02 - VBOX Sim Pack Installation and Setup
Please follow the steps below to install and configure the supplied hardware and software.
Software
IMPORTANT
– Microsoft Windows 10 or newer is required to use the software
1. Install the VBOX Sim Software which can be found on the supplied SD card. Alternatively, you can download the
software from the
VBOX Motorsport
2. Install FTDI USB drivers for the serial to USB cable.
3. If an external Video Capture Device is being used, install the relevant manufacturer software required to support
the video capture card.
https://en.racelogic.support//Product_Info/Modules_and_Accessories/VBOX_Sim_Pack/VBOX_Sim_Pack_User_Guide/02_-
Website.
_VBOX_Sim_Pack_Installation_and_Setup
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Racelogic VBOX Sim Pack
Summary of Contents for Racelogic VBOX Sim Pack
- Page 1 02 - VBOX Sim Pack Installation and Setup Please follow the steps below to install and configure the supplied hardware and software. Software IMPORTANT – Microsoft Windows 10 or newer is required to use the software 1. Install the VBOX Sim Software which can be found on the supplied SD card. Alternatively, you can download the...
- Page 2 There are two mounting options included in the box - Adhesive Dual Lock or the RLACS260 roll cage mount. You can either Dual Lock the VBOX LapTimer to your monitor bezel or secure it to your sim rig using the roll cage mount. https://en.racelogic.support//Product_Info/Modules_and_Accessories/VBOX_Sim_Pack/VBOX_Sim_Pack_User_Guide/02_- _VBOX_Sim_Pack_Installation_and_Setup...
- Page 3 2. Plug the serial to USB cable in to the VBOX LapTimer. The 5 pin Lemo connector plugs in to the bottom socket on the right side of the VBOX LapTimer. The USB connector plugs in to your PC. https://en.racelogic.support//Product_Info/Modules_and_Accessories/VBOX_Sim_Pack/VBOX_Sim_Pack_User_Guide/02_- _VBOX_Sim_Pack_Installation_and_Setup...
- Page 4 ◦ If you are using a single monitor, plug one end of an HDMI cable in to the ‘IN’ HDMI socket on the capture card, then plug the other end to a spare HDMI socket at the back of your computer. Note: The video capture card will most likely be recognised as a new monitor. Navigate to Windows Display https://en.racelogic.support//Product_Info/Modules_and_Accessories/VBOX_Sim_Pack/VBOX_Sim_Pack_User_Guide/02_- _VBOX_Sim_Pack_Installation_and_Setup...
- Page 5 HDMI socket on the back of your computer where your main screen was connected before. 6. After installing the software and making sure the hardware is correctly plugged in to the computer, a restart is recommended. https://en.racelogic.support//Product_Info/Modules_and_Accessories/VBOX_Sim_Pack/VBOX_Sim_Pack_User_Guide/02_- _VBOX_Sim_Pack_Installation_and_Setup...
