITIAL SETTING AND ADJUSTMENT [Source]: Select the data source same as [Object 1] or [Object 2] to show the ab- breviated name of the data source unit. [Label]: Enter the data name of [Object 1 (or 2)]. [Limit]: Set the digit number of the data of [Object 1 (or 2)]. [Source]: Select the data source of [Object 1 (or 2)].
  • Page 88 1. INITIAL SETTING AND ADJUSTMENT [Title]: Enter the title of the component. [Label]: Enter the data name. [Actual Source]: Select the data source of the actual thruster generating power. [Rated Source]: Select the data source of the rated thruster generating power. •...
  • Page 89 1. INITIAL SETTING AND ADJUSTMENT [Medium] component (two blocks.) • Azimuth Propulsion [Title]: Enter the title of the component. Azimuth [Label]: Enter the data name shown at the bottom of the indicator. [Source]: Select the data source of the azimuth propulsion. [Unit]: Enter the unit for the azimuth propulsion.
  • Page 90 1. INITIAL SETTING AND ADJUSTMENT • Command Matrix [Title]: Enter the title of the component. [Control Type]: Set the number of columns for the matrix. [Thruster Num]: Set the number of rows for the matrix. [Control Type Label]: Enter the text that appears at the top of the matrix. [Name]: Enter the text that appears at the left side of the matrix.
  • Page 91 1. INITIAL SETTING AND ADJUSTMENT • Drift And Radius [Title]: Enter the title of the component. • Dual Azimuth Promotion [Title]: Enter the title of the component. [Location]: Select the position of thruster ([FORE] or [AFT]). [Title]: Enter the title to show at the top of the indicator. [Degree] [Actual]: Set the source of the angle which the needle of the outer periphery points to (feedback angle of the thruster).
  • Page 92 1. INITIAL SETTING AND ADJUSTMENT [Dial Title]: Enter the title to show at the top of [Dial Meter 1 (or 2)] indicator. [Primary Source]: Select the data source of the long pointer of [Dial Meter 1 (or 2)] indicator. [Secondary Source]: Select the data source of the outer pointer of [Dial Meter 1 (or 2)] indicator.
  • Page 93 1. INITIAL SETTING AND ADJUSTMENT [MAX Generate (kW)]: Enter the maximum values of the graphs ([Object 1] to [Ob- ject 9]). [Source State]: Set the source that outputs operating status. The green indication of the graph means the generator is working, the red indication means the generator has stopped.
  • Page 94 1. INITIAL SETTING AND ADJUSTMENT • Graph (Wind Speed & Direction) [Title]: Enter the title of the component. [Label]: Enter the title of [Wind Speed] and [Wind Direction]. [Source]: Select the source of [Wind Speed] and [Wind Direction]. [Unit]: Enter the unit of [Wind Speed] and [Wind Direction]. [Smoothing]: Select [Apply] to smooth the graph.
  • Page 95 1. INITIAL SETTING AND ADJUSTMENT [Decimal Place]: Check the checkbox to show the value after decimal point. [Mathematical Sign]: Check the checkbox to show the minus sign (-) when the value is a negative figure. • Next Leg • Pitch And Roll [Title]: Enter the title of the component.
  • Page 96 1. INITIAL SETTING AND ADJUSTMENT [Latitude Source]: Select the data source of the latitude. [Longitude Source]: Select the data source of the longitude. [DATUM Source]: Select the data source of the datum. [Local Time (Time) Source]: Select the data source of the time information. [Local Time (Date) Source]: Select the data source of the date information.
  • Page 97 1. INITIAL SETTING AND ADJUSTMENT • Vertical Bar [Title]: Enter the title of the component. [Top Source]: Select the data source for the data at the top of the vertical bar. [Bottom Source]: Select the data source for the data at the bottom of the vertical bar. [Primary Source]: Select the data source of the bar.
  • Page 98 1. INITIAL SETTING AND ADJUSTMENT [Change button]: Check the checkbox to show the [Change] button. Click the [Change] button to show the [Vertical Graph (Middle)] hidden behind. Check the checkbox of [Show] in [Change Button] to show the component hidden behind. [Decimal Place]: Check the checkbox to show the value after decimal point.
  • Page 99 1. INITIAL SETTING AND ADJUSTMENT [Mathematical Sign]: Check the checkbox to show the minus sign (-) when the value is a negative figure. • Wind Direction [Title]: Enter the title of the component. [Location]: Select the reference point for the wind direction and speed from the pull- down list.
  • Page 100 1. INITIAL SETTING AND ADJUSTMENT [SOG Longitudinal Speed]: Select the data source of the longitudinal SOG. [STW Longitudinal Speed]: Select the data source of the longitudinal STW. [Bow Transverse Speed]: Select the data source of the longitudinal speed at the bow position.
  • Page 101 1. INITIAL SETTING AND ADJUSTMENT • Fore & AFT bridge, Fore & AFT bridge (Wide) to Fore & AFT bridge9 (Wide) Multiple components are combined on this window. The contents are same as the single component. • NAV Information [Title]: Enter the title of the component. [Component.Height]: Select the size of component.
  • Page 102 1. INITIAL SETTING AND ADJUSTMENT • Present Leg • Speed And Transverse [Title]: Enter the title of the component. [Location]: Select the reference point for the speed from the pull-down list. [Speed Label]: Enter the title shown at the upper of the longitudinal speed value. [Transverse Label]: Enter the title shown at the upper of the transverse speed value.
  • Page 103 1. INITIAL SETTING AND ADJUSTMENT • Vertical Graph [Title]: Enter the title of the component. [Label]: Enter the title of [Primary] or [Secondary]. [Source]: Select the data source of [Primary] or [Secondary]. [Source (sub)]: Set the other data source in the same range as the data of [Primary]. The [Source (sub)] appears only when the source of [Secondary] is not entered.

  • Page 104: Network Transmission Setting Between Ecdis And Radar

    ECDIS route and user chart symbol on the radar display. For non-Furuno radar, the ECDIS chart display can not show the radar echo. The TT symbol can be shown on the ECDIS chart display by connecting the ECDIS and radar by serial interface.
  • Page 105 1. INITIAL SETTING AND ADJUSTMENT For FCR-29 series 1) Press and hold the 1 HL OFF key, then press the MENU key five times. 2) Select [9 RADAR INSTALLATION][4 TT PRESET][1 TTM/TTD PREFER- ENCE] and then select [TRUE]. 4. Access the [Common Installation Setting] menu on the ECDIS. 5.
  • Page 106 14. Open the [Own Ship Setting] menu, then select [Radar Antenna] on the menu bar. 15. For one antenna unit, check [RAS001]. For two antenna units, check [RAS001] and [RAS002]. For non-Furuno radar 1. Open [Installation Parameters][Sensor Setting][Other Sensor] menu. 2. Check [OTR001] and enter [RA0201] to [SFID]. Do not use other than [RA0201] to [RA0204].

  • Page 107: How To Set The Forwarding Distance

    1. INITIAL SETTING AND ADJUSTMENT 1.16 How to Set the Forwarding Distance Set the forwarding distance* as follows. The configuration can be copied to other units connected to the network after saving the configuration. *: The distance the ship travels straight after the steering control. 1.

  • Page 108: Synchronization With Ship's Clock

    1. INITIAL SETTING AND ADJUSTMENT 1.17 Synchronization With Ship’s Clock The time (UTC) received from the GPS is shown. If the ZDA sentence is input from the ship’s clock, the time synchronized with the ship’s clock can be shown. Do as follows to activate the synchronization with the ship’s clock. Note: The local time setting is not available when the synchronization with ship’s clock is active.
  • Page 109 1. INITIAL SETTING AND ADJUSTMENT 4. Click [Ship & Route Parameters], then click the [Function2] tab. 5. Check the checkbox of [Color of own ship’s information (TEXT) will be changed by result of integrity check]. 6. Click the [Save] button to save the configuration. 1-103...
  • Page 110 1. INITIAL SETTING AND ADJUSTMENT This page is intentionally left blank. 1-104...

  • Page 111: Setting For Sensor Adapter

    SETTING FOR SENSOR ADAPTER The default Equipment ID of the Sensor Adapter is [MCV016]. Set the individual Equipment ID before connecting to the network. Connect the Sensor Adapter to the processor unit after setting the Equipment ID. Then enter the other settings of the Sensor Adapter from the [Common Installation Setting] menu on the processor unit.

  • Page 112: How To Save The Log File

    2. SETTING FOR SENSOR ADAPTER How to restore the default Equipment ID When you can not define the Equipment ID of the Sensor Adapter, restore the default and set the Equipment ID again. 1. Turn on the No. 8 segment of the DIP switch S10 on the board in the MC-3000S. 2.

  • Page 113: How To Activate The Maintenance Program

    2. SETTING FOR SENSOR ADAPTER 2.3.1 How to activate the maintenance program 1. Turn off all Sensor Adapters. 2. Connect the applicable MC-3000S to the PC with the LAN cable. 3. Turn on the No. 6 of the DIP-SW (S10) on the MC-CS board (24P0114). 4.

  • Page 114: How To Update The Firmware Program

    2. SETTING FOR SENSOR ADAPTER 2.3.3 How to update the firmware program 1. Delete the version number from the firmware binary file name. Example 2450081-01010088_mc_cs_mainpg.bin Program number Version number Delete the version number from the file name. Example 2450081_mc_cs_mainpg.bin 2. Activate the maintenance program of the Sensor Adapter MC-3000S. ®...
  • Page 115 2. SETTING FOR SENSOR ADAPTER 7. After the login, enter "dir". The file names that are saved in the Sensor Adapter are displayed. Confirm that the file names shown below are shown on the display. Enter the user name. Enter the user name. Enter the user name.
  • Page 116 2. SETTING FOR SENSOR ADAPTER This page is intentionally left blank.

  • Page 117: Dual Gyro System (Ecdis Only)

    DUAL GYRO SYSTEM (ECDIS Only) The dual gyro system by Yokogawa Denshikiki is available for the ECDIS. The system configuration is as shown below. Then, to set the gyro sensors, do as follows. HUB-3000 Contact signal Heading switch status No.3 GYRO No.1 GYRO (GYRO selector) No.2 GYRO...
  • Page 118 3. DUAL GYRO SYSTEM (ECDIS Only) 7. Click [TCS] on the tab bar. : Shown when [YOKOGAWA] is selected for [Manufacture]. 8. Select the signal format for the gyro selector. • [Digital]: Use the contact signal for the gyro selector. •...

  • Page 119: Hub-3000 Igmp Querier Setting

    HUB-3000 IGMP QUERIER SETTING When constructing a network with two or more FAR-27 radars via HUB-3000, set the IGMP querier of the HUB-3000. Parts and equipment needed • PC with the RS-232C serial port (D-SUB 9 pin connector) • RS-232C cross cable (D-SUB 9 pin) •...
  • Page 120 4. HUB-3000 IGMP QUERIER SETTING 5. Click [OK]. 6. Click [Setup], [Serial Port] to show the setting window. 7. Set the options as shown below on the setting window. • [Baud rate]: 9600 • [Data]: 8 bit • [Parity]: none •...
  • Page 121 4. HUB-3000 IGMP QUERIER SETTING 17. Enter "write" and press the Enter key. Reboot the HUB-3000 after performing "write" to enable the querier function of HUB-3000. Switch# config Switch_config# ip igmp-snooping querier Switch_config# show ip igmp-snooping Global IGMP snooping configuration: ----------------------------------- Globally enable : Enabled...
  • Page 122 4. HUB-3000 IGMP QUERIER SETTING This page is intentionally left blank.

  • Page 123: Raytheon Anschutz Autopilot Np-5400

    RAYTHEON ANSCHUTZ AUTO- PILOT NP-5400 The Raytheon Anschutz Autopilot NP-5400 is different from other autopilots in many respects, thus distinctive settings are required at the FMD. This chapter presents the information necessary to set up the FMD for use with the NP-5400. All cables from the HCS, Other Sensor 1, Other Sensor 2 and the BNWAS should be connected to the No.1 ECDIS (ECD001).

  • Page 124: Np-5400 Alert And Backup Navigator Setting

    5. RAYTHEON ANSCHUTZ AUTOPILOT NP-5400 5.1.2 NP-5400 alert and backup navigator setting Use “Other Sensor” for the connection between the NP-5400 and the AMS. For exam- ple, use [Other Sensor 1] for “Alert” as follows. On the [Other Sensor - OTR001] setting screen, set [Alert Information Source] to [Alert Sentence], and set [Sensor Name] to [Autopilot] or [NP-5400].

  • Page 125: Serial Ports Configuration

    5. RAYTHEON ANSCHUTZ AUTOPILOT NP-5400 5.1.4 Serial ports configuration Configure the serial port connected to each port (TCS, alert, speed, position, and time) on the NP-5400. Below is a connection example.  EC-3000  Sensor Adapter • Ch2: HCS001 • Ch3: HCS001 (for position and time) •...

  • Page 126: Tcs Port Setting

    5. RAYTHEON ANSCHUTZ AUTOPILOT NP-5400 TCS Port Setting Output setting Communication (input/output sentences) between the FMD and NP-5400 for the TCS application are as shown in the table below. FMDNP-5400 NP-5400FMD PANZCRQ AGHDT PANZEST AGHSC PANZPSR AGTHS PANZHTD HRSA — PANZRSA —...

  • Page 127: Np-5400 Alert Port Setting

    5. RAYTHEON ANSCHUTZ AUTOPILOT NP-5400 NP-5400 Alert Port Setting This setting connects the FMD to the NP-5400’s MOXA LAN-Serial Converter (BAM). For the output setting, like the normal Alert related setting, check the check box at "Output sentence name with destination this with sensor.". NP-5400 Backup Navigator Port Setting This setting connects the FMD to the NP-5400’s MOXA LAN-Serial Converter (BN- WAS).

  • Page 128: Speed Port Setting

    5. RAYTHEON ANSCHUTZ AUTOPILOT NP-5400 Speed Port Setting Speed data must always be transmitted from the FMD to the NP-5400. Set the speed port as shown to the right. Backup Navigator Setting The backup navigator (ALR sentence) can be output as shown below. Do this when a BNWAS is connected.

  • Page 129: Appendix 1 Equipment Id List

    APPENDIX 1 EQUIPMENT ID List Gateway Sensor Equipment ID Equipment Name Remarks Network Network MFD001 No.1 MFD 192.168.31.51 172.31.16.51 MFD002 No.2 MFD 192.168.31.52 172.31.17.51 MFD003 No.3 MFD 192.168.31.53 172.31.16.52 MFD004 No.4 MFD 192.168.31.54 172.31.17.52 MFD005 No.5 MFD 192.168.31.55 172.31.16.53 MFD006 No.6 MFD 192.168.31.56 172.31.17.53...
  • Page 130 APPENDIX 1 EQUIPMENT ID List Gateway Sensor Equipment ID Equipment Name Remarks Network Network RAD112 No.2 FAR-28 Radar 192.168.31.22 172.31.17.11 RAD113 No.3 FAR-28 Radar 192.168.31.23 172.31.16.12 RAD114 No.4 FAR-28 Radar 192.168.31.24 172.31.17.12 RAD115 No.5 FAR-28 Radar 192.168.31.25 172.31.16.13 RAD116 No.6 FAR-28 Radar 192.168.31.26 172.31.17.13 RAD117 No.7 FAR-28 Radar 192.168.31.27...

  • Page 131: Appendix 2 Subsystem

    APPENDIX 2 SUBSYSTEM Where the network configuration requires the use of a HUB-3000, the [Subsystem] settings must also be configured. For example, in a configuration like the one below, if the Subsystem settings are not configured, No. 1 ECDIS can only receive data from No. 1 Gyro, and No. 2 ECDIS can only receive data from No.

  • Page 132: Appendix 3 Rcb-002 Ip Address Setting

    APPENDIX 3 RCB-002 IP ADDRESS SETTING When multiple Radar Connection Box RCB-002s are connected to the same network, change the IP address as follows. Assign a different IP address to each RCB-002. IP address setting is not required for configurations with a single RCB-002. Preparation •...
  • Page 133 APPENDIX 3 RCB-002 IP ADDRESS SETTING 6. Enter the IP address as follows, then click the [SET] button. • No.1 RCB: 192.168.031.111 (Default setting) • No.3 RCB: 192.168.031.113 • No.2 RCB: 192.168.031.112 • No.4 RCB: 192.168.031.114 7. Click the [CLOSE] button. 8.
