Measuring the 0-60 time of your vehicle

1. Install PerformanceBox into your vehicle as described in the 'Quick Start Guide' section of
this manual.
2. Press the MENU button to select the Performance Mode.
▲▼
3. Now use the
top right hand corner:
4. The left hand side of the screen shows your live velocity unless you are in an area of poor
satellite reception in which case it flashes an image of a satellite.
5. Now perform your 0-60 acceleration run. As your vehicle goes over 60 mph the time will
instantly show in the 0-60 section of the window.
6. If you come to a stop you will see that this time remains on view. The Vmax section will also
show the highest speed you attained during this particular run.
7. You can now instantly start another 0-60 acceleration, as you pull away the screen will
reset and show your new values as you cross 60 mph.
02/05/2014
This screen shows the time and end velocity of two user-
configurable distances, i.e. 0-100m. If the units are changed to
feet then the two test ranges default to 60' and 330', but can be
changed to the desired distance. Start Speed is also configurable.
This screen shows the time and end velocity of two user-
configurable distances, i.e. 0-400m. If the units are changed to
feet then the two test ranges default to 660' and 1320', but can be
changed to the desired distance. Start Speed is also configurable.
This screen shows the current acceleration and peak acceleration
achieved by PerformanceBox. A level bar at the bottom of the
screen also shows this information in graphical form. The MAX
value is cleared by pressing the RESET button.
This screen shows the current deceleration and peak deceleration
achieved by PerformanceBox. A level bar at the bottom of the
screen also shows this information in graphical form. The MAX
value is cleared by pressing the RESET button.
This screen shows the current lateral acceleration and peak lateral
acceleration achieved by the PerformanceBox. A level bar at the
bottom of the screen also shows this information in graphical form.
The MAX value is cleared by pressing the RESET button.
buttons to scroll to the ACCEL screen. This screen shows 0-60 in the
Page 13
Performance Mode
