Quick Start Guide

https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/VBOX_4_Product_Range/VBOX_4/

Quick_Start_Guide

Getting Started

Registration

Please register your VBOX 4 unit so that Racelogic can continue to provide you with notifications about the latest

software releases and firmware upgrades for your Racelogic product, and offer technical support.

Mounting and Connecting

Basic Setup

1. Connect one end of the antenna cable to the connector on the antenna.

2. Place the antenna on the roof of the vehicle.

You can read more about how and where to place the GNSS antenna here.

3. Connect the power cable to the PWR port on the VBOX 4 unit.

4. Connect the Tablet/Laptop to the USB port on the VBOX 4 unit with the USB cable (RLCAB042).

5. Secure the VBOX unit in the vehicle.

You can, for example, place it in the foam insert in the carry case and secure the carry case in the back seat of

the vehicle with the seat belt.

Need help?

Do you have a question about the VBOX 4 and is the answer not in the manual?

Page 1 Quick_Start_Guide Getting Started Registration Please register your VBOX 4 unit so that Racelogic can continue to provide you with notifications about the latest software releases and firmware upgrades for your Racelogic product, and offer technical support. Register your device here.
Page 2 You can find the complete information about how to connect VBOX 4 ADAS to the different modules and accessories required for testing here. VBOX 4 units have a USB 2.0 connector that you can use to configure your VBOX unit and output real-time serial data at the full 100 Hz data rate.
Page 3 Connection The connection between the VBOX unit and the computer should be made via USB or Bluetooth for optimum performance. When the VBOX unit is physically connected and powered, open the VBOX Setup software and use the dropdown list to select the COM port that your VBOX unit is connected to.
Page 4 Depending on which menu you have open, the question mark icon will open up the corresponding User Guide page in the Help Racelogic Support Centre, to provide more information about the features and settings in this menu. Language Change the operating language.
Page 5: General Menu
After making changes to the configuration, Write to you must press the Write to unit button to unit make sure that the settings are uploaded to the connected VBOX unit. Closes the software, if changes have not Close been saved to the unit, you will be prompted to save the settings.
Page 6 Ethernet Menu MFD Menu...
